FLEXNET
BARB CONNECTOR
ASSEMBLY INSTRUCTIONS
Connecting a barb connector. Size 2"; 3"; 4"
1. Strictly ensure the pipe is cut perfectly straight during the cutting operation (Fig. 1).
When reconnecting a pipe to the connector, cut at least 1.5 cm (5/8") off the pipe end.
2. Insert the metal clamp onto the pipe (Fig. 2).
Fig. 1
3. Make sure that the pipe inside surface is wet, so it will not stick to the rubber seal in the connector, and
move it from it's groove.
4. Make sure that the pipe is inserted all the way to the connector's shoulder (Fig. 3a).
5. Make sure there is no gap between the metal clamp and the connector's shoulder (Fig. 3, 3a and 3b).
Fig. 3
AND FLEXNET
™
FLEXNET BARB CONNECTOR ASSEMBLY INSTRUCTIONS 1
Fig. 2
No gap
Fig. 3a
HP
™
Gap
Fig. 3b
Advertisement
Table of Contents
Summary of Contents for Netafim FLEXNET
- Page 1 4. Make sure that the pipe is inserted all the way to the connector’s shoulder (Fig. 3a). 5. Make sure there is no gap between the metal clamp and the connector’s shoulder (Fig. 3, 3a and 3b). No gap Fig. 3 Fig. 3a Fig. 3b FLEXNET BARB CONNECTOR ASSEMBLY INSTRUCTIONS 1...
- Page 2 Fig. 7 Fig. 8 Fig. 9 Connecting a PVC cement adaptor Glue the adaptor according to the PVC cement manufacturer's instructions. Netafim™ recommends using a cleaning primer to ensure proper welding. Sizes of PVC adaptors: 2“ ISO 63/50, ASTM 2”/1.5”...
- Page 3 3. Connect the relevant accessory (apply Teflon tape) (Fig. 15). If needed, retighten under water pressure. Fig. 13 Fig. 14 Fig. 15 Other Possible uses: Netafim Tapping kits: Cat No. 45000-003162 and 45000-003185. Branching connector Air vent. FLEXNET BARB CONNECTOR ASSEMBLY INSTRUCTIONS 3...
- Page 4 5. Make sure that the metal clamp is exactly above the rubber seal (Fig. 4). Fig. 3 Fig. 4 Fig. 5 6. Tighten forcefully (Fig. 8). No gap Fig. 6 Fig. 7 Fig. 8 FLEXNET BARB CONNECTOR ASSEMBLY INSTRUCTIONS 4...
- Page 5 ISO 1452: 160 mm; 200 mm; 250 mm; 315 mm. Connecting a PVC cement adaptor Glue the adaptor according to the PVC cement manufacturer's instructions (Fig. 9 and 10). Netafim™ recommends using a cleaning primer to ensure proper welding. Fig. 9 Fig. 10...
- Page 6 5. Make sure that one metal clamp is exactly above the rubber seal and the other exactly above the ribbed rim (Fig. 4). Fig. 3 Fig. 4 Fig. 5 6. Tighten both metal clamps forcefully (Fig. 7 and 8). Fig. 6 Fig. 7 Fig. 8 FLEXNET BARB CONNECTOR ASSEMBLY INSTRUCTIONS 6...
- Page 7 ISO 1452: 160 mm; 200 mm. Connecting a PVC cement adaptor Glue the adaptor according to the PVC cement manufacturer's instructions (Fig. 9 and 10). Netafim™ recommends using a cleaning primer to ensure proper welding. Fig. 9 Fig. 10 Coupling options...
