5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS
H135WSUA11 Hot Cabinet (Stainless Steel)
Model No.
H135WUA11
H135WSUA11
H135WUA11208
H135WSUA11208
H135WUA11240
H135WSUA11240
All are designed for AC service. The above model numbers may be followed by "M", "L", "D", "R"
and ending with "S" or "Z".
HOW TO INSTALL UNIT:
1. Place cabinet near warm ovens. Do NOT place
cabinet in drafty areas or near ventilating systems.
2. Plug end into proper wall outlet.
3. Fill with 2 qts.(1.8 liters) of clean, hot water.
CAUTION
for proper operation and to maintain warranty.
HOW TO PROOF:
1. Fill water pan (See "How to Install")
2. Push "POWER" switch to "ON." The yellow light
will come on.
3. Push "MODE SELECTION" switch to "PROOF".
The yellow light will come on.
4. Turn "HUMIDITY" dial to No. 8.
5. Turn "AIR" dial to "OFF."
6. Preheat for 30 minutes. "
7. Put fresh or fully thawed dough into cabinet.
NOTE: The cabinet temperature will drop tempera-
ture inside cabinet if cold dough is added.
Do NOT put frozen dough into cabinet
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
for H135WUA11 Hot Cabinet (Aluminum)
Volts
120
208
240
Use of treated or soft
water may be required
Watts Amps
2000 16
2000 9.6
2000 8.6
CONTROL PANEL PARTS IDENTIFICATION
1. Switch-Power
2. Yellow Light-Power
3. Thermostat-Humidity
4. Thermostat-Air
NOTE: No. 8 setting will give you an approximate
temperature of 95°F (35°C), and 90-95%
humidity. Experiment with different "HU-
MIDITY" and "AIR" settings to get the exact
temperature and humidity you need. The
thermometer shows the temperature inside
the cabinet.
NOTE: Check water level in water pan if you are
proofing longer than 90 minutes. Fill with
clean, hot water.
Hot Cabinets
Rev. 2 (3/13)
Hertz Phase NEMA
60 1 5-20P
60 1 6-15P
60 1 6-15P
5. Yellow Light-Proof
6. Red Light-Heat
7. Switch-Mode Selection
8. Thermometer
FL-2334
Page 1 of 4
