Summary of Contents for Inline COURT DIRECTOR CD100
- Page 1 im Vertrieb von CAMBOARD Electronics CD100 COURT DIRECTOR ™ COURTROOM A / V SWITCHING SYSTEM CD100 COURT DIRECTOR ™ COURTROOM A/V SWITCHING SYSTEM CD110 COURT DIRECTOR ™ STATUS DISPLAY BUTTON (OPTIONAL) CD 1 00 OPERATION MANUAL www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
-
Page 2: Fcc Compliance
Para prevenir un incendio, reemplace solo con el mismo tipo de fusible. CE COMPLIANCE All products exported to Europe by Inline, Inc. after January 1, 1997 have been tested and found to comply with EU Council Directive 89/336/EEC. These devices conform to the following... -
Page 3: Product Overview
/ display devices throughout the courtroom. • Rack Mountable - The CD100 can be mounted in a 1U rack space. © 2000 - INLINE, Inc. CD100 / CD110 Court Director™ System Operation Manual - Preliminary 11/30/2000 www.camboard.de Tel. - Page 4 Input 3 accepts analog video signals from a third computer, or can accept signals from a DVD player, VCR, or other auxiliary device when used with a video scaler. The INLINE IN1403 and IN1404 Video Scalers are recommended for applications requiring superb video scaling for compo- site video, S-Video, component video and RGB video signals.
-
Page 5: Installation
/ or long cable runs. High- resolution VGA extension cables such as the IN8000 Series are recommended for all input and output connections. © 2000 - INLINE, Inc. CD100 / CD110 Court Director™ System Operation Manual - V. 1.0 11/30/2000 www.camboard.de Tel. - Page 6 11.) Turn on the CD100, the VGA source(s), the output device(s), the local monitor(s), and any auxiliary devices. CD100 / CD110 Court Director™ System Operation Manual - V. 1.0 11/30/00 © 2000 - INLINE, Inc. www.camboard.de Tel. 07131 911201 ce-info@camboard.de...
- Page 7 *Newer Mac G3 models (with translucent cases) have 15-Pin HD connectors (pins arranged in 3 rows). Older G3 models (with solid white enclosures) incorporate 15-Pin D connectors (pins arranged in 2 rows). © 2000 - INLINE, Inc. CD100 / CD110 Court Director™ System Operation Manual - V. 1.0 11/30/2000 www.camboard.de...
- Page 8 Vertrieb von CAMBOARD Electronics CD100 / CD110 Court Director™ System Operation Manual - V. 1.0 11/30/00 © 2000 - INLINE, Inc. www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
- Page 9 Pin 2: Ground Pin 3: Receive POWER Universal Power: 90 - 260 VAC, 47 - 63 Hz © 2000 - INLINE, Inc. CD100 / CD110 Court Director™ System Operation Manual - V. 1.0 11/30/2000 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
-
Page 10: Operation
(in memory) so that the adjustment(s) will not have to be repeated once they have been optimized. CD100 / CD110 Court Director™ System Operation Manual - V. 1.0 11/30/00 © 2000 - INLINE, Inc. www.camboard.de Tel. 07131 911201 ce-info@camboard.de... - Page 11 PROJECTOR PORT CONTROL -The Memory Select Buttons can also be used to store and transmit serial ASCII or hex projector control strings to projectors, INLINE products (such as the IN1400 Series Scalers) or other serial controlled AV equipment in RS-232 modes. Projector Port Controls are activated (during power up) through either the front panel controls or via RS-232 remotes (see the Power Up Settings Section on the following page).
-
Page 12: Factory Default Reset
1200 up to 38,400. Note: The baud rate transmitted must match the baud rate selected on the CD100. CD100 / CD110 Court Director™ System Operation Manual - V. 1.0 11/30/00 © 2000 - INLINE, Inc. www.camboard.de Tel. 07131 911201 ce-info@camboard.de... - Page 13 2400 ACIA5 set projector port baud rate to 4800 ACIA6 set projector port baud baud rate to 9600** © 2000 - INLINE, Inc. CD100 / CD110 Court Director™ System Operation Manual - V. 1.0 11/30/2000 www.camboard.de Tel. 07131 911201 ce-info@camboard.de...
- Page 14 OVER? request judge override status PCCx send out projector code for projector memory x (1<=x<=4) CD100 / CD110 Court Director™ System Operation Manual - V. 1.0 11/30/00 © 2000 - INLINE, Inc. www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
- Page 15 (012<=xxx<=063) * This Command List is preliminary. All commands listed in this manual are functional, however, INLINE reserves the right to modify, remove and / or add commands on future product revisions. The commands are not case sensitive.
-
Page 16: Specifications
(1) IN9230: IEC Power Cable, 6’ long (USA only) (1) IN9123B: Rack Ears - For installing the CD100 in a standard 19” equipment rack Operation Manual CD100 / CD110 Court Director™ System Operation Manual - V. 1.0 11/30/00 © 2000 - INLINE, Inc. www.camboard.de Tel. 07131 911201 ce-info@camboard.de... -
Page 17: Troubleshooting
Œ Solution: Verify that the DB-9 cable is connected properly. If problems persist, call INLINE Technical Services at (714) 921-4100 for further assistance. © 2000 - INLINE, Inc. CD100 / CD110 Court Director™ System Operation Manual - V. 1.0 11/30/2000 www.camboard.de... -
Page 18: Warranty
If equipment fails because of such defects and INLINE is notified within two (2) years from the date of shipment, INLINE will, at its option, repair or replace the equipment at its plant, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications.
