Summary of Contents for Ortronics Wi-Jack DUO
- Page 1 Wi-Jack DUO Installation Guide DRAFT...
- Page 2 Copyright © 2006 Ortronics, Inc. All rights reserved. Specifications in this manual are subject to change without notice. Originated in the USA. Trademarks Any other trademarks appearing in this manual are owned by their respective companies. Ortrontic Wi-Jack DUO Draft...
-
Page 3: Table Of Contents
... . Overview of Ortronics AP Setup Process Provisioning Access Points ..... - Page 4 Notes ........Ortronics Wi-Jack DUO...
-
Page 5: Chapter 1 Introduction
Introduction The Ortronics Wi-Jack DUO™ is part of a comprehensive wireless network solution. The device works in conjunction with the Ortronics Wireless Controller and can act as a wireless access point or air monitor. As a wireless Access Point (AP), the Ortronics Wi-Jack DUO provides transparent, secure, high-speed data communications between wireless network devices (fixed, portable, or mobile computers with IEEE 802.11a and IEEE 802.11b/g wireless adapters) and the wired... -
Page 6: Front View
Front View 1-1 Ortronics Wi-Jack DUO IGURE Ortronics Wi-Jack DUO Part OR-71601435 Rev 02 Draft 2006... - Page 7 Ethernet LAN segment. This port supports wired users to gain access to the WLAN. See Appendix A. 4. Serial Number & MAC Address 5. Backhaul Plug An Ortronics Keystone Jack is provided for installation/integration of Wi-Jack DUO into the LAN. See Chapter 3 for Details. 6. Internal Antennas for Wireless Communication Introduction...
-
Page 8: Overview Of Ortronics Ap Setup Process
Ortronics Wireless Controller). AP Provisioning—Provisioning provides each Ortronics AP with initial settings that allow it to locate the host Ortronics Wireless Controller. Depending on the network topology and services, AP provisioning can be performed manually for each AP or plug-and-play for batches of APs. -
Page 9: Provisioning Access Points
Wireless Controller (using the CLI or Web interface) and then uploaded to the APs. This method can be used for adding Ortronics APs to a highly customized network, or greatly simplified for the most common provisioning. Manual Provisioning—APs can be individually provisioned using a serial console terminal connected to the AP. -
Page 10: Discovery Protocol
Software User’s Guide for more information on reprovisioning existing APs. Discovery Protocol The Discovery Protocol is a plug and play provisioning tool for Ortronics Wi-Jack DUO. The Discovery Protocol performs two tasks: Obtains the IP address of the TFTP server from which it downloads the AP boot image It discovers the IP address of the master Ortronics Wireless Controller in the network from which the AP can download its configuration. -
Page 11: Ap Reprovisioning
Once these discovery prerequisites are met, the switch will respond to APs with the IP address of the Ortronics Master Wireless Protocol. The APs can then obtain their image and configuration. To enable Discovery Protocol on an Ortronics Wireless Controller, enter:... -
Page 12: Ap Provisioning
Select the Port or Port Range for provisioning. To set the Port Range, select the first and the last ports of your range. All the ports in between are automatically selected. (Ports have to be sequentially assigned.) Ortronics Wi-Jack DUO Part OR-71601435 Rev 02 Installation Guide... - Page 13 Enter the required information and click Enable.The Port Range screen displays. 2-2 Port Range Screen IGURE Plug the AP into one of the ports configured for provisioning. If your AP is already plugged into the port, unplug it and plug it in again. If AP is connected through PoE, enter poe off followed by poe on.
- Page 14 (Provisioned). Note Check that the configured parameters are reflected in the AP list entry. Note Ortronics recommends that you provision each AP for a unique location as suggested by site-survey planning. Label each AP with this location infor- mation and place the AP in its proper location. Failure to place APs in the location for which they were provisioned will reduce the effectiveness of such RF features as triangulation.
- Page 15 12 Reboot the AP so the AP will come up with the new configured parameters. Use the Reprovisioning tab for APs which are already deployed but need to be reconfigured. See the Ortronics Wireless Software User’s Guide for information on reprovisioning. Provisioning Access Points...
-
Page 16: Manual Provisioning
Manual provisioning requires this procedure. You must use the serial console breakout adapter cable to be able to access the serial console interface to the Ortronics Wi-Jack DUO while allowing the device to be powered by the AC adapter or PoE (from an Ortronics Wireless Controller). -
Page 17: Chapter 3 Ap Deployment
LAN connections. Select a location as close as possible to the center of the intended coverage area. If necessary, use the Ortronics RF Plan site survey tool to determine the optimum locations for your access points and air monitors. The service location should be free from obstructions or obvious sources of interference. - Page 18 Install cables in accordance with all applicable local regulations and practices. For more port and cable details, see Appendix B. Ortronics Wi-Jack DUO Part OR-71601435 Rev 02 Installation Guide Draft 2006...
- Page 19 AP Deployment Chapter 3...
- Page 20 Ortronics Wi-Jack DUO Part OR-71601435 Rev 02 Installation Guide Draft 2006...
-
Page 21: Appendix A Cables
Cables “To AP” Specifications The RJ-45 connector labeled “To AP” attaches to the Ortronics Wi-Jack DUO User port either directly (if the AP is physically available) or indirectly (if the AP is already deployed). When connecting indirectly, use a straight-through FE coupler to attach the “To AP” connector to the FE cable leading directly to the AP’s User port with no intervening hubs, routers, or... - Page 22 Ortronics Wi-Jack DUO Part OR-71601435 Rev 02 Installation Guide Draft 2006...
-
Page 23: Appendix B Troubleshooting
(SoE) interface or using Telnet from a remote management station. Direct SPOE Connection to Wireless Controller This method requires that the Ortronics Wi-Jack DUO is connected directly to an SPOE-compatible network port on the Ortronics Wireless Controller (see “Connecting Required Cables” on page 13). -
Page 24: Direct Terminal Connection
AP support prompt (#) will appear. Direct Terminal Connection This method requires that the Ortronics Wi-Jack DUO is connected to a compatible serial console using the Ortronics serial breakout adapter OR-AP-SPOE (see “Connecting the Console Terminal” on page 12). -
Page 25: Remote Telnet Connection
(Aruba 5000) (sap-config location b.f.d) # telnet {enable|disable} Using Telnet to Connect Use a Telnet client on your management workstation to connect to the Ortronics Wi-Jack DUO’s individual IP address. The connection command may vary depending on the specific software used, but commonly appears as follows: >... -
Page 26: Ap Support
In addition to the user commands, the following commands are available upon successfully entering the privileged mode: show [config|stats|version] Note— These commands should be used only as directed by Ortronics Customer Support. Ortronics Wi-Jack DUO Part OR-71601435 Rev 02 Installation Guide... -
Page 27: Appendix C Product Specifications
PPENDIX Product Specifications Compliance FCC - Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 28: Certifications
FCC Part 15 Class A, FCC Part 15 Class C 15.207/15.247, Compatibility FCC Part 15 Class E 15.407 ICES-003 Class A, RSS 210 (CAN) Safety UL Listed (UL60950) UL Listed (CAN/CSA 22.2 No. 60950) Ortronics Wi-Jack DUO Part OR-71601435 Rev 02 Installation Guide 2006... -
Page 29: Product Features
Radio Characteristics The Ortronics Access Point can be configured to support IEEE 802.11a and IEEE 802.11b/g operation as an AP, and supports both IEEE 802.11a and IEEE 802.11b/g operation as an 802.11a provides a high data rate and reliable wireless connectivity. -
Page 30: Contents
Power over Ethernet The Ortronics Access Point supports the IEEE 802.3af standard for Power over Ethernet (PoE). With this feature, the Ortronics Access Point can accept electrical power from a compatible PoE-capable device (such as the Ortronics OR-WCU-5, OR-WCU-16 and OR- WCU-48) directly over the FE cable. - Page 31 C-1 Wi-Jack DUO Specifications ABLE Description 802.11a 802.11b 802.11g Antenna Dual, diversity internal tri-band 802.11a/b/g antennas Frequency 5.250 ~ 5.350 2.4 ~ 2.483 Ghz 2.412 ~ 2.462 Band Ghz (middle (US, Canada & Ghz (US, Can- band) 4 channels ETSI) ada) 5.725 ~ 5.825...
- Page 32 C-2 Wi-Jack DUO (Continued) ABLE Description Maximum Clients Multi-mode Radio Selectable via software Band Manageability: Management of all 802.11 parameters Network Wide AP Management via: WEB GUI SNMPv3 Access Point Profiles, Management by: Geographical Location BSSID Radio Type Encryption Support...
- Page 33 ABLE Description Power Requirements 48V DC / 200mA Power over Ethernet (802.3af compliant) Output Power 100 mW maximum (or lower as configured on the Ortronics Wireless Controller to comply with local regulatory requirements) Environmental Humidity 5% to 95% (non-condensing) Operating Ambient...
-
Page 34: Related Documents
Related Documents The following items are part of the complete documentation for the Ortronics Wireless Solution: Ortronics Wi-Jack DUO Installation Guide (this document) Ortronics Wireless Controller Installation Guide Ortronics RF Plan User’s Guide Ortronics Wireless Software User’s Guide For the current versions of these manuals, or to obtain the latest product release notes, visit the support section of our Web site (see page 32). -
Page 35: Text Conventions
Text Conventions The following conventions are used throughout this manual to emphasize important concepts: 3-1 Text Conventions ABLE Type Style Description Italics This style is used to emphasize important terms and to mark the titles of books. This fixed-width font depicts the following: System items Sample screen output System prompts... -
Page 36: Contacting Ortronics
Contacting Ortronics Main US 877-599-5393 - Toll-free Main 860-445-3800 888-282-0043 - Toll-free 860-405-2970 Email connect@ortronics.com Web Site http://www.ortronics.com Ortronics Wi-Jack DUO Part OR-71601435 Rev 02 Installation Guide 2006... -
Page 37: Notes
Notes... -
Page 38: Notes
Notes...
