Action pump 6008 Operating Instructions & Parts Manual

Operating Instructions & Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Action Barrel Pumps
Description
Action hand operated barrel pumps will deliver between eight ounces per stroke
and sixteen ounces per stroke depending on your specific model. The pumps are
designed to fit 3 / " and 2" threaded openings in 15, 30 and 55 gallon barrel and
4
drums. Both pumps are also designed to fit 2
pails. The extension tubes included reach the bottom of 55 gallon barrels. Model
6008 barrel pump is adjustable from 2, 4, 6 or 8 ounces per stroke. Model 6009 is
adjustable from 4, 8, 12 or 16 ounces per stroke. Both pumps have polypropylene
outer bodies and polyethylene inner parts. They are used for pumping water,
water-based liquids and detergents.
Specifications
Flow rate per stroke . . . . . . . . . . . . . . . . . . . . . . . . 8 ounces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 ounces
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 gal. flex 2
Inlet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bung Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2" Polypropylene (PP) . . . . . . . . . . . . . . . . . . . . . . . . . . . 2" (PP)
Suction Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32" Polyethylene (PE) . . . . . . . . . . . . . . . . . . . . . . . . . . . 32" (PE)
(Length & Material)
Packing Gland . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PE
Wetted Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PE & PP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PE & PP
SSU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . SAE 40W Oil @ 70˚F (about 4,000 SSU) . . . . . . . . . . . . . SAE 40W Oil @ 70˚
Max. Temp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140˚F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140˚F
General Safety Information
It is the
WARNING
responsibility of
the user to operate the pump in
conformance with OSHA rules for
dispensing liquids. Pump containers
should be grounded when using with
flammable liquids to avoid static
electricity. Pump should be washed out
before usage since processing
lubricants could contaminate fluids.
1.When using a hand pump (especially
when pumping flammable,
combustible or hazardous liquids)
follow all electrical and safety codes,
as well as the United States
Occupational Safety and Health Act
(OSHA), most recent National
/ " flexspout openings for 5 gallon
5
8
6008
5 / " . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
8
/ " . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1
2
1 / " . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
Electrical Code (NEC), National Fire
Protection, Inc. * (NFPA) Code 30
(Flammable and Combustible Code),
NFPA 56A (Standard for use of
Inhalation Anesthetics), NFPA 77
(Static Electricity), NFPA 78
(Lightning Protection Code), NFPA
80 (Standard for Fire Doors and
Windows), NFPA 251 (Standard
Method of fire Test of Building
Construction), NFPA 704
(Identification of the Fire Hazards of
Materials), other NFPA codes, local
codes and ordinances, as needed in
a particular application
2.Know the pump application,
limitations, and potential hazards.
6008 and 6009
6009
5 / " flex
8
/ "
1
2
1 / "
2
The "WARNING" statements
indicate potential hazardous
conditions for the operator or
equipment. TAKE NECESSARY STEPS
TO PROTECT PERSONNEL AND
EQUIPMENT.
NOTE: Pump should only be used with
liquids compatible with pump
component materials. Consult PUMP
CHEMICAL COMPATIBILITY CHART and
PUMP SPECIFICATIONS. Also, the
chemical supplier should be consulted
regarding any questions of chemical
compatibility, proper and safe use and
handling of chemical. Misapplication of
pump or use of noncompatible liquids
will void warranty.
