- Page 1 User Manual UH-4U 4K HDMI2.0 Switcher 4x1 All Rights Reserved Version: UH-4U(Build2.0)_2018V1.1 www.ute.de...
- Page 2 UH-4U: 4K HDMI2.0 4x1 Switcher Preface Read this user manual carefully before using the product. Pictures are shown in this manual for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact your local dealer or distributor for maintenance assistance.
- Page 3 UH-4U: 4K HDMI2.0 4x1 Switcher SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ⚫...
-
Page 4: Table Of Contents
UH-4U: 4K HDMI2.0 4x1 Switcher Contents 1. Product Introduction to UH-4U ..................1 1.1 Features ......................1 1.2 Package List ...................... 2 2. Panel Description of UH-4U ..................3 2.1 Front Panel ......................3 2.2 Rear Panel ......................4 3. System Connection ..................... 5 3.1 Usage Precaution .................... - Page 5 UH-4U: 4K HDMI2.0 4x1 Switcher 10. Technical Specification .................... 18 11. Panel Drawing ......................19 12. Troubleshooting & Maintenance ................20 13. Customer/ After-sales Service ................21 U.T.E. electronic GmbH & Co. KG www.ute.de...
-
Page 6: Product Introduction To Uh-4U
UH-4U: 4K HDMI2.0 4x1 Switcher 1. Product Introduction to UH-4U The UH-4U is an ultrathin auto switcher with four HDMI video inputs and one HDMI output. This switcher supports HDMI video resolution up to 4Kx2K@60Hz 4:4:4 HDR and multichannel audio. Except passing EDID information from the display, there are multiple built-in EDID settings to simplify an installation. -
Page 7: Package List
UH-4U: 4K HDMI2.0 4x1 Switcher 1.2 Package List 1x UH-4U: 4K HDMI2.0 4x1 Switcher with HDR Support ⚫ 2x Mounting Ears ⚫ 4x Mounting Screws ⚫ 4x Plastic Cushions ⚫ 1x RS232 Cable (3.5mm to DB9) ⚫ 1x IR Remote ⚫... -
Page 8: Panel Description Of Uh-4U
UH-4U: 4K HDMI2.0 4x1 Switcher 2. Panel Description of UH-4U 2.1 Front Panel AUTO SOURCE AUDIO MODE FIRMWARE Figure 2-1 Front Panel UH-4U(Build2.0) ① Auto/Source Button: Press to switch to next input source. ⚫ Press and hold at least three seconds to switch between manual mode and auto ⚫... -
Page 9: Rear Panel
UH-4U: 4K HDMI2.0 4x1 Switcher 2.2 Rear Panel IN 1 IN 2 IN 3 AUDIO RS232 IR IN EDID DC 5V Figure 2-2 Rear Panel UH-4U(Build2.0) ① IN1~IN4: Four type-A female HDMI input ports to connect HDMI sources. The input 4 port supports ARC. -
Page 10: System Connection
UH-4U: 4K HDMI2.0 4x1 Switcher 3. System Connection 3.1 Usage Precaution Make sure all components and accessories included before installation. ⚫ System should be installed in a clean environment with proper temperature and ⚫ humidity. All of the power switches, plugs, sockets, and power cords should be insulated and ⚫... -
Page 11: Connection Procedures
Please adopt qualified HDMI cables compliant with HDMI2.0 for reliable transmission when connecting. 3.4 Application The HDMI2.0 switcher UH-4U has a good application in various occasions, such as computer realm, monitoring, conference room, big screen displaying, television education, command & control center and smart house etc. -
Page 12: Source Button Control
UH-4U: 4K HDMI2.0 4x1 Switcher 4. Source Button Control The button “AUTO/SOURCE” on the front panel can be used to select input source and switch mode. Press and hold the button “AUTO/SOURCE” for 3 seconds or more to switch between the manual and auto modes. (Default: Manual switching.). -
Page 13: Ir Remote Control
UH-4U: 4K HDMI2.0 4x1 Switcher 5. IR Remote Control Please connect an IR receiver to the IR input port; the IR remote is used for signal switching and it can also be used to control source and display devices based on CEC function. -
Page 14: Rs232 Control
UH-4U: 4K HDMI2.0 4x1 Switcher 6. RS232 Control Connect the switcher to the control device (e.g. PC) with RS232 cable and set the parameters in the right manner, the control device is capable to control this switcher by RS232 commands. - Page 15 UH-4U: 4K HDMI2.0 4x1 Switcher The interface of the control software is shown as below: Parameter configuration area Monitoring area, indicates if the command sent works. Command sending area Please set the parameters of COM number, baud rate, data bit, stop bit and the parity bit correctly, then the RS232 commands can be sent in Command Sending Area.
-
Page 16: Rs232 Commands
UH-4U: 4K HDMI2.0 4x1 Switcher 6.2 RS232 Commands Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, then the RS232 commands can be sent in Command Sending Area. Baud rate: 9600;... -
Page 17: Source Device Control
UH-4U: 4K HDMI2.0 4x1 Switcher 6.2.2 Source Device Control Notes: The input source device is required to support CEC. ⚫ Due to the HDMI input 4 port does not support CEC, the source device connected to ⚫ this port can not be controlled by IR remote. -
Page 18: Display Device Control
UH-4U: 4K HDMI2.0 4x1 Switcher 6.2.3 Display Device Control Note: The display device is required to support CEC. Function Command Feedback Example Turn on the display device, e.g. >>TVOn >>TVOn HDTV. Turn off the display device, e.g. >>TVOff >>TVOff HDTV. -
Page 19: Edid Management
UH-4U: 4K HDMI2.0 4x1 Switcher 7. EDID Management 7.1 Predefined EDID Setting The rear panel boasts a 4-pin DIP switch to set the predefined EDID. The ten types of embedded EDID and their corresponding switch status are shown in the below list. -
Page 20: User Defined Edid Setting
UH-4U: 4K HDMI2.0 4x1 Switcher 7.2 User Defined EDID Setting Except directly invoking the embedded EDID, the specific EDID can be customized. There are five EDID can be customized following the below operations. Rename the user defined EDID according the following format. -
Page 21: Arc Mode
ARC, the audio connection diagram is shown below: Speakers ARC AUDIO: Speaker Amplifier IN 1 IN 2 IN 3 AUDIO RS232 IR IN EDID DC 5V Figure 8-1 ARC Connection Diagram of 4K HDMI2.0 Switcher UH-4U U.T.E. electronic GmbH & Co. KG www.ute.de... -
Page 22: Firmware Upgrade
UH-4U: 4K HDMI2.0 4x1 Switcher 9. Firmware Upgrade Please follow the steps as below to upgrade firmware by the Micro-USB port on the rear panel: 1) Prepare the latest upgrade file (.bin) and rename it as “USERAPP.bin” 2) Connect the switcher to the PC with USB cable, and then power on the switcher. -
Page 23: Technical Specification
UH-4U: 4K HDMI2.0 4x1 Switcher 10. Technical Specification Video Input Input (4) HDMI Input Connector (4) Female type-A HDMI HDMI Input Resolution Up to 4Kx2K@60Hz 4:4:4 HDMI Standard HDCP Version Video Output Output (1) HDMI Output Connector (1) Female type-A HDMI... -
Page 24: Panel Drawing
UH-4U: 4K HDMI2.0 4x1 Switcher 11. Panel Drawing U.T.E. electronic GmbH & Co. KG www.ute.de... -
Page 25: Troubleshooting & Maintenance
UH-4U: 4K HDMI2.0 4x1 Switcher 12. Troubleshooting & Maintenance Problems Potential Causes Solutions Colour losing or no video signal output in HDMI display. The connecting cables may Check whether the cables not be connected correctly are connected correctly No HDMI signal output in or it may be broken. -
Page 26: Customer/ After-Sales Service
There terms and conditions may be changed without prior notice. If there appear some problems when running the UH-4U please check and deal with the problems reference to this user manual. Any transport costs are borne by the users during the warranty. - Page 27 UH-4U: 4K HDMI2.0 4x1 Switcher U.T.E. electronic GmbH & Co. KG www.ute.de...
- Page 28 U.T.E. electronic GmbH & Co. KG Tel: +49-2302-28283-0 Fax: +49-2302-28283-10 Email: info@ute.de Website: www.ute.de...
