1.1 Introduction
1.1.1 Purpose and Scope
This documents the procedure used to install the nanoBTS hardware and physical
connections together with applying the base software configuration.
1.1.2 Related Documents
Reference
Document Title
Number
1
CENG0133
2
CENG0220
1.2 Warnings
This document must be translated into your local language, if English is
not commonplace.
This system is designed to be operated indoors as a fixed system
device and must be located either on or near the ceiling away from the
user. It must be mounted in a manner to ensure that all users and
bystanders and users are kept a minimum of 20cm away from
antennas at all times.
Do not touch or move the antenna(s) while the unit is transmitting or
receiving. Do not hold any component containing a radio such that the
antenna is very close to or touching any exposed parts of the body,
especially the face or eyes while transmitting.
In most parts of the world, regulatory approval(s) are needed before
the nanoBTS is operated.
Do not connect any device other than the nanoBTS to any RJ45 socket
that has been enabled for nanoBTS connection (i.e. 48Vdc operation).
© ip.access Ltd
COMPANY CONFIDENTIAL
Description
Customer Safety and Regulatory Information
Operations Procedure
CENG0210_XB Hardware Installation -
Page 1 of 12
nanoBTS.doc
