INSTRUCTION MANUAL
Heater assembly for Color and Day / Night domes
Thank you for choosing the heater assembly for 3-Axis Vandal resistant domes.
Before attempting to connect or operate this product, please read and follow these instructions.
General
This heater assembly is designed to provide heat to the new 3-Axis Vandal resistant domes.
The manual is designed to assist in the fitting of the heater assembly.
Contents of Package
1. Heater PCB
2. Heater
3. User Manual
4. Screw
Installation
1. Remove support bracket
2. Remove cable tie of the heater power cable
3. Remove OSD Control PCB
Advertisement
Table of Contents
Summary of Contents for Vicon Security V670-HT202VK
- Page 1 INSTRUCTION MANUAL Heater assembly for Color and Day / Night domes Thank you for choosing the heater assembly for 3-Axis Vandal resistant domes. Before attempting to connect or operate this product, please read and follow these instructions. General This heater assembly is designed to provide heat to the new 3-Axis Vandal resistant domes. The manual is designed to assist in the fitting of the heater assembly.
- Page 2 4. Install Heater & Heater + OSD Control PCB 5. Fasten support bracket Specification Power source Power supply 24VAC/12VDC Power consumption Power consumption 20W Max Heater ON : at 41℉(5℃) Operating Temperature Heater OFF : at 59℉(15℃) 50304449A...
