7. Technical Specifi cations
Processing
Input Processing Channels
Output Processing Channels
16 aux buses, 6 matrices, main LRC
Internal Eff ects Engines (True Stereo / Mono)
Internal Show Automation (structured Cues / Snippets)
Internal Total Recall Scenes (incl. Preamplifi ers and Faders)
Signal Processing
A/D Conversion (8-channel, 96 kHz ready)
D/A Conversion (stereo, 96 kHz ready)
I/O Latency (Console Input to Output)
Network Latency (Stage Box In > Console > Stage Box Out)
Connectors
MIDAS PRO Series Microphone Preamplifi er (XLR)
Talkback Microphone Input (XLR)
RCA Inputs / Outputs
XLR Outputs
Monitoring Outputs (XLR / ¼" TRS Balanced)
Aux Inputs/Outputs (¼" TRS Balanced)
Phones Output (¼" TRS)
AES50 Ports (KLARK TEKNIK SuperMAC)
Expansion Card Interface
ULTRANET P-16 Connector (No Power Supplied)
MIDI Inputs / Outputs
USB Type A (Audio and Data Import / Export)
USB Type B, rear panel, for remote control
Ethernet, RJ45, rear panel, for remote control
Mic Input Characteristics
Design
THD+N (0 dB gain, 0 dBu output)
THD+N (+40 dB gain, 0 dBu to +20 dBu output)
Input Impedance (Unbalanced / Balanced)
Non-Clip Maximum Input Level
Phantom Power (Switchable per Input)
Equivalent Input Noise @ +45 dB gain (150 Ω source)
CMRR @ Unity Gain (Typical)
CMRR @ 40 dB Gain (Typical)
32 Input Channels, 8 Aux Channels, 8 FX Return Channels
8 / 16
100
8 / 16
500 / 100
100
40-Bit Floating Point
24-Bit, 114 dB Dynamic Range, A-weighted
24-Bit, 120 dB Dynamic Range, A-weighted
0.8 ms
1.1 ms
16
1
2 / 2
8
2/2
6 / 6
1 (Stereo)
2
32 Channel Audio Input / Output
1
1 / 1
1
1
1
MIDAS PRO Series
< 0.01% unweighted
< 0.03% unweighted
10 kΩ / 10 kΩ
+23 dBu
+48 V
-125 dBu 22 Hz-22 kHz, unweighted
> 70 dB
> 90 dB
Input/Output Characteristics
Frequency Response @ 48 kHz Sample Rate
Dynamic Range, Analogue In to Analogue Out
A/D Dynamic Range, Preamplifi er and Converter (Typical)
D/A Dynamic Range, Converter and Output (Typical)
Crosstalk Rejection @ 1 kHz, Adjacent Channels
Output level, XLR Connectors (Nominal / Maximum)
Output Impedance, XLR Connectors (Unbalanced / Balanced)
Input impedance, TRS Connectors (Unbalanced / Balanced)
Non-Clip Maximum Input Level, TRS Connectors
Output Level, TRS (Nominal / Maximum)
Output Impedance, TRS (Unbalanced / Balanced)
Phones Output Impedance / Maximum output Level
Residual Noise Level, Out 1-16 XLR Connectors, Unity Gain
Residual Noise Level, Out 1-16 XLR Connectors, Muted
Residual Noise Level, TRS and Monitor out XLR Connectors
DN32-LIVE USB Interface
USB 2.0 high speed, type-B (audio/MIDI interface)
USB input / output channels, duplex
Windows DAW applications (ASIO, WASAPI and WDM audio device interface)
Mac OSX DAW applications (Intel CPU only, no PPC support, CoreAudio)
DN32-LIVE SD Card Interface
SD card slots, SD/SDHC
SD/SDHC supported fi le system
SD/SDHC card capacity, each slot
Battery for power blackout protection (optional)
SD card input / output channels
Sample rates (console clock)
Sample word length
File format (uncompressed multi-channel)
Maximum recording time (32 ch, 44.1 kHz, 32-bit on two 32 GB SDHC media)
Typical performance recording or playback
Display
Main Screen
Channel LCD Screen
Main Meter
Power
Switch-Mode Power Supply
Power Consumption
Physical
Standard Operating Temperature Range
Dimensions
Weight
** OSX 10.6.8 Core Audio supports up to 16x16 channel audio
Quick Start Guide
0 dB to -1 dB 20 Hz – 20 kHz
106 dB 22 Hz - 22 kHz, unweighted
109 dB 22 Hz - 22 kHz, unweighted
109 dB 22 Hz - 22 kHz, unweighted
100 dB
+4 dBu / +21 dBu
50 Ω / 50 Ω
20 kΩ / 40 kΩ
+21 dBu
+4 dBu / +21 dBu
50 Ω / 50 Ω
40 Ω / +21 dBu (Stereo)
-85 dBu 22 Hz-22 kHz, unweighted
-88 dBu 22 Hz-22 kHz, unweighted
-83 dBu 22 Hz-22 kHz, unweighted
1
32, 16, 8, 2
Win 7 32/64-bit, Win10 32/64-bit
Mac OSX 10.6.8**, 10.7.5, 10.8, 10.9, 10.10, 10.11, 10.12
2
FAT32
1 to 32 GB
CR123A Lithium cell
32, 16, 8
44.1 kHz / 48 kHz
32 bit PCM
WAV 8, 16 or 32 channels
200 min
32 channels on class 10 media, 8 or 16 channels on class 6 media
5" TFT LCD, 800 x 480 Resolution, 262k Colours
128 x 64 LCD with RGB Colour Backlight
18 Segment (-45 dB to Clip)
Auto-Ranging 100-240 VAC (50/60 Hz) ± 10%
70 W
5°C – 40°C (41°F – 104°F)
478 x 617 x 208 mm (18.8 x 24.3 x 8.2")
14.3 kg (31.5 lbs)
