E l e c t r i c F u e l L t d .
SP 102626
Info
Name:
SLX MARINE LIFEJACKET LIGHT
INSTRUCTION MANUAL
0.0
Purpose
1.0
Purpose
This Instruction Manual is intended to provide descriptive information on the Model SLX
Marine Lifejacket Light and its variations, operating instructions, information for its
maintenance and overhaul, instruction concerning the proper mounting of the light on
lifejackets to ensure compliance with minimum performance standards, and limitations for the
device.
2.0
Description of Device
The Model SLX and its variations is a SOLAS approved flashing lifejacket light that is
activated automatically when immersed in water and can be deactivated manually. Variations
of the SLX also offer manual activation or permanent deactivation. The SLX consists of a
battery and light encased in either one plastic housing (SLX), or a battery assembly and a
separate light assembly, connected by an electrical wire (SLX-II). See table 1 for options.
Table 1:
• SLX/SLX-II
• SLX/SLX-II (c)
• SLX/SLX-II (s)
The battery consists of one Lithium Manganese Dioxide cell incorporated into a water-tight
sealed housing. The housing has two exposed water sensor contacts. The electronic circuit
detects water and activates the light. The design prevents inadvertent extinguishing of the
light if the water sensor is not continuously immersed in water. The housing also has a button
for the manual switching of the light.
The light is a LED covered by a polycarbonate cover.
Operating Instructions
The SLX is activated automatically following immersion of the
water sensor in fresh water or seawater. The SLX can be turned off
by pressing the button on the top of the housing. See figure 1.
•
In SLX versions that allow manual activation, this can be done
by repressing the same button.
•
In SLX (s) versions with permanent off, the SLX can be reset
for water activation by one long pressing of the same button.
Rev:
1
Automatic
Manual on
activation in water
www.electric-fuel.com/safety
Date:
July 2010
Manual off
Page 1 of 3
Permanent off/
Reset
PRESS
▼
PRESS
▼
Figure 1:
Advertisement
Table of Contents
Summary of Contents for Electric Fuel SLX
- Page 1 SLX also offer manual activation or permanent deactivation. The SLX consists of a battery and light encased in either one plastic housing (SLX), or a battery assembly and a separate light assembly, connected by an electrical wire (SLX-II). See table 1 for options.
- Page 2 Once fastened with the clip, the light cannot be removed without breaking the clip. 2. The SLX light should be placed at the top or on the front of the shoulder of the lifejacket in accordance with the instructions of the lifejacket manufacturer.
- Page 3 3. SLX contains a lithium battery. Do not dismantle, tamper, recharge or incinerate. 4. Storage: Avoid extreme humidity and temperatures. 5. Disposal: Dispose of used batteries in accordance with local regulations.
