Vsst VR-110A User Manual

Audio/video streaming network adaptor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
111
Chapter 1
VR-110A Introduction and Installation
1-2. Package Information
Chapter 3
3-1. VR-110A setup
3-4. Basic setting
3-10. Checking current setting
4-1. MediaWings System configuration
4-2 How to use MediaWings
Chapter 5
VR-110A Advanced Setting
5-1. When using Firewall / IP router
5-2 Upgrading your Firmware
- 1 -
- 1 -

Table of Contents

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VR-110A and is the answer not in the manual?

Questions and answers

Summary of Contents for Vsst VR-110A

  • Page 1: Table Of Contents

    - 1 - - 1 - Table of Contents Chapter 1 VR-110A Introduction and Installation 1-1. VR-110A Characteristic 1-2. Package Information 1-3. Parts Description 1-4. Front LED description 1-5. Product Specification Chapter 2 VR-110A Network Configuration 2-1. Windows 98/me 2-2. Windows 2000 2-3.

  • Page 2: Vr-110A Characteristic

    EVDO mobile phone with RTSP player installed can use it with VOD service Full support on Static IP, external xDSL modem, and dynamic IP such as Cable modem (Cf. VR-110A does not support ADSL service with internal modem Easily managed by remote control and firmware upgrade through network With additional PCMCIA card, it is fully adaptable to 802.11b, wireless LAN...

  • Page 3: Parts Description

    VR-110A VR-110A User Explain spec, function and feature Manual Power Adapter (DC 6) Power supply UTP cable Cable for LAN and VR-110A BNC-RCA Converter Converter between RCA and BNC RCA/Stereo Pin Audio Jack Type change Converter 1-3. Parts Description [Power] Connect your 6V power adaptor here.

  • Page 4: Front Led Description

    - 4 - - 4 - [Reset button] Press this button for reset VR-110A to default value. [Video Port] Video Input for receiving Video data [Audio Port] Audio input with RCA / Stereo connection [On/Off] 75Ω Impedance resistor On/OFF switch...
  • Page 5 - 5 - - 5 - Name Color Status Description No Video Streaming VIDEO Green Blinking Video Streaming in progress No Audio Streaming AUDIO Green Blinking Audio Streaming in progress No client access STATUS Green More than one client access Blinking Firmware upgrade in progress No PCMCIA Wireless LAN...

  • Page 6: Product Specification

    - 6 - - 6 - 1-5. Product Specification List Description Video Interface Support standard NTSC / PAL analog video signal with 1 channel through BNC connector Audio Interface Support Standard analog stereo audio signal( RCA connector) Interface Network Interface 2 10/100Base-T Ethernet interface to access LAN/WAN (RJ-45 ports) Spec Remote Interface...

  • Page 7: Chapter 2 Vr-110A Network Configuration

    - 7 - - 7 - Chapter 2 VR-110A network 2-1. Windows 98/me configuration ① Select Windows menu [Start] [Setting] [Control Panel] ② Select [Network] ③ In the Network Window, select the LAN card being used among [TCP/IP] list, and click on [Property] ④...

  • Page 8: Vr-110A Setup

    By using embedded web interface, system configuration to use VR-110A can be set. When you start VR- 110A for the first time, or do not know the IP address that is given to VR-110A, you can use the following method. By default, VR-110A has IP address of “192.168.120.1” Since this IP will not change no matter what, you can change settings by accessing to this IP address directly.

  • Page 9: System Configuration

    3-3. System Configuration Basic Setting: Set camera name and location. Network Setting : IP setting for VR-110A : Static IP / DHCP / ADSL. Wireless LAN setting: Setting wireless LAN configuration RTSP setting : set RTSP port number, time out, concurrent user Media setting : Modify media setting for streaming(Video / Audio) Camera Control : Control camera for PAN/TILT/ZOOM relay, sensor input..

  • Page 10: Network Setting

    Password: ADSL Password Time server: IP address of server that sets, and manages time DDNS server : Once registered with VSST through phone or e-mail, your ID and password will be given. NAT : When using router before VR-110A, click here.
  • Page 11 111111 - 11 - - 11 -...

  • Page 12: Wireless Lan Setting

    From the menu in the left, select WLAN setting, and fill in the information Select “save and restart” button to reset VR-110A automatically and apply changed setting Uplink Port : This option decide whether to use Wireless LAN or Ethernet.

  • Page 13: Rtsp Setting

    3-7. VR-110A RTSP setting From the menu in the left, select RSTP setting, and fill in the information Select “save and restart” button to reset VR-110A automatically and apply changed setting 삭제됨: RTSP number : Port number of RTSP which clients access RTSP timeout : Set the idle time to stop streaming when no response from clients Maximum number of concurrent user.

  • Page 14: Media Setting

    - 14 - 3-8. VR-110A Media setting From the menu in the left, select Media setting, and fill in the information Select “save and restart” button to reset VR-110A automatically and apply changed setting 삭제됨: Frame rate : fps-frame per second Image quality : Decides quality of image.

  • Page 15: Camera Setting

    From the menu in the left, select camera setting, and fill in the information Select “save and restart” button to reset VR-110A automatically and apply changed setting PAN value can be in the range of 0-350. Tilt value can be in the range of 0-90 and Zoom value can...
  • Page 16 161616 - 16 - - 16 - 3-10. VR-110A Current Setting VR-110A’s current value and setting can be viewed by selecting “Current Setting”...

  • Page 17: Customer Support

    System diagram – Using IP router - When using IP router, set up your system in the order of Internet line > modem > Router> PC and VR-110A - VR-11A can be considered as a client, and by having DMZ setting for VR-110A, you can access from...

  • Page 18: Chapter 4 Mediawings

    2. In the play screen, click right mouse button, then select open video 3. type in the url address (ex : rtsp://192.168.120.1/) 4. You can check the IP address in current setting of VR-110A set up 5. play ok to start playing...
  • Page 19 [TCP] 1001 : Port that connects to VR-110A Ex) http://192.168.1201.:1001 / when you type in IP address of Vr-110A, you will go to setting page.(IP and setting screen, and no log-in required) 554 : RTSP Port(Real Time Streaming Port) This is player only port for video play.
  • Page 20 226 File received OK – 1053136 bytes in 10.640 sec ftp: 1053136 bytes sent in 10.55Seconds 99.82Kbytes/sec. Wanring : Do not change setting or turn off the power of VR-110A during firmware upgrade It takes about 1-2 min to finish upgrade. After upgrade,. VR-110A will restart automatically.
  • Page 21 212121 - 21 - - 21 - Product Warranty According to customer protection policy, VSST guarantees the product as followed : Warranty Period : 1 year after the purchase Product Multimedia Network Adaptor Model VR-110A Distributor VSST Manufacturer VSST Date of Serial No.
  • Page 23 222222 - 22 - - 22 -...
