Renew Health Zensor device V1 Start Manual

Start Guide
1
1
RA electrode patch label
2
1
RA electrode patch label
:10
sec
3
4
5
© Zensor Device 2019
TM

DETERMINE PATCH LOCATION

Electrode Array
Plan position of where patches will be placed before
�
1 2
removing the liners.
3
The patches should only be placed on healthy, dry skin.
�

SKIN PREPARATION

2
� Inspect the area to ensure the skin is:
� Intact
LA electrode patch label Lower left electrode patch label
Hairless
�
� If required, remove chest hair.
If required, clean skin using soap and water.
�
2
� Allow skin to dry completely.
APPLYING ZENSOR™ PATCHES
LA electrode patch label Lower left electrode patch label
� Remove the patch liners to expose the adhesive.
Place patches in the recommended position.
�
Press firmly across each patch for 10 seconds.
�
If required, coil and tape the excess wire to the skin.
�
ATTACH ZENSOR™ UNIT
� Give the BLUE button on your unit one quick press to turn it on. Make sure the
unit is showing a GREEN
Line up the unit studs with the magnetic studs on the patch.
�
� Connect the unit to the patch.
� Gently lift the edges of the unit to confirm all four connections are made.
� Try the 'wriggle test' - if you cannot move the unit around, you will know it is
properly attached.

EVERYTIME A SYMPTOM IS FELT

Press the BLUE button once.
�
� Remain still for 30 seconds while your heart rhythm is recorded.
The Zensor™ system is not intended to be used to summon emergency care.
www.zensordevice.com
3
3
light before attaching it.
PN 1414 Rev A
