SilverStone ECU02 User Manual

Warranty Information

This product has a limited 1 year warranty in North America and Australia.
For information on warranty periods in other regions, please contact your reseller or SilverStone authorized distributor.
本产品自购买之日起，于中国地区（不包含澳门，香港特别行政区）享有一年有限责任保固（部分产品为二年，三年或五年）。
详细保固年限请参照官方网站 https://silverstonetek.com.cn/ 公布之产品型号为依据。
Warranty terms & conditions
1. Product component defects or damages resulted from defective production is covered under warranty.
Defects or damages with the following conditions will be fixed or replaced under SilverStone Technology's
jurisdiction.
a) Usage in accordance with instructions provided in this manual, with no misuse, overuse, or other
inappropriate actions.
b) Damage not caused by natural disaster (thunder, fire, earthquake, flood, salt, wind, insect, animals, etc...)
c) Product is not disassembled, modified, or fixed. Components not disassembled or replaced.
d) Warranty mark/stickers are not removed or broken.
Loss or damages resulted from conditions other than ones listed above are not covered under warranty.
2. Under warranty, SilverStone Technology's maximum liability is limited to the current market value for the
product (depreciated value, excluding shipping, handling, and other fees). SilverStone Technology is not
responsible for other damages or loss associated with the use of product.
3. Under warranty, SilverStone Technology is obligated to repair or replace its defective products. Under no
circumstances will SilverStone Technology be liable for damages in connection with the sale, purchase,
or use including but not limited to loss of data, loss of business, loss of profits, loss of use of the product or
incidental or consequential damage whether or not foreseeable and whether or not based on breach of
warranty, contract or negligence, even if SilverStone Technology has been advised of the possibility of
such damages.
4. Warranty covers only the original purchaser through authorized SilverStone distributors and resellers and
is not transferable to a second hand purchaser.
5. You must provide sales receipt or invoice with clear indication of purchase date to determine warranty
eligibility.
6. If a problem develops during the warranty period, please contact your retailer/reseller/SilverStone
authorized distributors or SilverStone
http://www.silverstonetek.com.
Please note that: (i) You must provide proof of original purchase of the product by a dated itemized receipt;
(ii) You shall bear the cost of shipping (or otherwise transporting) the product to SilverStone authorized
distributors. SilverStone authorized distributors will bear the cost of shipping (or otherwise transporting) the
product back to you after completing the warranty service; (iii) Before you send the product, you must be
issued a Return Merchandise Authorization ("RMA") number from SilverStone. Updated warranty
information will be posted on SilverStone's official website.
Please visit http://www.silverstonetek.com for the latest updates.
Additional info & contacts
For North America (usasupport@silverstonetek.com)
SilverStone Technology in North America may repair or replace defective product with refurbished product that is not
new but has been functionally tested.
Replacement product will be warranted for remainder of the warranty period or thirty days, whichever is longer.
All products should be sent back to the place of purchase if it is within 30 days of purchase, after 30 days,
customers need to initiate RMA procedure with SilverStone Technology in USA by first downloading the "USA
RMA form for end-users" form from the below link and follow its instructions.
http://silverstonetek.com/contactus.php
For Australia only (support@silverstonetek.com)
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Please refer to above "Warranty terms & conditions" for further warranty details.
SilverStone Technology Co., Ltd. 12F No. 168 Jiankang Rd., Zhonghe Dist., New Taipei City 235 Taiwan R.O.C.
+ 886-2-8228-1238 (standard international call charges apply)
For Europe (support.eu@silverstonetek.de)
For China (support@silverstonetek.com.cn)
For all other regions (support@silverstonetek.com)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
电子卡
螺丝
包材
本表格依据 SJ/T 11364 的规定编制。
○ : 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求
以下。
— : 表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限
量要求。且該限用物質為排除項目
G11235510
ECU02 ECU02
USB-C 3.1 PCI
EXPRESS CARD
WITH 20 PIN KEY-A CONNECTOR
Includes one USB 3.1 Gen2 internal 20pin connector
PCIe Gen 3.0 x2 throughput up to 16Gbps
Compliant with eXtensible Host Controller Interface (xHCI) specification Revision 1.1
Compliant with USB Attached SCSI Protocol Revision 1.0 (UASP)
Includes optional low profile slot cover for supporting low profile cases

Introduction

The SilverStone ECU02 is a PCIe Gen 3.0 x2 expansion card with one internal 20pin USB 3.1 Gen2 connector
that supports one USB Type-C port on cases or front panels. It supports UASP (USB Attached SCSI Protocol) for
enhanced performance and operating systems with xHCI (eXtensible Host Controller Interface) can also easily
work with and install ECU02 without the need for any drivers. For those looking to upgrade or add additional
USB 3.1 Gen2 Type-C port to their computer, the ECU02 is a must-have upgrade.

Specifications

Model No. SST-ECU02
Power requirement 5V via SATA 15pin power connector
Form factor Low profile - PCIe 3.0 x2 (16Gbps)
USB Ports Internal 20 pin Key-A connector for USB 3.1 Gen2 Type-C port
USB 3.1 controller ASMEDIA ASM3142
Transmitting Speed USB 3.1 Gen2 (10Gbps), USB 3.1 Gen 1 / USB 3.0 (5Gbps),
USB 2.0 (480Mbps), USB 1.1 (12Mbps)
Power Management Support USB 3.1 and USB 2.0 link power management
Current protection Support over current detection and protection
Operating system support Windows 7 / 8 / 8.1 / 10 (32bit / 64bit) or future release version,
Ubuntu / Linux / Mac OS
Extra UASP and Multiple INs function
Net Weight 47g
Dimension 123mm (W) x 21mm (H) x 105mm (D)
tor
e (xHCI) specification Revision 1.1
