Limited Warranty; Exclusive Remedies - Master Flow PR1D Application Instructions

6. Mount Fan Assembly
Using four pre-drilled holes in the tandem whole
house fan flange, secure the fan assembly to the
ceiling joists and framing with included fasteners.
The installation should allow a 24" (61cm) clearance
for a fully open exhaust door, vertically and horizon-
tally at the hinged side of the door (Figure 5).
7. Make Electric Connections
At the home's breaker box, turn off electrical power
to the circuit associated with the fan. DO NOT turn
on the power to this circuit until installation is com-
plete. In the attic, remove the cover plate from the
fan's electrical junction box. Insert the source power
cable into the fan junction box through the cable con-
nector provided. Connect the black wire from the
power supply to the fan's black wire. Connect the
white wire from the power supply to the fan's white
wire. Connect the ground wire from the power sup-
ply to the fan's green wire (Figure 6). Firmly secure
all wire connections with included wire nuts. Push all
wire connections into the fan's junction box and
install the cover plate. Replace all previously existing
insulation around the newly installed whole house fan.
CAUTION: Installing electrical power supply to the fan
requires a high level of electrical knowledge. If you
are not experienced at installing residential electrical
wiring or are not familiar with national and local elec-
trical codes, contact a qualified electrician to com-
plete the installation.
8. Install the Grill
From the hallway side of the opening, center the grill
over the opening and fasten the grill to the sheetrock
using the included white-head screws. The screws
must go through the sheetrock and penetrate the
ceiling joists and framing, ensuring the grill is secure-
ly attached (Figure 7). If you cannot penetrate the
joists or framing, utilize the included plastic sheetrock
anchors. To install a sheetrock anchor, gently tap the
anchor into the appropriate hole until it is flush to the
ceiling surface.
9. Operate Fan
Open all windows and interior doors of rooms that
you would like to your Tandem Whole House Fan to
ventilate. Be sure the flues of all fireplaces are
closed. To start tandem the fan, press the on/off but-
ton on the wireless remote control. Press the speed
button to toggle between low or high-speed opera-
tion. Press the "timer" button on the remote control
to activate the 4-hour timer. There will be two audi-
ble beeps to let you know the timer feature is active.
To turn the timer feature off, simply press the timer
button again. There will be a single audible beep sig-
naling the timer is off.
NOTICE: If parts and/or accessories are missing or
this product does not operate correctly, contact
Master Flow ® Technical Services at 1-800-211-9612.
Do not return to store where purchased.
Ratings:
Electrical Requirements: 110/120V AC, 60Hz,
2.4 Amperes
Air Flow: 1,600 CFM max
FCC ID: THE-GC621964
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
interference that may cause undesired operation.

LIMITED WARRANTY

MASTER FLOW
POWERED VENTILATION
PRODUCTS
Limited Warranty
The warranty period listed above starts at the comple-
tion of installation of your Master Flow
Ventilation Products and terminates if either your Master
Flow ® Powered Ventilation Products are replaced or if
the building is sold or transferred (subject to the limited
transferability provision below).
Product
Powered Roof Ventilators
PR1D, CPR1D
PR2D, CPR2D, PRD2H
PRSOLAR1
PR3XD, PR3DHT
Powered Gable Ventilators
CPG2, PG2
PGSOLAR1
PG3X, PG3HT
Whole House Fans
WHFTAN1 .
30BWHFS, WHFS24M, WHFS30M

Exclusive Remedies

For any Master Flow ® Powered Ventilation Product that
does not perform properly as a result of a manufacturing
defect, GAFMC will provide you with replacement product.
If your claim arises during the Labor Protection Plus
period, GAFMC will also reimburse you for the reason-
able costs to remove and reinstall the defective product
(excluding labor and any costs involved with repairing
or replacing other roofing or building materials) but not
to exceed the original retail price of the product.
Decisions as to the extent of repair or replacement
required will be made solely by GAFMC. The remedy
under this warranty is available only for those Master
Flow ® Powered Ventilation Products exhibiting defects at
the time of settlement. The replacement Products as
well as any remaining original Master Flow
Ventilation Products will be warranted only for the origi-
nal warranty period.
Limitations on Coverage
Even if your Master Flow ® Powered Ventilation Products
were not properly installed according to GAFMC's appli-
cation instructions, this limited warranty remains in
effect if your Master Flow ® Powered Ventilation Products
fail to perform as a result of manufacturing defects.
However, GAFMC will NOT compensate you for:
1. Damage to your roof or your building or resulting
from anything other than an inherent manufacturing
defect in your Master Flow ® Powered Ventilation
Products, such as:
a) Improper installation of your Master Flow
Powered Ventilation Products, faulty application
or application not in strict accordance with
GAFMC's printed application instructions.
b) Settlement, movement or defects in the building,
walls, foundation, roof deck, or materials adjacent
to or over which Master Flow ® Powered Ventilation
Products were installed.
2. Damage to your Master Flow
Products or leaking into your building resulting
from factors beyond GAFMC's control, including,
®
but not limited to:
a) Acts of nature, such as hail, storms, or winds.
b) Improper storage or handling of your
Master Flow
3. Damage resulting from the application of overlying or
adjacent roofing materials.
4. Damage resulting from mold growth or condensation.
® Powered
5. Chipping, fading or peeling paint on your Master Flow
Powered Ventilation Products.
6. Labor costs for removing or replacing your Master
Flow
Labor
Warranty Protection
ically provided for above or for any other roofing or
)
Term (yrs) Plus (yrs
building materials.
5 2
5 3
Transferability;
5 2
Remedy for New Owner
10 5
This Limited Warranty may not be transferred or
assigned, directly or indirectly, except for one
transfer as follows:
5 3
5
2
1. Coverage will be automatically extended to only the
10 5
second owner of the property.
2. If the transfer takes place within the first two years,
5
2
the second owner shall be entitled to all benefits
10 5
contained in this warranty.
3. If the transfer takes place after the first two years,
the length of this warranty shall be reduced to the
one-year period after ownership changes (but in no
event longer than the original warranty term).
What You Must Do
To file a claim under this Warranty, you must send a
notice of claim in writing describing your complaint,
together with proof of purchase to establish that you are
the original or second owner and proof of application
date, and photographs of the affected products (if possi-
ble) to: LL Building Products Inc., a subsidiary of
GAFMC, 295 McKoy Rd., Burgaw, NC 28425, within 30
days after your discovery of a potential manufacturing
defect. NOTE: Notice to your contractor or dealer is
® Powered
NOT notice to GAFMC. Within a reasonable time after
proper notification, GAFMC will evaluate your claim and
resolve it in accordance with the terms of this Warranty.
You should have this warranty certificate signed and
dated by your contractor or dealer to help establish proof
of purchase and related information. You should retain
this certificate for your records in the event you need to
file a claim.
Sole and Exclusive Warranty
THIS WARRANTY IS EXCLUSIVE AND REPLACES ALL
OTHER WARRANTIES, CONDITIONS, REPRESENTATIONS
AND GUARANTEES, WHETHER EXPRESS OR IMPLIED,
WHETHER BY STATUTE, AT LAW OR IN EQUITY, INCLUD-
ING THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. This written
®
warranty is your exclusive warranty from GAF Materials
Corporation and represents the SOLE REMEDY available
to any owner of GAFMC's Powered Master Flow
Ventilation Products. GAFMC makes NO OTHER REPRE-
SENTATIONS, CONDITION, GUARANTY OR WARRANTY of
any kind other than that stated herein. GAFMC WILL NOT
BE LIABLE IN ANY EVENT FOR CONSEQUENTIAL, punitive,
special, INCIDENTAL or similar DAMAGES OF ANY KIND,
including DAMAGE TO THE INTERIOR OR EXTERIOR OF
ANY BUILDING, whether for breach of this warranty, negli-
gence, strict liability in tort, or for any other cause.
® Powered Ventilation
® Powered Ventilation Products.
® Powered Ventilation Products except as specif-
®
®
