Summary of Contents for uRADMonitor A3
- Page 1 PRODUCT MANUAL ADVANCED AIR QUALITY MONITORING STATION...
-
Page 2: Table Of Contents
A3 uRADMonitor A3 is an automated, fixed monitoring station that tracks a total of 8 important air quality parameters. It comes in a compact, rugged aluminum enclosure Summary with wall mounting support. The data is exported to the uRADMonitor network and... -
Page 3: Sensors
Estimated for normal usage conditions. Device maintenance is recommended after the shortest sensor lifespan interval (2 years). The purpose of the model A3 detector and of the entire uRADMonitor network is to Estimated for alcohol. monitor chemical and physical factors that can have a negative impact on our health or on the environment. -
Page 4: Product Features
It is an allergenic and a known carcinogenic compound that can cause serious health effects, depending on concentration and exposure. Even in tiny quantities just above 0.1ppm it can irritate the eyes and Picture 4: uRADMonitor A3 motherboard front and bottom view Parameter uRADMonitor... -
Page 5: Connecting And Starting Your A3
Your device must be pre-provisioned with the LoraWAN credentials or configured via USB. • The GSM variant A data SIM card must be inserted in your A3 unit before it can connect over Internet. You can change the APN settings via USB. Picture 5: usbASP Programmer configured for 3.3V Starting with hardware version HW106, the LoRaWAN, Wifi and GSM settings can be customized via the USB connection. -
Page 6: The Alarm
Having the usbAsp AVR Programmer connected to your computer (on Windows you’ll also need the driver) and the avrdude software installed, you are ready to go. Connect the programmer to the uRADMonitor PCB. GND must connect to PIN6 on the PCB. Make sure to match the header pins correctly. -
Page 7: Uradmonitor Api
If you have a Ethernet or a Wifi A3, you can also access the unit directly, by Get device data opening its DHCP assigned LAN IP in your Internet browser: http://data.uradmonitor.com/api/v1/devices/[ID]/[sensor]/[interval] Method: GET Authentification: All calls must be authenticated with user-id and user-key sent in... -
Page 8: Usb Serial Connection Setup
USB Serial connection setup USB Configuration commands Use a standard USB data cable to connect your computer to the uRADMonitor unit The current firmware implements commands for configuration, debugging and data using its USB port: access. Each command must be issued between double quotation marks and any following parameters are separated by a comma. - Page 9 Description: on devices with Ethernet, WIFI or Default value is 0, so the speaker is active by depending on uRADMonitor device type. Currently it GSM, this command sets the server the payload default. is only used by GSM devices, where the value should be sent to.
-
Page 10: Frequently Asked Questions
If it is an Ethernet or a Wifi variant, open your router's admin page and make sure the A3 received a valid IP via DHCP. Try pinging the IP to make sure the connection is properly setup. It it is a GSM/Cellular A3 unit, make sure you've inserted a valid data sim, and the APN is correctly set. -
Page 11: Disclaimer
This Your A3 comes with a warranty that covers any defects in material or workmanship work has a direct impact on the quality of our environment and implicitly, on the under normal use during the warranty period.
