Summary of Contents for Robinson Regatta
- Page 1 NOMINAL SIZE A (mm) B (mm) 5 x 4 1392 5 x 6 2012 5 x 8 2632 1662 5 x 10 3252 5 x 12 3872...
- Page 2 Thank you for purchasing your new Robinsons greenhouse. We recommend you familiarise yourself with the instructions and read all safety information before you commence assembly. This instruction manual is also available online at www.robinsonsgreenhouses.co.uk in our technical help section should you need to reprint it. Should you require any additional advice you can always call us on 01782 385409. These instructions are divided into sections highlighted by a white number/letter on a black background at the bottom corner of most pages (see opposite page for details);...
- Page 3 SECTION TITLE ASSEMBLY SYNOPSIS: IMPORTANT INFORMATION / CONSIDERATIONS Most components should have a ‘D’ code punched into their metal surface. Identify and sepa- PARTS LIST rate all like for like components prior to assembly. The ‘parts list’ also separates parts into the various sections shown below.
- Page 4 Section Section Part Section Size Part Section Size (mm) (mm) D071 1274 D072 1277 D044 1897 D043 1894 D001 2517 D021 2514 D002 3137 D022 3134 D003 3757 D023 3754 D070 1277 D042 1897 D752 D014 2517 D015 3137 1000 RUBBER (1m) 11 15 18...
- Page 5 Section Section Part Section Size Part Section Size (mm) (mm) D812 1660 D762 + D347 lock D661 1906 1714 D764 D758 D754 D763 + D156 D813 1675 1714 strike = D765 D766 1773 D834 1660 D753 D760 1714 D755 10 12 14 D825 1660 10 12 14...
- Page 6 8 x 10 is the model 8'6" x 10' 8" MODEL (mm) WIDTH (mm) LENGTH (mm) DIAGONAL 5 x 4 1392 2168 5 x 6 2012 2610 REGATTA 1662 5 x 8 2632 3113 3652 5 x 10 3252 4214 5 x 12 3872...
- Page 7 Feed glazing rubber into each glazing bar and PARTITION trim to length. Notice that some channels are ONLY REFER TO only used on a partition. Applying a lubricant to SEPARATE MANUAL the aluminium channels will speed up insertion. PARTITION ONLY REFER TO SEPARATE MANUAL...
- Page 8 4 X 2 Part No Quantity D070 1277 D070 D071 1274 D066 1676 D103 1787 D174 M6-10mm M6-15mm M6-NUT D071 Rubber 1000 6 X 2 Part No Quantity D042 1897 D042 D043 1894 D066 1676 D103 1787 D174 M6-10mm M6-15mm M6-NUT D043 Rubber...
- Page 9 D103 10mm D066 TRANSIT BOLT ON 15mm DIAGONALS D066 D103 15mm...
- Page 10 Part No Quantity Part No Quantity D111 D756 1670 D048 1676 D174 D655 1906 D227 15.5m D757 1738 D750 M6X10 D751 M6X15 M6NUT 10mm D750 D751 10mm 10mm 10mm D655 D757 D655 D048 D757 D048 D756 15mm 10mm 15mm 10mm 15mm 15mm 15mm...
- Page 11 D750 D750 D751 D111 D655 D750 D048 D757 D048 D757 D655 D174 D756 D756...
- Page 12 Part No Quantity Part No Quantity D111 D756 1670 D048 1676 D174 D655 1906 D227 15.5m D757 1738 D750 M6X10 D751 M6X15 M6NUT D750 10mm D751 10mm 10mm 10mm D655 D757 D655 D048 D757 D048 D756 15mm 10mm 15mm 15mm 10mm 15mm 15mm...
- Page 13 D750 D750 D751 D655 D111 D750 D048 D757 D048 D757 D655 D174 D756 D756...
- Page 14 EQUAL...
- Page 15 4’ 6’ 8’ 10’ 12’ Part Quan. Part Quan. Part Quan. Part Quan. Part Quan. D044 1897 D072 1277 D001 2517 D002 3137 D003 3757 D752 D752 D752 D752 D752 RUBBER RUBBER RUBBER RUBBER RUBBER 1000 1000 1000 1000 1000 D752 D752 D752...
- Page 16 Part No mm Quantity Part No mm Quantity D220 D866 PLUS SCREW D205 D863L D863R BOLM6X11 SYNUTM6 D862 D1208 8 X 12 S/T 1 of - FS6017 610 x 610 8 x 19 S/T pane FS6018 D863R D863R D866 D863L D866 D1208 1 of -...
- Page 17 D862 D863L D862 FLIP VIEW D119...
- Page 18 Part No mm Quantity Part No mm Quantity D079 PLUS BOLM6X11 FLUFF D114 BOLM6X15 SYBOLM6 X11CROP SYNUTM6 D114 D079 D114 FLIP VIEW...
- Page 19 D775 GLASS D1254 GLASS D775 GLASS...
- Page 20 Part No mm Q Part No mm Q D762 + D347 lock = D233 D764 1714 1 D909 D763 + D156 strike = D909 247 x 812 D765 1714 1 247 x 812 P053 pane pane D760 1714 1 (cut 2 D225 x 305) D761...
- Page 21 D909 247 x 812 pane D909 D233 247 x 812 pane D909 247 x 812 pane D060 D225 D062 D225 D840B P053...
- Page 22 D759 D759 PART Section Size (mm) D758 D758 D812 1660 D661 1906 D758 D754 D812 D813 1675 D766 1773 D826 D767 D767 D826 D834 1660 D813 D766 D766 D813 D753 D755 D825 D825 1660 D826 1677 125° D665 1908 D767 1773 D759 D755...
- Page 23 PART Size (mm) 4’ 6’ 8’ 10’ 12’ D1206 610 X 1374 5 D775 610 X 900 D1208 610 X 610 D1254 610 X 305 8 10 13 D770 457 X 305 D771 457 X 1374 D909 247 X 812 D772 ANGLE D774...
- Page 24 D220 D220...
- Page 25 D862 D079...
- Page 26 Part No Part No D163 D864 D150 D845 D082 1270 BOLM6X15 SYNUTM6 D081 1270 D845 D845 D655 D767 D766 D163 D655 D845...
- Page 27 N/A 4 D150 D082 D081 D864 D864 N/A 4 D845...
- Page 28 Part No Quantity D860 D087 D087 D860 D860 D087...
- Page 29 Part No Quantity D312 D222/B D204L/B D204R/B D751 D204R D312 D758 D774 D758 D759 D759 D222/B...
- Page 30 O7mm...
- Page 31 Part No Quantity D168L D168R (handle) D165 D166 FS6013 D166 D166 D168L D168R D165 D165 INTERNAL VIEW D729TG - 100 x 525 panes x 6 PINCH ALL GLASS RETAINERS BEFORE GLAZING D165...
- Page 32 3 slat Example: 2x 4’ shelves ‘ST0304’ = 8’ run 10mm crop D2013 D048 15mm 10mm 10mm D066 D048 D2014 10mm crop D2002 =1240mm D2002 =1240mm D2014 D2021 D2003 =1860mm...
- Page 33 5 slat Example: 2x 4’ staging ‘ST0504’ = 8’ run D048 D2045 D2043 D066 D048 10mm D2044 crop 10mm crop 10mm 10mm 10mm D2040 D2040 D2041 D2043 D2044 D2045 D2042 D2042 D2042 D2002 =1240mm 10mm 10mm D2002 FINISH =1240mm START D2003 =1860mm D2002...
- Page 34 D214 D203 D201 D119 D119 D208 D211 D048 D202 D841 D119 D211 D048 D207 D048 D206...
- Page 35 START ROCRE W/G FINISH ROFIN W/G ROFIN W/G D119 START FINISH EQUAL EQUAL...
- Page 36 Please be aware that this is a multi-national manual, if you spot any errors or have any constructive comments regarding the manual please email james@thegreenhousepeople.co.uk and I will make the necessary amendments. Whilst the information contained in this booklet is accurate at the time of publication, changes in the course of Robinsons policy of improvement through development and design might not be indicated.
