Summary of Contents for Aeroex Technologies ROX-400
- Page 1 AEROEX Technologies Inc. Oil Mist Eliminator ROX-400/600/800/1100/2000 Installation & Service Manual www.aeroex.com AEROEX Technologies Inc. 705-734-0199 17 Hamilton Rd sales@aeroex.com Barrie, ON Canada, L4N 8Y6 orderdesk@aeroex.com Tel: 705-734-0199 Fax 705-734-1013 Rev 7-02/19...
-
Page 2: Installation
Installation: • Mount mist collector level. • Units can be mounted directly on top of machines, on a post or on the wall. • Ensure that there is 20” free space above to open lid and remove filters. • Minimize the length of ducting to avoid air flow loses. •... -
Page 3: Maintenance
Maintenance: The mist collector can operate for long periods without maintenance. The maintenance period will depend on the type of oil & solids/chips in air stream. Some soluble oil & synthetic concentrates will congeal requiring the mechanical separator elements and agglomerator filter media to be manually cleaned/washed. The air flow will reduce if this happens. - Page 4 Disassembly: Disconnect and lock-out electrical power. Remove bolts (4) on hinged lid. Lid jack nut. Insert 3/8” bolt and jack lid up to open. Remove the bolts on impeller inlet plate and remove. Remove nut on pressure plate and remove. Remove 1 stage mechanical separation elements.
- Page 5 On models prior to Jan 2013 Replace bottom foam gasket each time HEPA filter is changed. Check oil drain line, clean if necessary. To remove to remove 3 stage filter (HEPA), loosen straps. Rev 7-02/19 www.aeroex.com orderdesk@aeroex.com...
-
Page 6: Filter Options
ROX-400 / 600 Use on sticky or high solids coolant applications Use on oil applications stage agglomerator filter ring ROX-400 / 600 filter ring, coolant 600FR-2204 ROX-400 / 600 filter ring, oil 600FR-2206 Pressure Plate for Filter Ring 600PP-2002 One time purchase when converting to filter ring. - Page 7 ROX-800 / 1100 Item Description Part # Stage Mechanical Element 1100ME-002 ROX-800 / 1100 Stage Agglomerator Filter 1100AF-012 ROX-800 / 1100 Coolant stage agglomerator filter, 1100AF-2010 for used with filter ring ROX-800 / 1100 Use on sticky or high solids coolant applications Use on oil applications stage agglomerator filter ring ROX-800 / 1100 filter ring, coolant...
- Page 8 ROX-2000 Item Description Part # Stage Mechanical Element 2000ME-002 ROX-2000 Stage Agglomerator Filter 2000AF-012 ROX-2000 Coolant stage agglomerator filter, 2000AF-2010 for used with filter ring ROX-2000 Use on sticky or high solids coolant applications Use on oil applications stage agglomerator filter ring ROX-2000 filter ring, coolant 2000FR-2204 ROX-2000 filter ring, oil...
