Summary of Contents for STOLLMAN BlueMod+C11/G2
- Page 1 Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference BlueMod+C11/G2 Hardware reference Author: jj Date of Saving: 23.02.07 Ref: BlueRS+C11-G2_HWreference_V1_0.doc Revision: 0.1 Page 1 of 1...
- Page 2 Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference Note This device was developed for the purpose of communication in an office environment. It is intended solely for our industrial clients for physical integration into their own technical products after careful examination by experienced technical personnel for its suitability for the intended purpose.
-
Page 3: Table Of Contents
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference Table of contents Introduction......................5 1.1 Feature Summary ..................5 1.2 Applications ....................6 Block Diagram ....................7 Application Interface ..................8 3.1 Power Supply....................8 3.2 Power-On-Reset ................... 9 3.3 Serial Interface.................... 10 3.4 GPIO Interface.................... - Page 4 Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 5.3.1.1 Deep Sleep state ................... 20 5.3.1.2 Power down state .................. 20 5.3.1.3 Idle state....................20 5.3.1.4 Power Consumption ................21 5.4 RF performance..................22 Enviromental Requirements..................24 5.5 Power-up Time ................... 24 Mechanical Characteristics ................
-
Page 5: Introduction
It addresses developers of hardware environments for BlueMod+C11/G2. For detailed information about software interfaces refer to the software reference manual. The BlueMod+C11/G2 is available with EDR functionality disabled and enabled. For the product with EDR disabled all information given in the following chapters regarding EDR performance and functionality is not valid. -
Page 6: Applications
E + V GmbH Hardware reference 1.2 Applications BlueMod+C11/G2 can be used in different applications. Some typical applications are described in this chapter. For applications requiring an external adapter please refer to other BlueRS+ versions from Stollmann BG/JW: Bitte Kapitel nach Wunsch einfügen Author: jj Date of Saving: 23.02.07... -
Page 7: Block Diagram
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 2 Block Diagram BlueRS+C11/G2 +3V3-PA +3V3 EXT-RES# ARM7 RS-232 (TTL) AT91SAM7S GPIO 256k Single Chip USB 2.0 FS FLASH Class1 JTAG Bluetooth BC04-ROM SRAM TEST Fig. 1 Block Diagram Author: jj Date of Saving: 23.02.07 Ref: BlueRS+C11-G2_HWreference_V1_0.doc... -
Page 8: Application Interface
BlueMod+C11/G2 E + V GmbH Hardware reference 3 Application Interface 3.1 Power Supply The BlueMod+C11/G2 has 2 power supply rails, which always should be kept on the same voltage level. Signal Usage C-13 Supply for digital and low power RF circuitry,... -
Page 9: Power-On-Reset
Excessive noise or too slow current transient response on the supply rails may have an impact on the RF performance. 3.2 Power-On-Reset The BlueMod+C11/G2 is equipped with circuitry for generating Power On Reset and to provide under-voltage supervision. An integrated circuit type Maxim DS1818R provides this functionality. -
Page 10: Serial Interface
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 3.3 Serial Interface The interface functionally corresponds to the norm V.24 / RS-232 but has TTL-level. • Transmission speeds 300 bps – 1,843200 Mbps (asynchronous) • Character representation: 7 to 9 Bit, even, odd, mark, space or no Parity, 1, 1.5 or 2 stop bits •... -
Page 11: Alternate Gpio/Io Functions
Please refer to the ATMEL data sheet AT91SAM7Sxxx Rev. F for complete information. The possibilities depicted in the following chapters are an subset only. The following function blocks may be usable on the BlueMod+C11/G2: 3.5.1 Master/Slave SPI Interface Pin #... -
Page 12: Synchronous Serial Interface
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 3.5.2 Synchronous Serial Interface The Synchonous Serial Interface is capable of handling the protocols I2S, Short Frame Sync, Long Frame Sync and other Telecom protocols. Receiver and transmitter do act independently. Due to multiplexing interdependencies the SSC is only available with the Transmitter clock signal TK used for both directions if the UART IF is enabled. -
Page 13: Pcm Interface
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 3.5.4 PCM interface XXX (JW) For being able to use the PCM interface the HW needs to be altered. At the moment no version with this alteration can be ordered. The PCB layout allows the use of the Bluetooth HCI chips PCM interface at certain GPIO pins for future enhancements by population changes. -
Page 14: Bluetooth Radio Interface
BlueMod+C11/G2 E + V GmbH Hardware reference 3.6 Bluetooth radio Interface The BlueMod+C11/G2 offers 3 population variants for the antenna 1) The BlueMod+C11/G2/-AE variant presents a 50 impedance antenna interface on a Radiall UMP connector, type R107103020. See http://www.radiall.com/ 2) The BlueMod+C11/G2/-AI variant presents an integrated ceramic antenna. -
Page 15: Pin Description
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 4 Pin Description The BlueMod+C11/G2 module is soldered on customers PCB via stamp pins located on the module PCB edges. 4.1 Pin Numbering Top View Author: jj Date of Saving: 23.02.07 Ref: BlueRS+C11-G2_HWreference_V1_0.doc Revision: 0.1... -
Page 16: Pin Description
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 4.2 Pin Description 4.2.1 General Pin Description Signal Dir. Activ Description /EXT_RES Reset low active M0-DTXD Test pin – do not connect GPIO3 () General Purpose IO GPIO0 () General Purpose IO... -
Page 17: Application Specific Pin Description
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 4.2.2 Application Specific Pin Description 4.2.3 SPP Configuration Pin Name SPP function Dir. Active Description GPIO3 Break out generate break GPIO0 GPIO1 Break detect Optional, connect external to RXD special firmware required... -
Page 18: Electrical Characteristics
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 5 Electrical Characteristics 5.1 Absolute Maximum Ratings Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated under “Electrical... -
Page 19: Gpio, Jtag; Serial If And Test Pins
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 5.2.2 GPIO, JTAG; Serial IF and Test Pins Vcc = 3.3V, T = - 40° C to +85° C Symbol Item Condition Limit Unit Low-Level Input Voltage -0.3 High-Level Input Voltage < 8mA Low-Level Output Voltage <... -
Page 20: Power Consumption And Power Down Modes
5.3.1.1 Deep Sleep state The Bluetooth RF is completely deactivated, no paging requests from other Bluetooth devices will be recognized. Only rising control line DTR will activate the BlueMod+C11/G2 and may initiate a Bluetooth link dependent on other parameters. Note: In Deep Sleep state the AT command set is not active, CTS line is low 5.3.1.2 Power down state... -
Page 21: Power Consumption
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 5.3.1.4 Power Consumption Condition Current Consumption MEAN PEAK Deep sleep Power down Idle, all functions available, no Bluetooth link Page Scan 12,1 101,0 Inquiry and Page Scan 12,4 101,0 Bluetooth connected, no data traffic, max. TX PWR (Slave) -
Page 22: Rf Performance
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 5.4 RF performance Vcc = 3.0V to 3.6V, T = - 40°C to +85°C Unit Receiver Frequency [GHz] Limit Spec 2.402 -90,0 -80,0 Sensitivity at 0.1% BER ≤-70 2.441 -90,0 -80,0 2.480... - Page 23 Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference Vcc = 3.0V to 3.6V, Tamb = - 40°C to +85°C Unit Transmitter Frequency [GHz] Limit Spec 2.402 16,0 18,5 19,0 RF transmit power +4 to load, at antenna 2.441 16,0 18,5...
-
Page 24: Enviromental Requirements
-40 to +85 ° C 5.5 Power-up Time The time until the BlueMod+C11/G2 is able to accept link requests or serial data is about TBD seconds after power-up. This time can be reduced to approx. tbd second by parameter change. -
Page 25: Mechanical Characteristics
If the use of the UMP antenna connector is considered, please contact Stollmann for information on accessories like cables, plugs etc. Or look at www.radiall.com for the UMP type family. On the BlueMod+C11/G2 the following receptacle will be populated for RF signal routing, if the BlueMod+C11/G2/-AE variant is ordered. Manufacturer Type... -
Page 26: Recommended Land Pattern
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 6.3 Recommended Land Pattern Land pattern recommended for manual soldering Alternative land pattern recommended for reflow soldering Author: jj Date of Saving: 23.02.07 Ref: BlueRS+C11-G2_HWreference_V1_0.doc Revision: 0.1 Page 26 of 26... -
Page 27: Housing Guidelines
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 6.4 Housing Guidelines The individual case must be checked to decide whether a specific housing is suitable for the use of the internal antenna. A plastic housing must at least fulfill the following requirements: •... -
Page 28: Antenna Issues
This is functional for a BlueMod+C11/G2/-AI integrated into a plastic housing. No additional antenna is required. For an external antenna to be set in, e.g. because the BlueMod+C11/G2 is integrated into a metal housing, the ceramic antenna is replaced by 2 alternative solutions •... - Page 29 Optimal placement The best position to place the BlueMod+C11/G2 on the target PCB is in the upper right corner. This position is optimal concerning antenna interference; radiation pattern and PCB space that has to be keep free for the restricted area.
- Page 30 BlueMod+C11/G2 E + V GmbH Hardware reference When placing the BlueMod+C11/G2 at the right edge of the PCB ensure that the restricted area on the target PCB is free of planes, traces and parts. acceptable, but not optimal placement When placing the BlueMod+C11/G2 on other positions than the right side the complete restricted area should be kept free of planes, traces and parts.
-
Page 31: Safety Guidelines
E + V GmbH Hardware reference 7 Safety Guidelines According to SAR regulation EN 50371-2002 the BlueMod+C11/G2 is not intended to be used in close proximity to the human body. Please refer to above-mentioned regulation for more specific information. In respect to the safety regulation EN 60950-1: 2001 all conductive parts of the BlueMod+C11 are to be classified as SELV circuitry. -
Page 32: Fcc Compliance And Fcc Statement
Consult the dealer or an experienced radio/TV technician for help. The radiated output power of BlueMod+C11/G2 is far below the FCC radio frequency exposure limits. Nevertheless, the BlueMod+C11/G2 shall be used in such a manner, that the potential for human contact during normal operation is minimized. -
Page 33: Rf-Exposure Statement
IC ID: 4957A-C11G2 Since the BlueMod+C11/G2 is a module to be integrated into a for the FCC authority unknown end product, the FCC approval under this ID is a “Limited Modular Approval”, also called LMO. This implies that all OEM’s incorporating the BlueMod+C11/G2 in their end product and wanting to ship to the USA or Canada have to measure spurious emissions according to FCC Part 15.247 in a FCC accredited EMC lab and have to keep... -
Page 34: Rohs Declaration
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 8.3 RoHS Declaration Declaration of environmental compatibility for supplied products: Hereby we declare to our best present knowledge based on declaration of our suppliers that this product do not contain by now the following substances which are banned by Directive 2002/95/EC (RoHS) or if contain a maximum concentration of 0,1% by weight in homogeneous materials for •... -
Page 35: Related Documents
CSR product data book BlueCore 4-ROM BC41B143A April 2006 • Radiall UMP MMP Introduction • Radiall data sheet UMP R107.103.020 • Stollmann BlueMod+C11/G2 Software Manual • Bluetooth SIG RF_TS_EDR.pdf test specification • 10 Ordering Information The BlueRS+C11/G2 is available in the following variants: Name Antenna Art No. - Page 36 Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference system, or to affect its safety or effectiveness. Stollmann customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Stollmann for any damages resulting.
-
Page 37: History
Stollmann BlueMod+C11/G2 E + V GmbH Hardware reference 12 History Version Release Date By Change description 20.10.2006 JJ Initial Document - preliminary 27.10.2006 JJ Updated Alternative GPIO Functionality, Name correction 20.02.2007 JJ Updated to evaluated data Author: jj Date of Saving: 23.02.07 Ref: BlueRS+C11-G2_HWreference_V1_0.doc...
