Summary of Contents for AirTegrity wireless 4000 Series
- Page 1 Series 4000 Router Installation Guide Rev 4.06, 2005 March 04...
- Page 2 All rights reserved. No part of this book or manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or by any information storage and retrieval system, without the express written permission from the AirTegrity Wireless, Inc., except for the inclusion of a brief quotation(s) used in a review.
- Page 3 The information is provided on an “as is” basis. The author, AirTegrity Wireless, Inc., shall have neither liability nor responsibility to any person or entity with respect to any loss or damage arising from the information contained in this book or from the use of equipment or software that might accompany it.
- Page 4 We, AirTegrity Wireless Inc., of 276 Kingsbury Grade, Suite 206, Stateline Nevada, 89449-5188, USA, declare under our sole responsibility that the model 4000 series installed with the 2024-06 radio card to which this declaration relates is in conformity with the following standards and/or other normative...
-
Page 5: Readers' Feedback
Frontmatter Readers’ Feedback At AirTegrity Wireless, Inc., our goal is to create in-depth technical documentation of the highest quality and value. Each book is crafted with care and precision, involving many hours of research and the collaboration of many members from the development teams. - Page 6 AirTegrity Limited Warranty Limited Warranty Hardware. AirTegrity Wireless, Inc. (“AirTegrity“), warrants that commencing from the date of delivery to Customer (but in case of resale by an AirTegrity reseller, commencing not more than ninety (90) days after original shipment by AirTegrity), and continuing for a period of the longer of (a) ninety (90) days or (b) the period set forth in the Warranty Card accompanying the Product (if any), the Hardware will be free from defects in material and workmanship under normal use.
- Page 7 Frontmatter DISCLAIMER OF WARRANTY. EXCEPT AS SPECIFIED IN THIS WARRANTY, ALL EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS, AND WARRANTIES INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NONINFRINGEMENT, SATISFACTORY QUALITY OR ARISING FROM A COURSE OF DEALING, LAW, USAGE, OR TRADE PRACTICE, ARE HEREBY EXCLUDED TO THE EXTENT ALLOWED BY APPLICABLE LAW.
-
Page 8: Documentation Conventions
About the Manual Configuration Warning Please read the following before attempting the installation of your Series 4000 Routers: • The antenna design, alignment and placement are all critical to the successful operation of wireless networks. In the majority of cases, the network manager needs the assistance of antenna specialists to perform these tasks. -
Page 9: Table Of Contents
Contents Regulatory Information ..........iii Readers’... - Page 10 Index: Index-1 Series 4000 Router Installation Guide...
-
Page 11: Chapter 1: Installation
Installation The following sections provide section-by-section, step-by-step instructions on how to get your Series 4000 Router up and running. Do not skip any sections or steps. The first section begins with instructions after you have received the equipment and are ready to begin installation: Location of Ports and Connectors Required Computer Equipment and Software... -
Page 12: Required Computer Equipment And Software
Chapter--Installation Topic--Required Computer Equipment and Software Figure 1-1 Back Panel of the Series 4000 Router WARNING: Before you apply power to the AirTegrity Router, be USB and RS232 ports are sure that the antenna (or a 50 ohm part of the front panel. dummy load) is attached to the RF connector(s). -
Page 13: Install The Ethernet Cabling
Chapter--Installation Topic--Install the Ethernet Cabling – Terminal Emulation Program (for example, Hyperterminal or Vicomsoft) is recommended to allow you to access the AOS CLI commands and other CLI administrative interfaces of the Series 4000 Router. The WebUI provides all the functionality of AOS CLI with the exception of the unit’s BIOS options. - Page 14 Chapter--Installation Topic--Settings - Control Panel • Web browser • Ethernet cables with the proper connectors • Two free Ethernet ports that connect to your LAN - one for the Router and one for your PC. Complete the following steps: Connect your PC to your Ethernet LAN. Connect the Series 4000 Router to your Ethernet LAN.
-
Page 15: Connecting To The Series 4000 Router Through The Rs232 Serial Console
Continue with the AOS CLI and WebUI Reference Guide and the AirTegrity Wireless Router Application Guide (included in the User Documentation CD) for configuration instructions. Connecting to the Series 4000 Router through the RS232 Serial Console Use a DB9 =>... - Page 16 Chapter--Installation Topic--Installation Caution - READ THIS SECTION • As a wireless product requiring antenna installation, the antenna alignment is critical to operation of the unit. An unqualified or inexperienced person would not be able to perform antenna alignment. For example, they would need to know the exact location of the Base Station when installing a CPE device and they would experience in estimating the effect of obstructions, distance and weather.
-
Page 17: Chapter 2: Hardware Features
Hardware Features The Series 4000 Router product is multi-protocol router supporting both wireless and wired interfaces. The Router is available in a variety of models and optional plug-in modules. Some models and plug-in configurations might not support all the features and hardware options described in this manual. -
Page 18: Understanding Radio Frequency Transmission Power Values
Understanding Radio Frequency Transmission Power Values The goal of this appendix is to familiarize the reader with basic technology concepts and terms involved in wireless communications specific to AirTegrity products. The topics to be covered include • Additive and subtractive effect by system components on the overall system. •... - Page 19 Appendix--Understanding Radio Frequency Transmission Power Values Topic--decibel For example: Power (in dB) = 10 * log10 (Signal/Reference) Where: • Signal is the power of the signal from the RF transmitter • (for example 50 mW) • Reference is the reference power •...
- Page 20 Appendix--Understanding Radio Frequency Transmission Power Values Topic--decibel Table A-2 Approximate dBm to mW conversion values Approximate dBm Antenna Approximate mW transmit power at the RF interface as gain presented to the coaxial cable or antenna if directly attached 3dBm 2.0mW 4dBm 2.5mW 5dBm...
-
Page 21: Estimating Cable Loss
Appendix--Understanding Radio Frequency Transmission Power Values Topic--Estimating Cable Loss The table above clearly shows the logarithmic effect of the increase of dBm against the respective mW power. For example: If 0dB = 1mW, then 14dB = 25mW. If 0dB = 1mW, then 10dB = 10mW, and 20dB = 100mW. Subtract 3dB from 100 mw to drop the power by half (17dB = 50mW), then subtract 3dB again to drop the power by 50% yet again (14dB = 25mW.) Note... -
Page 22: Gain
Appendix--Understanding Radio Frequency Transmission Power Values Topic--sectoral The primary classes of antenna are based on their three-dimensional radiation patterns: sectoral, omni-directional and directional. In addition, there are some 24 specific physical types antennas grouped into 6 categories. (Detailed descriptions of the physical types or categories is beyond the scope of this document.) For reference the 6 categories are: •... -
Page 23: Effective Isotropic Radiated Power
Appendix--Understanding Radio Frequency Transmission Power Values Topic--Effective Isotropic Radiated Power Effective Isotropic Radiated Power The radiated (transmitted) power is rated in either dBm or watts. Power coming off an antenna is measured as Effective Isotropic Radiated Power (EIRP). EIRP is the value that regulatory agencies such as the FCC or European Telecommunications Standards Institute (ETSI) use to determine and measure power limits in applications such as 2.4 GHz wireless equipment. -
Page 24: Outdoor And Indoor Propagation And Range
Appendix--Understanding Radio Frequency Transmission Power Values Topic--Receiver sensitivity Table A-4 Receiver Sensitivity -30 dBm 0.0001 mW -40 dBm 0.00001 mW -50 dBm 0.000001 mW -60 dBm 0.0000001 mW -70 dBm 0.00000001 mW Outdoor and Indoor Propagation and Range The following guidelines show the approximate effects of range and other factors on wireless propagation outdoors and indoors. -
Page 25: Maximum Power Levels And Permitted Channels In Regulatory Domains
Maximum Power Levels and Permitted Channels in Regulatory Domains This appendix contains the maximum power levels and radio channels permitted by various regulatory domains. Specifications for IEEE 802.11a and IEEE 802.11b systems are presented. Links to the table in this appendix follow: •... -
Page 26: Maximum Power
Appendix--Maximum Power Levels and Permitted Channels in Regulatory Domains Topic--Maximum Power The following table shows the maximum power levels and antenna gains allowed for each IEEE 802.11b regulatory domain. The maximum power level is specified in equivalent isotropic radiated power (EIRP). An improper combination of power level and antenna gain can result in EIRP above the amount allowed per regulatory domain. -
Page 27: Channels
Appendix--Maximum Power Levels and Permitted Channels in Regulatory Domains Topic--Channels Table B-2 Maximum Power Levels Per Antenna Gain for IEEE 802.11b Regulatory Domain Antenna Gain (dBi) Maximum Power Level (mW) China (10 mW EIRP maximum) 13.5 Japan (10 mW/MHz EIRP maximum) 13.5 Channels This section contains lists the permitted radio channels for each regulatory domain. - Page 28 Appendix--Maximum Power Levels and Permitted Channels in Regulatory Domains Topic--Channels Table B-3 IEEE 802.11a Channels Channel Frequency Regulatory Domains (MHz) US, Canada, Japan Singapore Taiwan Central and South America 5210 5220 5230 5240 5260 5280 5300 5320 5745 5765 5785 5805 The channel identifiers, channel center frequencies, and regulatory domains of each IEEE 802.11b 22-MHz-wide channel are listed below.
- Page 29 Appendix--Maximum Power Levels and Permitted Channels in Regulatory Domains Topic--Channels Table B-4 IEEE 802.11b Channels Channel ID Frequency Regulatory Domains (MHz) US, Canada, EMEA Israel China Japan Central and South America 2457 2462 2467 2472 2484 In Mexico, channels 1 through 8 are for indoor use only. Channels 9 through 11 can be used Note indoors and outdoors.
- Page 30 Receiver Sensitivity defined defined Regulatory Domains maximum EIRP maximum power decibel permitted channels defined Required Equipment and Software decibels dipole Connecting the Router via Ethernet decibels isotropic Router Model dipole antenna AirRunner 4000 Series Installation Guide Index-1...
- Page 31 Index Serial number System Hardware Description Wireless propagation and range Wireless Systems Path Loss Calculator Index-2 Series 4000 Router Installation Guide...
