AlphaGrip AG5T(SKR-4300UT) Keyboard with Track-ball
1.General Specification
1.1
USB Standard
The USB keyboard is a bus powered compound device that has an external USB downstream HUB port and an
embedded USB composite function device. It is complied with USB standard version 1.1 and HID standard version
1.1. The USB transmission speed for the embedded USB HID keyboard and HID Mouse are 1.5Mbps, which is low
speed USB. The USB related spec is available on the web page http://www.usb.org/
1.2
System requirements
The followings are the requirements for using the USB HUB and embedded Keyboard and Mouse.
1. An USB Downstream port with "A" type connector. The USB Downstream port must have capable to
supply 500mA of VCC current.
2. Operating system with USB compliant device driver and HID device support. (Windows 98 Second
Edition /ME/2000/XP or lather version is recommended). Note: The Windows 98 Second Edition
/ME/2000 and Windows XP are registered trademark of Microsoft Corporation.
1.3
Electrical Specification
Connector
USB speed
Operating voltage range
Operating current
Operating temperature
Storage temperature
Operating humidity
Storage humidity
a "B" type connector for USB up stream port and a
"A" type connector for USB down stream port.
Low speed (1.5MBPS) for embedded Function,
Full speed (12MBPS) for integrated USB HUB
4.5~5.25V
Max 500mA
0 ~ 40℃
-40 ~ 60℃
0~90% RH non-condensing
0~95% RH non-condensing
Advertisement
Table of Contents
Related Manuals for Alphagrip AG5T
Summary of Contents for Alphagrip AG5T
- Page 1 AlphaGrip AG5T(SKR-4300UT) Keyboard with Track-ball 1.General Specification USB Standard The USB keyboard is a bus powered compound device that has an external USB downstream HUB port and an embedded USB composite function device. It is complied with USB standard version 1.1 and HID standard version 1.1.
- Page 2 2.Key Position number & Layout 1-1 Key position number Space " Shift Shift nl pa cl & > < 2-2 Key Layout...
- Page 3 3.Key Operation 1-1 AG-5 Button/Character Chart Capital Letter Punctuation Shift Number Shift Caps Lock Number Lock Function Lock Key No. Single Key shift (note 1) note 2 Shift note 3 Shift note 2 Shift note 2 Shift note 2 Shift &...
- Page 4 Punctuation Shift Number Shift Caps Lock Number Lock Function Lock Capital Letter Key No. Single Key shift (note 1) note 2 Shift note 3 Shift note 2 Shift note 2 Shift note 2 Shift Page Page Page Page Enter Enter Enter Enter Enter...
- Page 5 AlphaGrip technology enables comfortable, high speed, desk-free typing and gaming on your PC. The key to the AlphaGrip is the placement of rocker buttons and button clusters on the back of the device. When you grasp the AG-5 your fingers naturally fall on all the buttons you need (including button clusters on the front of the device where your thumbs naturally fall) to generate all the letters of the alphabet with a single keystroke per character.
-
Page 6: Important Safety Information
Use of the AG-5 is at your own risk. AlphaGrip, Inc., its employees, shareholders, consultants, affiliates, marketers, resellers, and manufacturing partners, hereby disclaim any liability whatsoever for any injuries or damages that may arise as a result of your use of the AG-5. - Page 7 CONSEQUENTIAL AND CERTAIN OTHER DAMAGES AlphaGrip, Inc. warrants that for a period of 90 days immediately following the purchase of your AG-5, under normal use, it will be free from defects in material and workmanship. THIS LIMITED WARRANTY APPLIES ONLY TO THE ORIGINAL PURCHASER AND LASTS ONLY FOR AS LONG AS SUCH PURCHASER CONTINUES TO OWN THE PRODUCT.
- Page 8 FCC NOTICE THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITION: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERATION.
