- Page 1 Hardware Manual eNet-1553 Part Number: 151B1-00000 ● Cage Code: 4RK27 NAICS: 334118 Alta Data Technologies LLC 4901 Rockaway Blvd, Building A Rio Rancho, NM 87124 USA ● (tel) 505-994-3111 www.altadt.com...
- Page 2 We welcome comments and suggestions. Please contact us at 888-429-1553 (toll free in US) or 505- 994-3111 or visit our web site for support submit forms at www.altadt.com or email us at alta.info@altadt.com or alta.support@altadt.com. eNet-1553 Hardware Manual 151B1-00000-A5 ●...
-
Page 3: Table Of Contents
Signal Capture Discussion ....................9 Host Memory Map ......................10 eNet-1553 Global Registers ..................10 Revision Information...................... 10 Appendix A eNet-1553 Connectors and Cable Assembly Information ......11 Appendix B Setting eNet-1553 Static IP V4 Address ............ 17 eNet-1553 Hardware Manual 151B1-00000-A5 ●... -
Page 4: Enet-1553 Hardware Manual
Hardware Manual Introduction This manual provides detailed hardware information on the eNet-1553 interface product. In addition to this information, the reader may also want to reference the following documents provided on the CD and our Web Site AltaCore Specifications and User Manual: Detailed description of the 1553 ™... -
Page 5: Enet-1553 Description
Description eNet-1553 is an innovative product that provides “remoting” of 1553 operations on is an innovative product that provides “remoting” of 1553 operations on is an innovative product that provides “remoting” of 1553 operations on 10/100/1000 Ethernet IP/UDP local area networks (LAN). -
Page 6: Card Level Specifications
0 to +70C Standard -40 to +85C Extended Temp Parts with –E Option (as applicable). *Note: The eNet-1553 device cannot operate at extended temperature range when the POE option is in use. When using POE, it should only operate in the 0-70C Standard Range. -
Page 7: Power Specifications
Alta’s optional J1 cable (ENETCAB-1553-J1-01) provides a USB connector for power source. Most computers/USB power adapters provide enough power, but some only provide ~500 mAmps and this will not allow eNet-1553 to negotiate to 1000 Ethernet (as gigabit Ethernet draws extra power: about 300-400 mAmps). If using USB power, make sure it can provide at least 1000 mAmp of power (there are many low cost USB-AC power adapters that provide 1000 or 2000 mAmp of USB 5V power). -
Page 8: Mtbf
Please contact your Local Sales Representative or Alta Technical Support for additional information regarding any concerns or questions that may arise regarding MTBF for the this product. Environment: Ground Benign, 25C Table 4. MTBF eNet-1553 MTBF 674,732 hrs eNet-1553 Hardware Manual ● 151B1-00000-A5 Alta Data Technologies LLC www.altadt.com ●... -
Page 9: Enet-1553 Photograph
Photograph The following picture shows the front side of the eNet-1553 product. Status and Activity LEDs Figure 1. eNet-1553 Front Side LED Descriptions Table 5. LED Descriptions Name Description PWR BIT Green = Power On, FGPA Loaded and No Bit Errors Detected... -
Page 10: Enet-1553 Dimensions
Dimensions The following figure provides the dimensions of the eNet-1553 product. All units are in millimeters. Figure 2. eNet-1553 Dimensions (mm) eNet-1553 Hardware Manual ● 151B1-00000-A5 Alta Data Technologies LLC www.altadt.com ●... -
Page 11: Factory Default Ip V4 Address
How to Reset IP Address to Factory Default It can be useful to reset the eNet It can be useful to reset the eNet-1553’s IP address back to the factory default (see ’s IP address back to the factory default (see above) if you have forgotten the device’s address (or for other reasons). -
Page 12: Signal Capture Discussion
Signal Capture Discussion The eNet-1553 HW provides Signal Capture capability on Channel One. The Signal Capture feature uses an analog-to-digital converter (ADC) to capture the electrical signal on the selected 1553 stub (A or B). The Signal Capture feature will capture 2048 samples at a rate of 20MHz, or 50 nanoseconds per sample. -
Page 13: Host Memory Map
Figure 3. Basic Memory Map eNet-1553 Global Registers The first Megabyte of the eNet-1553 memory map contains backplane and global card level settings and status values that affect processing for all channels. Details on Global Registers may be found in the AltaCore-1553 Spec User’s manual. -
Page 14: Appendix A Enet-1553 Connectors And Cable Assembly Information
Appendix A eNet-1553 Connectors and Cable Assembly Information J1 and J2 Connector Information – Alta & Glenair (GA) Part Numbers http://www.glenair.com/index.htm 26-Pin Connectors are Keyed with “A” or “B” pattern. J1 uses the A pattern. J1 Jack: Glenair 801-011-02M10-26SA Female... - Page 15 ~EXT RT ADD ENABLE JTAG TRST TX INHIBIT 1553 CH 1B- IRIG IN JTAG TMS ETHERNET BI_DC- ~FACTORY IP RESET JTAG TCLK ETHERNET BI_DD+ ETHERNET BI_DD- EXT CLK I/O – TTL I/O eNet-1553 Hardware Manual ● 151B1-00000-A5 Alta Data Technologies LLC www.altadt.com ●...
- Page 16 Optional J1 and J2 Cable Assemblies eNet-1553 has two Glenn Air circular connectors labeled J1 (left-most) and J2 (right- most). Connector part numbers and pin-outs are provided in the eNet-1553 hardware manual. Alta provides optional cable assemblies for these connections and their part numbers are: ...
- Page 17 Recommend >1000 MA source, which is common on most computers, but low-end wall adapters may not provide enough power (recommend wall adapter ratings at 2000+ MA). o Pin 1 +5 Vcc; Pin 4 Ground; Data Pins 2 & 3 Not Connected eNet-1553 Hardware Manual ● 151B1-00000-A5 Alta Data Technologies LLC www.altadt.com...
- Page 18 The ENETCAB-J2-01 assembly is show below: eNet-1553 J2 Connector. High Density Female DB26 Jack Figure A-2: Optional ENETCAB-J2-01 Cable Assembly eNet-1553 Hardware Manual ● 151B1-00000-A5 Alta Data Technologies LLC www.altadt.com ●...
- Page 19 ~EXT RT ADD ENABLE Yellow/Black ~TX INHIBIT Brown/Black IRIG IN Blue/Red Red/Blue ~FACTORY IP RESET Green/Black Black/Green Black/Brown EXT CLK I/O – TTL I/O Black/White Table A-2: J2 DB26 Pin-Outs eNet-1553 Hardware Manual ● 151B1-00000-A5 Alta Data Technologies LLC www.altadt.com ●...
-
Page 20: Appendix B Setting Enet-1553 Static Ip V4 Address
You will need to set your local computer’s IP address to match the 192.168.0.X class.class.subnet settings of eNet-1553’s default to communicate to the device (X = host number and can be anything other than eNet-1553’s default value of 128). STEP ONE: Set your Windows Computer’s Static IP V4 Address to Match eNet-1553’s class.class.subnet Values. - Page 21 Here are general instructions (do not have eNet-1553 connected to your computer yet). 1. Open the "Start" menu and click Control Panel. Click the "Network and Internet" link, then the Network and Sharing Center link. Click the "View network connections" link to see your adapters.
- Page 22 Version 4 is selected, the Properties Properties button should brighten and be selectable. utton should brighten and be selectable. Right-Click to for “Properties” or “Status” eNet eNet-1553 Hardware Manual ● 151B1-00000-A5 Alta Data Technologies LLC Alta Data Technologies LLC www.altadt.com...
- Page 23 STEP TWO: Use AltaView to Set eNet : Use AltaView to Set eNet-1553 IP Address. With the latest Alta software installed on your computer, perform the following steps: With the latest Alta software installed on your computer, perform the following steps: With the latest Alta software installed on your computer, perform the following steps: 1.
- Page 24 COMPLETE window. Close AltaView if you want. a. NOW CYCLE POWER on the eNet NOW CYCLE POWER on the eNet-1553 device and it should be ready for device and it should be ready for use with the new IP Address. If you mess up, no worries, you can reset use with the new IP Address.
