- Page 1 VOIP BTS Operation Manual Version 1.2 Draft Copy 240 S Pineapple Ave, Ste 701, Sarasota, FL-34236 Tel: (941) 954-8701 Fax: (941) 954-8595...
-
Page 2: Table Of Contents
• Physical Device • AC Power Port • Antenna Ports • Ethernet Port • Status Indicator • Powering ON the xMax VOIP BTS • Powering OFF the xMax VOIP BTS • Technical Support • Certification • Warranty Information 240 S Pineapple Ave, Ste 701, Sarasota, FL-34236... - Page 3 Part 15 of the FCC's rules. This device is a commercial unit and should be installed by licensed technician. This device is capable of transmitting/receiving voice and data services to and from xMax handsets. The xMax VOIP BTS is installed with all the necessary software to make wireless VOIP phone calls using xG proprietary physical layer technology.
-
Page 4: Physical Device
Physical Device: The xMax VOIP BTS is housed in a standard rackmount 1U chassis. The dimensions of the device are 19”*10.19”*1.75” Pictures of this device are shown below: Figure 1: xMax VOIP BTS Front/Side View Figure 2: xMax VOIP BTS Rear View... -
Page 5: Ac Power Port
AC Power Port: AC Power: The device operates of 110V/220VAC; 50/60Hz and single-phase AC power line. The device is connected to the AC power line5 using a standard 3-prong power connector. This is shown in the following pictures: Figure 3: Power Connector and Rear Toggle Switch The Toggle switch on the rear end (near the power connector) is the main switch. -
Page 6: Antenna Ports
Before turning ON the device, please connect the antenna using the recommended coaxial cable to the chassis mount BNC connector installed on the rear of the unit. The cable and antenna acts like a load to the xMax VOIP BTS. Never turn the unit ON without installing the cable and antenna. -
Page 7: Ethernet Port
Figure 6: Ethernet Port The Ethernet Port is used to connect the Base Station to the SIP server. Connect the SIP server to the Base station before powering ON the xMax VOIP BTS. 240 S Pineapple Ave, Ste 701, Sarasota, FL-34236... -
Page 8: Status Indicator
Status Indicator: There are five LEDs installed on the front Panel. These LEDs are bicolor and will turn Green or Red depending on the status of the xMax VOIP BTS. A picture of these LEDs is shown below: Figure 7: Status Indicator LEDs... -
Page 9: Powering On The Xmax Voip Bts
Powering ON the xMax VOIP BTS: Follow the following steps to turn on the device: 1- Toggle the front and rear switch in the OFF position. 2- Connect the power chord to the AC (110V main line) 3- Connect the coaxial cable and antenna to the Antenna port. -
Page 10: Technical Support
Code of Federal Regulations (CFR), Title 47 - Telecommunication, FCC Part 15 Subpart B- Class A Requirements. A copy of the certification can be requested from xG Technology, Inc by submitting your request in writing. Our address is: xG Technology, Inc...
