Norstone Safeline Installation Manual

A x1 B x2 C x2
1
B x2
E x2 or F x2 or
M x2
G x2 or H x2 or
I x2 or J x2 or
K x2 or L x2
A
N
M4 x 12 mm M4 x 20 mm
x2 E x2 F x2
C
b.
Meuble avec support en bois

Wood shelf mounting

y = x + 200 mm
O x4
y
M5 x 12 mm M5 x 20 mm M6 x 12 mm M6 x 20 mm
G x2 H x2 I x2 J x2
2 a.
Meuble avec support vitré

Glass shelf mounting

y = x + 200 mm
y
A
D
A
D
M8 x 20 mm M8 x 40 mm
K x2 L x2 M x2
B x2
A
C x2
C x2
B x2
http://www.norstone-design.com
Safeline
ST4.8 x 16 mm
N x1 O x4
D
N
