Quick Installation Guide
Broadband Router
Wi-Fi Protected Setup/Push-Button Configuration
Your existing N wireless peripherals must support WPS
feature. Simply activate WPS feature on both devices to
automatically configure the wireless network security.
Model
WL250N-AR
WL300N-AR
WL151N-AR
Please replace the default password as soon as possible
to prevent unauthorized access to your wireless router
Wireless-N
Default IP Address
192.168.2.1
192.168.0.1
Username
admin
admin
Password
1234
admin
Advertisement
Table of Contents
Related Manuals for AmbiCom WL250N-AR
Summary of Contents for AmbiCom WL250N-AR
-
Page 1: Quick Installation Guide
Wi-Fi Protected Setup/Push-Button Configuration Your existing N wireless peripherals must support WPS feature. Simply activate WPS feature on both devices to automatically configure the wireless network security. Model Default IP Address Username Password WL250N-AR 192.168.2.1 admin 1234 WL300N-AR WL151N-AR 192.168.0.1 admin... - Page 2 Setting Up The Router 1. Turn off your ISP broadband modem. Connect an ethernet cable from your DSL/Cable modem to the WAN port on the back of the router. 2. Connect up to 4 non-wireless computers into the LAN port on the back of the router.
- Page 3 In Windows 2000, click Start Settings Control Panel Network and Dial-up Connections. 2. Right-click Local Area Connection and then click Properties. 3. In Windows XP/2000, select Internet Protocol (TCP/IP) and click Properties. 4. The Internet Protocol (TCP/IP) Properties window opened.
- Page 4 8. After you have successfully login, take a moment to familiarize yourself with the router setup interface. 9. Click the Quick Setup Wizard option. 10. Setup your time zone and click Next. 11. Select your broadband connection type. Note: Some DSL users are not required to type the username and password when connecting to the Internet.
- Page 5 Your new deivce will be joining your protected wireless home network within minutes. Technical Support Visit ambicom.com online for latest tips, troubleshooting and updates. Weekdays: 9:00a.m - 6:00p.m. (Monday – Friday. Except holidays) Phone: (408) 321 – 0822 Email: support@ambicom.com...
- Page 6 Disclaimer This product is design for indoor use only. AmbiCom Inc., is not liable for the personal injury and property damage cause by misuse of this product. By using this product, users agree to obey their local regulations, public safety laws, and maintaining safety environment to other user.
- Page 7 However, any implied warranty or merchantability of fitness for a particular purpose is for a period of 1 year on this written warranty. AmbiCom, Inc. reserves the right to change its warranty policy without prior notice. Information provided in this manual is subject to change without prior notice.
- Page 8 cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment. Federal Communication Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure set forth for an uncontrolled environment.
