Summary of Contents for Vyyo Inc. V290iA
- Page 1 V290iA User Guide Version 1.0...
- Page 2 Copyright and Compliance Copyright Information Copyright © 2006 Vyyo Inc. All rights reserved. Vyyo reserves the right to alter all equipment specifications and descriptions in this publication without prior notice. No part of this publication shall be deemed part of any contract or warranty unless specifically incorporated by reference into such contract or warranty.
- Page 3 FCC Compliance Information NOTE: This equipment is authorized under FCC ID PBJ290-IA to operate in the A block of the Upper 700 MHz Guard Band pursuant to Part 27 of the FCC’s rules. In addition, this equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC’s rules.
-
Page 5: Table Of Contents
How This Guide is Organized ................2 Related Documentation ..................3 Obtaining Documentation ..................3 Documentation Feedback ..................3 List of Abbreviations...................4 Chapter 1 Overview ....................7 V290iA and the Vyyo BWA System ..............7 Chapter 2 Physical and Functional Description..........9 V290iA Basic Description...................9 Interfaces ......................10 Housing......................11 Heating and Cooling ..................11 Power.......................12... - Page 6 Cable Connections...................18 Initial Operation....................19 Chapter 4 Configuring the V290iA ..............21 Configuring V290iA Components..............21 Configuring the Cisco Router ..............22 V290iA Cisco 3200 Default Configuration ...........22 SCADA Traffic Configuration...............23 Chapter 5 Maintenance ..................29 Interface Panel LEDs ..................29 WiFi LEDs Operation...................30 Upgrading Software ..................31 Upgrading the V284 Software ..............31...
- Page 7 Chapter 0 Overview Appendix F Ethernet Cable Specifications ............49 Ethernet (AUI) Port Pinout (DB−15)..............49 Ethernet Version 2 and IEEE 802.3 Physical Characteristics......50 Ethernet Coaxial−type Connection Limits for 10−Mbps Transmission ....50 Appendix G FCC Declaration of Conformity .............51 V290iA User Guide...
-
Page 9: About This Guide
About This Guide The V290iA User Guide is part of the documentation package for the Vyyo wireless access system. The guide describes the V290iA device, and how to install, configure and maintain the V290iA. For instructions on installing the antenna, refer to the appropriate guide. An antenna must be installed by a professional following all safety precautions. -
Page 10: How This Guide Is Organized
This guide is organized into the following chapters and appendices: Chapter 1: Overview This chapter provides an overview of the V290iA and the Vyyo wireless access system. Chapter 2: Physical and Functional Description This chapter includes a physical and functional description of the V290iA and its components, as well as an overview of the process of modem initialization. -
Page 11: Related Documentation
Related Documentation For information on other Vyyo wireless system topics, see the following guides: NMS User Guide Base Station User Guide V290iA Quick Reference Guide Obtaining Documentation To obtain additional documentation, please contact info@vyyo.com. Documentation Feedback We welcome your comments about this guide. Please send comments to: Address: 6625 The Corners Parkway, Suite 210, Norcross, GA 30092 Tel: 678.282.8000... -
Page 12: List Of Abbreviations
Internet Control Message Protocol IEEE Institute of Electrical and Electronic Engineers IETF Internet Engineering Task Force IGMP Internet Group Management Protocol Internet Protocol International Standards Organization International Telecommunications Union ITU-T Telecommunication Standardization Sector of the International Telecommunication Union V290iA User Guide... - Page 13 Physical Layer Point-to-Point Protocol Quadrature Amplitude Modulation Quality of Service QPSK Quadrature Phase-Shift Keying Radio Frequency Request For Comments SNAP Subnetwork Access Protocol SNMP Simple Network Management Protocol Signal-to-Noise Ratio Transmission Control Protocol TFTP Trivial File-Transfer Protocol Upstream V290iA User Guide...
-
Page 15: Chapter 1 Overview
Overview The V290iA is a Customer Premises Equipment (CPE) device used to provide wireless communications at remote locations as part of a Vyyo wireless network. The V290iA provides remote connectivity for SCADA and IP devices. The V290iA consists of three major components, integrated into a single chassis: A Vyyo wireless modem, used for communicating over the Vyyo wireless network. -
Page 17: Chapter 2 Physical And Functional Description
Physical and Functional Description The V290iA is comprised of a Vyyo V284 RF modem and a Cisco 3200-series router, integrated into a single housing. This housing is designed for easy mounting on a wall or pole in the remote location. -
Page 18: Interfaces
Figure 3: Vyyo V290iA bottom view Interfaces The following interfaces are available in the V290iA: Six DB-9 serial ports – Four serial ports are available to connect serial devices such as SCADA devices. Two ports serve as console ports: one for the Cisco router (MARC), and one for the Power and Control Card. -
Page 19: Housing
The Ethernet and Serial interfaces use a rugged design to protect the interface pins. The interface panel is located on the bottom of the V290iA when it is mounted in the standard way, and the RF antenna connection is on the top. -
Page 20: Power
2 Physical and Functional Description Power The V290iA supports an input voltage of 48VDC (36-72 VDC), with 5A input current protection. The V290iA has a manageable Power and Control Card, providing power to the different units, such as the Cisco cards, the V284+A card, and the temperature... - Page 21 (IP address, subnet mask and more) from the DHCP server. Note: The description of how the Cisco router establishes IP connectivity, applies to the V290iA default Cisco setting. The customer may change the Cisco setting to a fixed IP address, or any other IP addressing method supported by the Cisco IOS.
-
Page 23: Chapter 3 Installing The V290Ia
Installing the V290iA The V290iA is designed to be installed on a wall, pole, or shelf. This section describes all the steps required for installation. For instructions on installing the antenna, refer to the appropriate guide. An antenna must be installed by a professional following all safety precautions. -
Page 24: Verifying Package Contents
Four SST LOCK 1/4 washers. Four SST LOCK 3/8 washers. Mounting the V290iA The V290iA can be mounted on a wall, a pole, or a shelf. In wall mounting, the interface panel faces down, and the main mounting bracket faces to the rear. -
Page 25: Wall Mounting
Chapter 3 Installing the V290iA Wall Mounting To mount the V290iA on a wall: 1. Orient the device so that the main mounting bracket (refer to Figure 3) faces the wall and the interface panel faces down. 2. Attach the device to the wall using the enclosed mounting screws. -
Page 26: Shelf Mounting
Perform the following cable connections (refer to Figure 6): 1. Connect the Flat Panel or Yagi antenna to the V290iA UHF connector. 2. Optionally connect the WiFi antenna to the V290iA’s WiFi connector, located on the top of the V290iA chassis. -
Page 27: Initial Operation
Connect the Power cable. Initial Operation The V290iA starts operating as soon as power is connected. If you turned off the external power switch prior to connecting the power cable, turn it ON. The front panel LEDs behave as described in Interface Panel LEDs on page 29. If the behavior of the LEDs deviates from standard, refer to Troubleshooting on page 33. -
Page 29: Chapter 4 Configuring The V290Ia
Configuring the V290iA The V290iA comes with a standard configuration on delivery, and requires minimal, if any, additional configuration to operate normally. The V290iA uses the embedded Cisco 3200-series router to enable IP routing and bridging functionality, and can be configured to provide additional services beyond those provided by the standard configuration. -
Page 30: Configuring The Cisco Router
MARC IP address via the FESMIC LAN interface is 10.0.0.30 WMIC IP address is 10.0.0.1 Default Configuration CLI Commands The following displays the V290iA Cisco 3200 default values’ running configuration. service timestamps debug datetime msec interface Serial1/3 service timestamps log datetime msec... -
Page 31: Scada Traffic Configuration
Router# SCADA Traffic Configuration The V290iA optionally interfaces with asynchronous SCADA devices via serial ports Ser0 – Ser3. This section illustrates how to transmit SCADA traffic using TCP encapsulation over Telnet tunneling. Telnet Tunneling Telnet Tunneling protocol uses the TCP protocol to deliver raw data between serial ports. - Page 32 4 Configuring the V290iA Telnet caller and the SCADA device is the called. Once the caller receives serial data, it initiates a permanent TCP connection. Telnet Tunneling Configuration This configuration uses the following network setup. Figure 7: SCADA Traffic Tunneling Caller Side Configuration The following displays the caller-side configuration.
- Page 33 Chapter 4 Configuring the V290iA no motd-banner interface Serial1/1 no exec-banner physical-layer async exec-timeout 0 0 no ip address session-timeout 0 0 no flush-at-activation no vacant-message interface Serial1/2 physical-layer async no modem inout no ip address autocommand telnet SER1 /stream...
- Page 34 4 Configuring the V290iA autocommand telnet SER3 /stream no vacant-message no activation-character no modem inout special-character-bits 8 autocommand telnet SER4 /stream escape-character NONE no activation-character autohangup special-character-bits 8 stopbits 1 escape-character NONE exec autohangup no autobaud stopbits 1 speed 9600...
- Page 35 Chapter 4 Configuring the V290iA interface Serial1/2 physical-layer async no cdp run no ip address interface Serial1/3 control-plane physical-layer async no ip address line con 0 interface FastEthernet2/0 stopbits 1 line 1 4 interface FastEthernet2/1 no exec-banner no vacant-message interface FastEthernet2/2...
-
Page 37: Chapter 5 Maintenance
Maintenance The V290iA is designed for high reliability and requires only limited maintenance. This chapter describes the behavior of the V290iA LEDs during normal operation. In the event of device functionality issues, refer to Troubleshooting on page 33. Interface Panel LEDs The following figure shows the LEDs on the V290iA’s interface panel. -
Page 38: Wifi Leds Operation
Blinks green when packets are transmitted or received. Ethernet port) WiFi LEDs Operation As shown in Figure 8, the V290iA front panel includes three WiFi LEDs: Ethernet (E), Status (S), and Radio (RF). These LEDs are used in combination to determine overall V290iA device status. -
Page 39: Upgrading Software
Upgrading the V284 Software To upgrade the V284: 1. Ensure that the latest release of the V290iA software is loaded on a laptop which is running a TFTF server (pumpkin). 2. Make sure the TFTP server (pumpkin) is activated, and set to permit access to the directory in which the software package is located. -
Page 41: Chapter 6 Troubleshooting
Troubleshooting {?TBD} V290iA User Guide... -
Page 43: Appendix A V290Ia Technical Specifications
V290iA Technical Specifications This appendix lists the V290iA technical specifications. When installing the V290iA, you must ensure that the physical environment and RF configuration meet these requirements. For example, the pole must be able to support the device’s weight, and the antenna must be compatible with the listed frequency ranges. -
Page 44: Uhf Radio Characteristics
A V290iA Technical Specifications UHF Radio Characteristics Parameter Specification Downstream Frequency 746-747 MHz Channel bandwidth 330 KHz Modulations 64QAM 16QAM QPSK SNR for BER < 10E6 24 dB 19 dB 13 dB Minimum signal level -87 dBm Maximal signal level... -
Page 45: Appendix B Antennas Technical Specifications
Radiator Feed Sucoform 141 Antenna Base Sandcast Aluminium Alloy Grade LM25 Radome Fire retardant Polyurethane Moulding Fasteners Stainless Steel Grade A2-70 Lightning protection Direct Grounded Mounting Brackets Hot Dip Galvanized Steel to suit 38 - 60mm. dia. V290iA User Guide... -
Page 46: Mounting Options
Operational Temperature Range -50ºC to +80ºC Mounting Options Error! Not a valid link. Figure 9: Mounting for Vertical Polarization of the Yagi Antenna Error! Not a valid link. Figure 10: Mounting for Horizontal Polarization of the Yagi Antenna V290iA User Guide... -
Page 47: Flat Panel Subscriber Antenna
DC Grounded Mechanical Dimensions (L x W x D) 450 x 450 x 30 mm (max) Weight 3 Kg (max) Connector N type Female Radome Plastic Base plate Aluminum with chemical conversion coating Outline drawing Mounting Kit V290iA User Guide... -
Page 48: Flat Panel - Environmental Specifications
– Ice and Snow – – – 25 mm Radial Wind Speed Survival – – – 220 Km/h Operation 160 Km/h Wind Load (Survival): – Front Thrust – – 39.6 kg Side Thrust – – 4.3 kg V290iA User Guide... -
Page 49: Appendix C Power Cable Specifications
This appendix lists the technical specifications of the power cable. Power Connector Requirements The following items are required for the V290iA power inlet matching connector: Cable – CABLE SHIELDED 4 X 22AWG Plug sealed – Manufactured by Tyco, MFG: 796094-2. -
Page 50: Internal Connectors Description
Pin8 = RTS out V290i Connector Item Pin Number Name Description Pin1 = RxPO Pin2 = RxNO FE0X to Connector RJ45 Pin3 = TxPO FE2X Female Pin4 & 5 = TxC Pin6 = TxNO Pin7 & 8= RxC V290iA User Guide... - Page 51 Pin Number Name Description Connector N- Type female 50 Standard antenna V290i Connector Item Pin Number Name Description Pin1 = Negative Circular plastic Pin2 = Positive connector 4 Input Pin3 = Negative pins male Pin4 = Positive V290iA User Guide...
-
Page 53: Appendix D Uhf Antenna Cable Specifications
UHF Antenna Cable Specifications This appendix lists the technical specifications of the antenna cable. {?TBD} V290iA User Guide... -
Page 55: Appendix E Serial Cable Specifications
The table below gives the EIA/TIA−232 speed and distance limitations. Data Rate (Baud) Distance (Feet) Distance (Meters) 2400 4800 9600 19200 38400 57600 115200 V290iA User Guide... -
Page 57: Appendix F Ethernet Cable Specifications
Data In Circuit Shield CI−A Control In Circuit A CI−B Control In Circuit B CI−S Control In Circuit Shield Voltage Common Voltage Plus Voltage Shield (L25 and M25) Shell Protective Ground Any pin not referenced is not connected. V290iA User Guide... -
Page 58: Ethernet Version 2 And Ieee 802.3 Physical Characteristics
Maximum segment 500 m (1640ft.) 152 m (500ft.) length Maximum network 2500 m (8200ft.) 762 m (2500ft.) length (with four repeaters) Maximum connections (taps per segment) Minimum 2.5 m (8.2 ft.) 0.5 m (1.64ft.) connection (tap) spacing V290iA User Guide... -
Page 59: Appendix G Fcc Declaration Of Conformity
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Drawn up at: On May 8, 2006 VYYO Inc 4015 Miranda Avenue Palo Alto, Ca. VYYO Inc. Dr. Mike Ritter VP. Marketing V290iA User Guide...
