PPM ViaLiteHD HEA-xx-HB-4 series User Manual

Outdoor enclosure
Table of Contents

Advertisement

Quick Links

HEA-
-HB-4 V
L
HD SATCOM6 H
XX
IA
ITE
ANDBOOK
ViaLiteHD
SATCOM6
Outdoor enclosure
User Manual
HEA-xx-HB-4
CR3974
21/12/18
Pulse Power & Measurement Ltd, 65 Shrivenham Hundred Business Park, Watchfield, Swindon, Wiltshire SN68TY, UK
Tel +44 (0)1793 784389
Fax +44 (0)1793 784391
Email
sales@vialite.com
Web
www.vialite.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ViaLiteHD HEA-xx-HB-4 series and is the answer not in the manual?

Questions and answers

Summary of Contents for PPM ViaLiteHD HEA-xx-HB-4 series

  • Page 1 HEA- -HB-4 V HD SATCOM6 H ANDBOOK ViaLiteHD SATCOM6 Outdoor enclosure User Manual HEA-xx-HB-4 CR3974 21/12/18 Pulse Power & Measurement Ltd, 65 Shrivenham Hundred Business Park, Watchfield, Swindon, Wiltshire SN68TY, UK Tel +44 (0)1793 784389 Fax +44 (0)1793 784391 Email sales@vialite.com www.vialite.com...
  • Page 2 HEA- -HB-4 V HD SATCOM6 H ANDBOOK Instrument Care and Safety Information Please read the whole of this section before using your ViaLiteHD product. It contains important safety information and will enable you to get the most from your Fibre Optic link. Electrical Safety The ViaLiteHD SATCOM6 enclosure provides the termination for power inputs and can be fitted with power supplies.
  • Page 3: Table Of Contents

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK TABLE OF CONTENTS INITIAL INSPECTION ................................ 4 INTRODUCTION TO THE VIALITEHD RANGE ......................... 4 SATCOM6 SYSTEM DESCRIPTION ..........................5 Backplane connections ............................7 Glandplate connections ............................9 External interface connectors and fuses....................... 10 Power system ..............................
  • Page 4: Initial Inspection

    A ViaLiteHD system can be added to at any time, enabling the system to evolve with the needs of the user. ViaLiteHD is a product brand manufactured by Pulse Power and Measurement Ltd (PPM). ViaLite Communications is a division of...
  • Page 5: Satcom6 System Description

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK SATCOM6 System Description The SATCOM6 is a stainless steel, weatherproof enclosure designed specifically to be mounted near or by the antenna at teleports and ground stations. The enclosure accepts up to six ViaLiteHD modules including all RF, digital and ancillary modules. The enclosure can be fitted with dual power supplies, switch and splitter modules to enable full redundancy.
  • Page 6 HEA- -HB-4 V HD SATCOM6 H ANDBOOK Power switches PSUs Optional sunshield SNMP Management & Control PCB Fans Mounting hinges SNMP card Backplane LNBs craft port Optical adapters Figure 1 SATCOM6 enclosure, illustrated are several EDGE modules mounted to the Backplane PCB...
  • Page 7: Backplane Connections

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK Backplane connections Your cabinet should be delivered fully configured as per your order, and ready to operate. The details of the default backplane configuration will be contained in your order specific handbook that your SATCOM6 is delivered with. PSU Main D6–fan status...
  • Page 8 HEA- -HB-4 V HD SATCOM6 H ANDBOOK Switch/ Function description Configuration example Configuration example description jumper  Serial digital card used in ‘POWER’ (jumper down) connects the output of the LNB to the BUC FEED pin SLOT3 of the fibre optic receiver; ‘DATA’ ...
  • Page 9: Glandplate Connections

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK Glandplate connections Figure 3 SATCOM6 enclosure - bottom view Any unused connections will be environmentally sealed. Figure 4 SATCOM6 glandplate with dimensions...
  • Page 10: External Interface Connectors And Fuses

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK External interface connectors and fuses RF connector: N-Type female, impedance to match your RF modules Power connector:* Circular plug [Neutrik Powercon True1] Gland: M16 Gland accommodate wire diameters 2 to 7mm [Lapp Kabel 53112110] * If no power cable is supplied a mating half will be supplied unwired, with assembly instructions A range of preterminated power cables are available contact ViaLite Communications for more details.
  • Page 11: Power Supply Specification

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK EDGE Switch 0.4W typical EDGE Splitter 0.4W typical EDGE Ethernet 1.9W typical SNMP controller 4.0 W typical EDGE LNB PSU 7.1W typical (@ output 18V, 350mA) EDGE LNB PSU efficiency 88% typical, for HRP-1-00-0N-00 AC to DC efficiency 84.5% typical, for HPS-6, more details see section 3.4.3 DC to DC efficiency...
  • Page 12: Enclosure Installation

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK Enclosure installation The SATCOM6 enclosure has been designed to work in harsh environments. The maximum ambient temperature for the enclosure is C. When installing the enclosure pay attention to the following: Leave open space around the enclosure to allow air circulation (minimum gap of 15cm is recommended). Avoid installation in places with direct exposure to the sun.
  • Page 13: System Configuration

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK System configuration Slots configuration Your SATCOM6 should be delivered preconfigured to your order instructions. To check the configuration, please follow the procedure below. Check if the module is suitable to be used in the slot according to the pin outs it has (see table 1 in section 3). Using jumpers J11 and J21 configure pins 1 and 9 of the slot.
  • Page 14: Summary Alarm Configuration

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK Pin number Pin description BUC FEED or TX422 IN+ (configurable via J11) TX422 IN- TX232 IN RX422 OUT+ RX422 OUT- RX232 OUT LNB FEED or RTS (configurable via J21) Serial CFG1 Serial CFG2 ALARM Serial CFG3 Table 5 Slots 3 and 6 pin-outs...
  • Page 15: External D25 Connector

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK External D25 connector The external D25 connector provides access to serial interface if serial digital cards are installed in slot 3 or 6. Refer to the serial digital cards handbook for more information. Dry relay contacts to indicate alarms are also available. Pin description Description Pin description...
  • Page 16: Logic Interface, Rs232

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK 5.7.2 Logic interface, RS232 Absolute maximum voltage rating -15 to +15V No damage Input, Logic Low (max) <0.8V Input, Logic High (min) >2.6V Output, Logic Low (max) <-3.2V no load Output, Logic High (min) >+3.2V no load Drive capability 3k ohms...
  • Page 17: Cabinet Power Input, 24Vdc

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK 5.7.10 Cabinet power input, 24VDC Nominal input voltage 24VDC Maximum operational voltage range 19-36VDC See section 3.4.3 for more details 5.7.11 Cabinet power input, 48VDC Nominal input voltage 48VDC Maximum operational voltage range 36-72VDC See section 3.4.3 for more details...
  • Page 18: Additional Auxiliary Modules

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK Additional auxiliary modules The space for auxiliary modules is provided under the metal work holding the motherboard. The wide range of passive units includes diplexers, RF splitters, bias Tees. Fibre components including fibre splice trays, CWDM filters and optical splitters can also be installed in this area.
  • Page 19: 70030 High Current Bias T Dc, 75 Ohms

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK 70030 High current Bias T DC, 75 ohms Uses part number 56087 in upto 3 positions Sectioned Front view Figure 8 SATCOM6 position of 70030 70042 Low current Bias T DC Injector, 50 ohms Uses part number 56094, upto 3 can be mounted on a single internal bracket Figure 9 SATCOM6 position of 70042...
  • Page 20: 70021 Low Current Bias T Dc Injector, 50 Ohms

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK 70021 Low current Bias T DC Injector, 50 ohms Uses part number 56099 in upto 3 positions Figure 10 SATCOM6 position of 70021 56097 RF splitter/combiner, 2 way, 10-2500MHz, 50 ohms Uses part number 56097 in upto 3 positions Figure 11 SATCOM6 position of 56097...
  • Page 21: 56098 Rf Splitter/Combiner, 2 Way, 10-2500Mhz, 75 Ohms

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK 56098 RF splitter/combiner, 2 way, 10-2500Mhz, 75 ohms Uses part number 56098 in upto 3 positions Figure 12 SATCOM6 position of 56098 56100 RF splitter/combiner 3 way, 700-2400MHz, 50 ohms Uses part number 56100 in upto 2 positions Sectioned Rear view Figure 13 SATCOM6 position of 56100...
  • Page 22: 56140 Rf Splitter/Combiner 4 Way, 400-2400Mhz, 50 Ohms

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK 56140 RF splitter/combiner 4 way, 400-2400MHz, 50 ohms Uses part number 56140 in 1 position Figure 14 SATCOM6 position of 56140 56088 Diplexer and Bias Tee, 4 port, 10MHz + L-Band + DC, 50 ohms Uses part number 56088 in upto 3 positions This module has four separate ports for L-Band, 10MHz, DC and common Sectioned Rear view...
  • Page 23: 56089 Diplexer And Bias Tee, 3 Port, 10Mhz + L-Band + Dc, 50 Ohms

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK 6.10 56089 Diplexer and Bias Tee, 3 port, 10MHz + L-Band + DC, 50 ohms Uses part number 56089 in upto 3 positions This module has four separate ports for L-Band +DC, 10MHz and common Sectioned Rear view Figure 16 SATCOM6 position of 56089 6.11...
  • Page 24: 53237 Cwdm 8 Channel High Isolation Module, Wave Length 1470 - 1610Nm

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK 6.12 53237 CWDM 8 channel high isolation module, wave length 1470 - 1610nm Uses part number 53237 in 1 position Figure 18 SATCOM6 position of 53237 6.13 53238 CWDM 8 channel standard isolation module, wave length 1470 - 1610nm Uses part number 53238 in 1 position Figure 19 SATCOM6 position of 53238...
  • Page 25: 54150 Ancillary Ethernet Module

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK 6.14 54150 Ancillary Ethernet module Uses part number 5150 in 1 position Figure 20 SATCOM6 position of 54150 6.15 56213 RF splitter/combiner 6 way, 10-200MHz, 50 ohms Uses part number 53213 in 1 position Figure 21 SATCOM6 position of 54213...
  • Page 26: 56214 Rf Splitter/Combiner 3 Way, 5-500Mhz, 50 Ohms

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK 6.16 56214 RF splitter/combiner 3 way, 5-500MHz, 50 ohms Uses part number 53214 in upto 2 positions Figure 22 SATCOM6 position of 54214 6.17 92223 Tray fusion splice holder Uses part number 92223 in 1 position Figure 23 SATCOM6 position of 92223...
  • Page 27: Satcom6 Specification

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK SATCOM6 specification SATCOM6 ViaLiteHD Outdoor Enclosure Number of RF links 1 to 6 IP Rating IP66 External Dimensions (H:W:D) 380mm : 300mm : 210mm Weight (without modules) Approx. 15kg Material 304 stainless steel Interface N-type (50Ω...
  • Page 28: Satcom6 Part Number Matrix

    HEA- -HB-4 V HD SATCOM6 H ANDBOOK SATCOM6 part number matrix Note: Note not all combinations of options are available. Contact ViaLite Communications for more details...
