C-motech CDM-650PRO Manual

Wireless cdma docking station, fae
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FAE Manual
Page 1 of 62
CDM-650PRO FAE manual
Wireless CDMA Docking Station
INEW Digital Company
Technical Support:
jglee@inewdc.com
TEL: 82-42-933-7328
FAX: 82-42-934-4829
www.inewdc.com
Connect your network on wireless Internet easily

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDM-650PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for C-motech CDM-650PRO

  • Page 1 FAE Manual Page 1 of 62 CDM-650PRO FAE manual Wireless CDMA Docking Station INEW Digital Company Technical Support: jglee@inewdc.com TEL: 82-42-933-7328 FAX: 82-42-934-4829 www.inewdc.com Connect your network on wireless Internet easily...
  • Page 2 Regulatory Information & Safety notices 1. Regulatory Notices This device is compliant with Parts 15, 22 and 24 of the FCC Rules. Operation of this device is subject to the following two conditions: 1. This device may not cause harmful interference, and 2.
  • Page 3 Regulatory Information & Safety notices WARNING (EMI) This equipment has been tested and found to comply with the limits pursuant to Part 15, 22 & 24 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation.
  • Page 4 MUST BE POWERED OFF. It can transmit signals that could interfere with this equipment. Do not operate the CDM-650PRO in any aircraft, whether the aircraft is on the ground or in flight. In aircraft, the CDM-650PRO MUST BE POWERED OFF.
  • Page 5 Regulatory Information & Safety notices POTENTIALLY UNSAFE AREAS Posted facilities -Turn off this modem in any facility or area when posted notices require you to do so. Blasting areas - Turn off Modem where blasting is in progress. Observe restrictions and follow any regulations or rules.

  • Page 6: Table Of Contents

    FAE Manual Page 2 of 62 Copyright ....................4 Purpose ...................... 4 1. INTRODUCTION..................5 1.1 OVERVIEW ..................5 1.2 APPERANCE ..................6 1.3 MAIN FEATURE.................. 6 1.4 SPECIFICATION................. 7 1.4.1 Mechanical Specification ............. 7 1.4.2 Environment Specification ............7 1.4.3 Electrical Specification..............
  • Page 7 FAE Manual Page 3 of 62 2.4.1 PPP auto mode................ 19 2.4.2 Bridge mode................20 2.5 SETTING HOST PC ................21 2.5.1 Setting Host PC’s network environment ........21 2.6 WEB-BASED CONFIGURATION PAGE ..........23 2.6.1 Overview ................23 2.6.2 Web-based configuration page description ........24 3.

  • Page 8: Copyright

    Copyright FAE manual describes features including hardware, software and operation of CDM- 650PRO. C-motech has made best effort to ensure that the information contained in this document is accurate and reliable. This document is the property of C-motech and implies no license under patents, copyrights, trade secrets. No part of this...

  • Page 9: Introduction

    CDM-650PRO has some special function on wireless mobile network like always on-line, demands on-line etc. CDM-650PRO has various input voltage range that can support it from 6~30 [VDC] which provides compatibility for platforms utilizing various industry applications.

  • Page 10: Apperance

    FAE Manual Page 6 of 62 1.2 APPERANCE Below are the appearance and the each part of name of CDM-650PRO. [Picture1. Each part name of CDM-650PRO] 1.3 MAIN FEATURE Wireless Internet/Network External wireless mobile 1X EV-DO DUAL-BAND modem adaptable A 10/100Mbps Ethernet Port...

  • Page 11: Specification

    Under 350 [mA] @ 12 [VDC] Ior = -104 [dBm] Under 550 [mA] @ 12 [VDC] [Table3. Electrical specification] 1.4.4 Hardware specification Item Description Product Name CDM-650PRO User MCU 32-bit Network Processor Program Memory 4M Bytes (Flash) Data Memory 16M Bytes (SDRAM) Wireless Interface USB 1.1 Host interface...

  • Page 12: Software Specification

    FAE Manual Page 8 of 62 1.4.5 Software Specification Item Description Boot loader for CDM-650PRO Boot loader Flash erase/write for storing image Built-in commands Kernel Linux Kernel v2.4.28 PPP/PPPoE for wireless mobile network - RFC 1631 - Up to 253 users...

  • Page 13: Protocol Information

    FAE Manual Page 9 of 62 1.5 PROTOCOL INFORMATION 1.5.1 PPP (Point-to-Point Protocol) PPP (Point-to-Point Protocol) is a protocol for communication between two computers using a serial interface, typically a personal computer connected by phone line to a server. For example, your Internet server provider may provide you with a PPP connection so that the provider's server can respond to your requests, pass them on to the Internet, and forward your requested Internet responses back to you.

  • Page 14: Dhcp (Dynamic Host Configuration Protocol)

    FAE Manual Page 10 of 62 PPPoE has the advantage that neither the telephone company nor the Internet service provider (ISP) needs to provide any special support. Unlike dialup connections, DSL and cable modem connections are "always on." Since a number of different users are sharing the same physical connection to the remote service provider, a way is needed to keep track of which user traffic should go to and which user should be billed.

  • Page 15: Nat (Network Address Translation Or Network Address Translator)

    FAE Manual Page 11 of 62 DHCP is an extension of an earlier network IP management protocol, Bootstrap Protocol (BOOTP). DHCP is a more advanced protocol, but both configuration management protocols are commonly used and DHCP can handle BOOTP client requests. Some organizations use both protocols, but understanding how and when to use them in the same organization is important.

  • Page 16: Rip V1/V2 (Routing Information Protocol)

    FAE Manual Page 12 of 62 - A global IP address to any of a pool of local IP addresses on a round- robin basis NAT is described in general terms in RFC 1631, which discusses NAT's relationship to Classless Inter-domain Routing (CIDR) as a way to reduce the IP address depletion problem.

  • Page 17: Sntp (Simple Network Time Protocol)

    FAE Manual Page 13 of 62 Simple Network Management Protocol (SNMP) is the protocol governing network management and the monitoring of network devices and their functions. It is not necessarily limited to TCP/IP networks. 1.5.7 SNTP (Simple Network Time Protocol) Simple Network Time Protocol (SNTP) is a protocol that is used to synchronize computer clock times in a network of computers.

  • Page 18: Icmp (Internet Control Message Protocol)

    FAE Manual Page 14 of 62 user as an SNTP client, SNTP server, or both. In basic terms, the SNTP client initiates a time request exchange with the time server. As a result of this exchange, the client is able to calculate the link delay, its local offset, and adjust its local clock to match the clock at the server's computer.

  • Page 19: Basic Information

    (These images will be updated) Note. 1. CDM-650PRO : Wireless 1X EV-DO DUAL-BAND Docking Station 2. UTP Cable: Connecting cable between Host PC and CDM-650PRO. 3. 12 [VDC] Adapter: Supply + 12 [VDC] power. Connect your network on wireless Internet easily...

  • Page 20: Software Composition

    2.2 SOFTWARE COMPOSITION All software for CDM-650PRO is composed below. 2.2.1 Web-based configuration page CDM-650PRO has a web-based configuration page that user can set the function of CDM-650PRO for user’s purpose. 2.2.2 Firmware Firmware is the program operating the CDM-650PRO.

  • Page 21: Description Of Each Part

    FAE Manual Page 17 of 62 2.3 DESCRIPTION OF EACH PART 2.3.1 3-Status LED CDM-650PRO has 3-State LED for indicating the current state. [Picture2. Front of CDM-650PRO] Display Description Indicate the main power on. Indicate the wireless modem re-booting. POWER Blinking Be keep going is the external modem is empty.

  • Page 22: Mini-Dc Power

    User can supply the power range from + 6 to + 30 [VDC] 2.3.3 Ethernet Port User can connect CDM-650PRO with Host PC, HUB, Router etc, via 10/100 Ethernet port. The RJ-45 connector (Ethernet port) has two Link-LED. Below the table 9 shows the each state of LAN connection.

  • Page 23: Operation Mode

    User can choose this mode of CDM-650PRO for their purpose. 2.4.1 PPP auto mode On PPP auto mode, CDM-650PRO has the IP from ISP (Internet Service Provider) then CDM-650PRO keeps the IP and shares the IP with connected Host PC via NAT. Below picture shows CDM-650PRO how to operate on PPP auto mode.

  • Page 24: Bridge Mode

    FAE Manual Page 20 of 62 2.4.2 Bridge mode On Bridge mode, CDM-650PRO has no IP but the Host PC gets the IP from ISP directly through CDM-650PRO. [Picture5. Bridge mode operation] CDM-650PRO has a PPPoE Authenticator internally and this function can communicate with PPPoE client on PC or other Router.

  • Page 25: Setting Host Pc

    Page 21 of 62 2.5 SETTING HOST PC CDM-650PRO is set by PPP auto mode on factory default. So just connect an UTP cable (Ethernet cable) between PC and CDM-650PRO. Set the network environment of the host PC as automatically.
  • Page 26 FAE Manual Page 22 of 62 [Picture7. The second step of setting the Host PC] 2.5.1.3 Double click the “Internet Protocol [TCP/IP]” item. [Picture8. The third step of setting the Host PC] 2.5.1.4 Check the “Obtain an IP address automatically” then click the [OK] button.

  • Page 27: Web-Based Configuration Page

    Internet wirelessly. 2.6 WEB-BASED CONFIGURATION PAGE 2.6.1 Overview User can configure some functions of CDM-650PRO for user’s purpose by web-based configuration page in CDM-650PRO. This web-based configuration page is simplified and easy setup. Below picture shows the brief image of CDM-650PRO’s configuration.

  • Page 28: Web-Based Configuration

    Default setting is User name: admin, Password: admin. But user can change this option on System tab in the web-based configuration page. 2.6.2 Web-based configuration page description 2.6.2.1 Home tab Home tab shows the basic information about CDM-650PRO. [Picture13. Home tab page] Connect your network on wireless Internet easily...
  • Page 29 RSSI Current mode Current operation mode Information 1X EV-DO DUAL-BAND information eth0: CDM-650PRO’s private IP address Interface ppp0: Status of 1X EV-DO DUAL-BAND IP address (After getting IP from ISP, this IP will appear) Connection Connect or disconnect wireless network [Table8.
  • Page 30 650PRO’s process, getting IP etc. User can check the CDM-650PRO state via Syslog item. 2.6.2.3 Ethernet tab Ethernet tab is set by the options of a CDM-650PRO’s Ethernet port like static or DHCP, IP address, Subnet Mask, Gateway and DHCP host name.
  • Page 31 FAE Manual Page 27 of 62 ITEM Description CDM-650PRO’s IP type Connect Type - Static: Setting the IP statically(User can set a IP) - DHCP: Setting the IP dynamically (do not set this) IP address IP Address (If user select DHCP, this option will be inactive)
  • Page 32 FAE Manual Page 28 of 62 ITEM Description Setting the SNMP enable/disable Activate - Enable: Enable SNMP - Disable: Disable SNMP Setting SNMP public or private Read Community Name - Public: Reading community string available - Private: Reading community string disable Setting SNMP public or private Write Community Name - Public: Writing community string available...
  • Page 33 FAE Manual Page 29 of 62 - Enable: Generate Link up event - Disable: Not generate Link up event Link Ethernet port down event enable/disable Link Down Trap - Enable: Generate Link down event - Disable: Not generate Link down event [Table11.
  • Page 34 FAE Manual Page 30 of 62 ITEM Description Setting the SNTP enable/disable Operation - Enable: Enable SNTP - Disable: Disable SNTP SNTP Server Address IP address of SNTP server Time Zone Time stamp from GMT(Green Mean Time) [Table12. SNTP tab information] 2.6.2.6 DNS tab DNS tab is set for choosing the DNS(Domain Name Service) server.
  • Page 35 FAE Manual Page 31 of 62 ITEM Description DNS IP Setting the first DNS server IP address Address DNS IP Setting the second DNS server IP address Address [Table13. DNS tab information] Note. CHS-628PRO gets the two DNS Addresses from ISP and uses them fundamentally but if the DNS is not effective then try to connect to user DNS what they set.
  • Page 36 Default Gateway CDM-650PRO’s Ethernet gateway IP address [Table14. DHCP tab information] 2.6.2.8 MODE tab MODE tab selects method that CDM-650PRO how to connect on the internet. For more detail, refer to the chapter “2.4 Operation mode”. [Picture20. MODE tab] Connect your network on wireless Internet easily...
  • Page 37 FAE Manual Page 33 of 62 ITEM Description Selecting the connecting mode - PPP auto: PPP connection via 1X EV-DO DUAL-BAND Select Mode network - Bridge: PPPoE connection with PC. *In this case user is needed dial-up connection Internet Domain Select Domain.
  • Page 38 FAE Manual Page 34 of 62 2.6.2.9 NAT tab NAT tab is set for choosing the option of NAT (Network Address Translation) protocol. This tab is affected by PPP auto mode. [Picture21. NAT tab] ITEM Description Setting the NAT enable/disable Operation - Enable: Enable NAT - Disable: Disable NAT...
  • Page 39 FAE Manual Page 35 of 62 2.6.2.10 Router tab User can set the routing option manually. There are Zebra, RIP, OSPF option and you can see each one if you push the button. [Picture22. Router tab] ITEM Description Setting Zebra protocol. ZEBRA OP Enable: Enable Zebra Disable: Disable Zebra...
  • Page 40 FAE Manual Page 36 of 62 2.6.2.11 VRRP tab VRRP (Virtual Router Redundancy Protocol) is used for back- up network. [Picture23. VRRP tab] ITEM Description Operation Set Enable/Disable Virtual Router Master Set Master IP address Virtual Router Backup Set Backup IP address (Blank available) [Table18.
  • Page 41 FAE Manual Page 37 of 62 2.6.2.12 System tab System tab is set for setting the option of the configuration page like admin name, password etc. [Picture24. System tab] ITEM Description Admin Name Administrator ID for login Admin Password Administrator Password for login HTTP Port web-based configuration page port used Setting the Telnet server enable/disable...
  • Page 42 FAE Manual Page 38 of 62 2.6.2.13 Reboot tab Reboot tab is used for rebooting CDM-650PRO via web- based configuration page. To apply information that is selected, user should reset CDM-650PRO using the hardware reset button, power on/off or this option.
  • Page 43 FAE Manual Page 39 of 62 2.6.2.14 Upgrade tab Upgrade tap is used for upgrading CDM-650PRO’s firmware. [Picture26. Upgrade tab] * Select the new firmware. * During upgrading the new own, 3 state LED turns on and off in order then the LEDs are blinking together when it has finished.

  • Page 44: Usage

    FAE Manual Page 40 of 62 3. USAGE 3.1 OPERATION MODE CDM-650PRO operates two modes. One is PPP auto mode and the other one is Bridge mode. User can change the function of CDM-650PRO by web-based configuration page for user’s purpose.
  • Page 45 3.1.1.5 Select PPP auto then choose the Internet Domain. (If you choose “Coporate”, write “User ID” and “Password”, Tel number. Click the button. [Picture30. MODE tab] 3.1.1.6 Go to Reboot or reset CDM-650PRO. Connect your network on wireless Internet easily...

  • Page 46: Bridge Mode

    3.1.2.5 Selecting Bridge in MODE tab below window appears then click button. [Picture31. MODE Page] 3.1.2.6 All setting finished then select Reboot tab. Click the [Reboot] button or push the reset button on left side of CDM-650PRO. Connect your network on wireless Internet easily...
  • Page 47 FAE Manual Page 43 of 62 3.1.2.7 To use CDM-650PRO on the Bridge mode, should establish the PPPoE connection. In this example, we assumed that user uses the Windows XP. For connect between PC and CDM- 650PRO, click the right button of mouse on the “My Network Places”...
  • Page 48 FAE Manual Page 44 of 62 3.1.2.9 The New Connection Wizard appears then click [Next] button. [Picture34. Second step of creating a PPPoE dialer connection] 3.1.2.10 Check the “Connect to the Internet” item, then click [Next] button. [Picture35. Third step of creating a PPPoE dialer connection] Connect your network on wireless Internet easily...
  • Page 49 FAE Manual Page 45 of 62 3.1.2.11 Check the “Set up my connection manually” then click [Next] button. [Picture36. Forth step of creating a PPPoE dialer connection] 3.1.2.12 Check the “Connect using a broadband connection that requires a user name and password” item then click [Next] button.
  • Page 50 FAE Manual Page 46 of 62 3.1.2.13 Write the ISP Name what you want then click [Next] button. [Picture38. Sixth step of creating a PPPoE dialer connection] 3.1.2.14 Write User name/Password/Confirm password what you use. Then click [Next] button. [Picture39. Sixth step of creating a PPPoE dialer connection] Connect your network on wireless Internet easily...
  • Page 51 FAE Manual Page 47 of 62 3.1.2.15 All setting is finished correctly, check “Add a shortcut to connection and close this wizard, click Finish” then click [Finish] button. [Picture40. Seventh step of creating a PPPoE dialer connection] 3.1.2.16 Click the PPPoE shortcut icon on my desktop, then PPPoE dialer connection program appears then click [Connect] button.
  • Page 52 3.1.2.17 Connecting window appears, trying to connect CDM-650PRO on Internet. [Picture42. Connecting between PC and CDM-650PRO] 3.1.2.18 After the connection between PC and CDM-650PRO is established, then go to the verifying stage. [Picture43. Verifying username and password] 3.1.2.19 On the Registering stage the Host PC is connecting on the network.

  • Page 53: Advanced Setting

    FAE Manual Page 49 of 62 3.2 ADVANCED SETTING User can connect CDM-650PRO with other network device. User can change the function of CDM-650PRO by web-based configuration page for user’s purpose. 3.2.1 Connecting with HUB When user want to connect CDM-650PRO with HUB, select the CDM- 650PRO mode PPP auto mode.

  • Page 54: Setting Virtual Server

    Virtual server that is port forwarding can be used to set up public the local server connecting outside network. When remote users send requests for accessing the local server, CDM-650PRO can forward those requests to the appropriate server to handle the requests.
  • Page 55 FAE Manual Page 51 of 62 Picture47. Setting virtual server of WEB server] 3.2.2.6 The WEB server is established. Picture48. Set by virtual server of WEB server] 3.2.2.7 Select the Redirect IP Address: 192.168.0.11, Protocol: TCP, Port Range: 21 => 21, then click button.
  • Page 56 Picture50. Set by virtual server of FTP server] 3.2.2.9 All setting finished then select Reboot tab. Click the [Reboot] button or push the reset button on left side of CDM-650PRO. Note. To operate virtual server function, should set CHS-628PRO mode as PPP auto mode and Bridge mode does not support this function.

  • Page 57: Setting Dmz Host

    DMZ Host function make connected network device like a computer including all port service be seen by remote computer. Picture51. CDM-650PRO connected with a server and a PC via DMZ Host] 3.2.3.1 Connect Power cable on CDM-650PRO. 3.2.3.2 Execute Internet Explore then connect “192.168.0.1”, web- based configuration page.
  • Page 58 3.2.3.7 Select Operation item: Enable, DMZ Host IP: 192.168.0.10, then click button. Picture52. Setting DMZ Host server] 3.2.3.8 All setting finished then select Reboot tab. Click the [Reboot] button or push the reset button on left side of CDM-650PRO. Connect your network on wireless Internet easily...

  • Page 59: Connecting With Xdsl, Vpn, Router Via Pppoe

    There may be needed to connect with network device like xDSL modem, VPN, PC supported by PPPoE. User should select CDM-650PRO as Bridge mode. Picture53. CDM-650PRO connected with xDSL, VPN, PC by PPPoE] Note. PPPoE connection supports the only 1:1 direct connection.

  • Page 60: Troubleshooting

    4.1.3.2 Please check whether the UTP cable is connected at both ends. 4.1.3.3 Please check the PC’s LAN card. 4.1.3.4 If you connect cross HUB with CDM-650PRO, use the cross UTP cable. 4.1.3.5 Please check whether the UTP cable is correctly or not.

  • Page 61: Checking Software

    FAE Manual Page 57 of 62 4.1.6 Console data does not appear on hyper terminal. 4.1.6.1 Please check the connection between PC and CDM-650PRO correctly. 4.1.6.2 Please check the 24 to 24 pin cable correctly. 4.1.6.3 Please check whether the serial cable is cross or not. The cross cable is correct.
  • Page 62 4.2.3.3 Please check that the Host PC’s network environment is set by dynamically. 4.2.4 I need to set up a server connecting with CDM-650PRO. 4.2.4.1 To use a server like a web, ftp, or mail server, you need to know the respective port numbers they are using. For example, port 80 (HTTP) is used for web;...
  • Page 63 FAE Manual Page 59 of 62 Telnet 23 to 23 53 to 53 Gopher 70 to 70 POP3 [Table20. Example of the Port Forwarding per application] 4.2.4.2 These online game hosting service other applications. Application Start and End Protocol 7777 to 27900 Halflife 27015 to 27015 PC Anyware...

  • Page 64: Faq

    5.2 Does the CDM-650PRO support IPX or Apple Talk? No, The CDM-650PRO does not support IPX and Apple Talk. But if the CDM-650PRO is set by Bridge mode and ISP supports IPX or Apple talk, passing through with those protocols may be possible.
  • Page 65 650PRO. 5.9 How many ports can be simultaneously forwarded? In theory, CDM-650PRO can establish 4,000 sessions at the save time, but you can only forward 25 range of ports. 5.10 Where can I get a static or Dynamic IP address? Public IP is from ISP and Private IP is from DHCP in CDM-650PRO.
  • Page 66 FAE Manual Page 62 of 62 (All document finished) If your questions are not here, contact us www.cmotech.com Thank you. Connect your network on wireless Internet easily...
