ALLIANCE BL200-bt Quick Start Manual

BL200-bt
List Price: $175.00
Free App Available to Download

Fixture Features:

Body: Solid brass with an aged brass finish
Knuckle: Solid brass with dial adjustment for easy adjustments
Shroud: Brass with a clear glass convex lens and double o-ring gasket
Wire: Industry First, double wire lead pre-connected to the fixture, 16 awg (UL listed), brown
Stake: Plastic ground stake, attached to the fixture (8.5 in; 21.6 cm length)
Warranty: Ten Year Warranty on Integrated Fixture
Certification: Complies with the requirements of UL-1838 and
CAN/CSA-C22.2 No. 250.7. Identified with the ETL and cETL Listed Mark.

Integrated LED Features:

Wattage: 2w - 6w
App Store
Operating Voltage Range: 10v - 14v
Lumen Output: 10lm to 350lm
Beam Spread: 40°
CRI: 80
CCT Options: 2700K, 3000K, 4000K
RGB Options: Unlimited Color Wheel Options with quick preset options for
Red, Green, Blue, Amber and Purple
Google Play
Dimming: Dimming option available for every color choice
Scenes: Preset scenes of Red+Green, Purple+Orange, and Red+White+Blue
· Bluetooth Mesh Technology
· Phone App Driven
· Adjustable Color Temperatures
· Adjustable RGB Color
· Preset Scenes
· Dimming Capable
· Zoning Capable
-25 foot wire lead, pre-stripped for easy wire connection
-18 inch wire lead, LED connection ready

Bluetooth RGB+CCT
