Guide line to check and repair the safety equipment of the

Robusta Plus Sliding Gate ver. 1.0

Contents

1. Technical data of the Robusta Plus Sliding gate ............................................................................. 1

2. Checklist in case of failure Drive unit C720 / 721 ........................................................................... 2

3. Checklist in case of failure Drive unit C746 / 844 ........................................................................... 3

4. Manual for to check the safety devices of the sliding gates guiding post / lock post .................... 4

5. AERF System (Wireless Band) ......................................................................................................... 9

6. Installation of resistive safety strip at the front of the wing of Robusta Plus sliding gate ........... 11

6.1 Table of required resistive safety strip (SAP code) according the height of the gate ................ 11

6.2 Procedure to connect resistance safety strip to the AERF system ............................................. 12

Electrical drawing safety strips E780 ................................................................................................ 14

Electrical drawing photocells E780 ................................................................................................... 15

1. Technical data of the Robusta Plus Sliding gate

Type of FAAC unit:______________ Dimension:______________ Construction year:_______

Created 11.08.2014:

Approved 11.08.2014:

Bodo Kiesewalter

Table of Contents

Need help?

Do you have a question about the Robusta Plus and is the answer not in the manual?

Questions and answers

Summary of Contents for Betafence Robusta Plus

Page 1: Table Of Contents
5. AERF System (Wireless Band) ......................9 6. Installation of resistive safety strip at the front of the wing of Robusta Plus sliding gate ... 11 6.1 Table of required resistive safety strip (SAP code) according the height of the gate ....11 6.2 Procedure to connect resistance safety strip to the AERF system ..........
Page 2: Checklist In Case Of Failure Drive Unit C720 / 721
2. Checklist in case of failure Drive unit C720 / 721 checked Error analysis by using the status LEDs No LED active Check the fuse of the steering, if necessary replace LED BUS is blinking or off LED is blinking: Photocells are working LED is off: Photocells doesn’t work, check wire connection, if necessary replace the photocell.
Page 3: Checklist In Case Of Failure Drive Unit C746 / 844
Warning light does not blink Check the bulb, if necessary replace it. Lamp stays always on; replace the board of the warning light. Status LEDs of the steering 3. Checklist in case of failure Drive unit C746 / 844 checked Error analysis by using the status LEDs No LED active Check the fuse of the steering, if necessary replace...
Page 4: Manual For To Check The Safety Devices Of The Sliding Gates Guiding Post / Lock Post
Otherwise Check OSE-S unit (Connection box inside the guiding post) (Status LED must be off) if status LED is on check the sensors of the safety edge, if necessary replace the OSE-S unit. Warning light does not blink Check the bulb, if necessary replace it. Lamp stays always on;...
Page 5 4.1 Safety edges For 1 safety edge is required: 1 x rubber profile 1 x Light beam (photocell assembled on top and bottom of the rubber profile) 1 x OSE unit Light beam sensor (top and bottom of the rubber profile) OSE signal processing (Yellow item) Connection wire of OSE unit...
Page 6 The connection cable of the OSE unit has the follow wires: Brown: Power, plus (24V from controller) White: Power, minus (0V from controller) Yellow: Signal (in loop with the AERF receiver, connector 8) (electrical drawing page 15) Green: Signal (input of the controller, connector 6) The photo below shows the “possible”...
Page 7 If 2 OSE units connected in line (serial) and one of it is activated, the other one will activated automatically. Red LED in “ON” status; One OSE unit is activated or fault, one is active too. How to solve the problem: Take a new light beam and connect to the OSE unit.
Page 8 Receiver on the photos below Receiver in work With plastic cap Without plastic cap The upper LED is ON, the signal from transmitter will received, system is working This LED shows the power for the receiver is OK. If it is off, the power is missing / fault Receiver fault, signal (light beam) from transmitter is missing.
Page 9: Aerf System (Wireless Band)
Important, please note: Without the plastic cap the working distance of the photocells are very low, about 2m only. For to check it is required to assemble the plastic cap. A lens is inside the plastic cap for to increase the range. Connection plan of the photocells: 5.
Page 10 5.1.1 DIP-switch SETTINGS Transmitter (component at the wing): Switch 1: off Switch 2: on Switch 3: off Receiver (component at the drive unit): Switch 1 on Switch 2: off Switch 3: on Switch 4: on Switch 5: on 5.1.2 Programming the activation time ATTENTION: First program the activation time, then program transmitters to the receiver 1.
Page 11: Installation Of Resistive Safety Strip At The Front Of The Wing Of Robusta Plus Sliding Gate
6. Installation of resistive safety strip at the front of the wing of Robusta Plus sliding gate If the AERF system doesn’t work as described in point 5.1, the light beam safety strip in front of the wing can changed to a resistive safety edge.
Page 12: Procedure To Connect Resistance Safety Strip To The Aerf System
IMPORTANT NOTE: Replacing the optical resistance safety strip at the front of the wing by a resistance safety strip is under responsibility of the installer. The present instruction guideline is given by Betafence on an informative basis only. 6.2 Procedure to connect resistance safety strip to the AERF system 6.1 Transmitter:...
Page 13 6.2 Receiver: Two of the wire connections have to be changed. The grey wire (connector 6) has changed to connector 3 The blue wire (connector 8) has changed to connector 5 10 11 12 The photo shows the wire (blue and grey) connected to the new position of AERF receiver The dip switch of the receiver has to be changed to the follow position:...
Page 14: Electrical Drawing Safety Strips E780
Electrical drawing safety strips E780 Created 11.08.2014: Approved 11.08.2014: Bodo Kiesewalter...
Page 15: Electrical Drawing Photocells E780
Electrical drawing photocells E780 Created 11.08.2014: Approved 11.08.2014: Bodo Kiesewalter...
