Pro4Tech NanoPen User Manual

Self-contained covert digital camcorder concealed inside a fully functioning standard profile ballpoint pen

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

User Guide

Table of Contents

Need help?

Do you have a question about the NanoPen and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro4Tech NanoPen

Page 3: Table Of Contents
Taking a Snapshot............Indications..............PC Functions............... 21 File Management............Disconnecting the Pen..........NanoPen Manager............. 23 Synchronizing Date and Timestamp......Formatting the NanoPen Memory........ Updating the NanoPen Firmware......... Pairing and Un-Pairing..........Care and Maintenance..........32 Troubleshooting............33 Technical Specification..........34 Warranty..............35 FCC Compliance............
Page 4: Introduction
The Pen can also be left unattended if required, and will still function normally. All NanoPen files are time and date stamped and stored in the internal flash memory in the following formats: Movie = MPEG4 (QVGA 320 x 240) •...
Page 5: Box Contents
Box Contents NanoPen Remote Control key fob Multi-Charger USB Cable Spare ink refills User Guide Reference Card Carrying Case NanoPen User Guide...
Page 6: Parts And Control
Parts and Control Closed View This view shows the Pen in its normal state. Lens location (do not obscure) Microphone location (do not block) NanoPen User Guide...
Page 7: Open View
Open View This view shows the Pen in its open state. All components listed here, are concealed when the Pen is closed. Power on/off button LEDs indicators Micro-USB socket NanoPen User Guide...
Page 8: Remote Control Reference
Remote Control Reference This view shows the Remote Control. Lock button (Taking a snapshot) Alarm button (A/V recording) Unlock button (Audio only recording) LED indicator ocket cover Micro-USB socket NanoPen User Guide...
Page 9: Function Table
Power Twice Button Four Four Locking times times Twice Twice Unlocking Memory Begin Once Once level indication 17 Twice Twice Twice Battery Begin Once Once level indication 18 Twice Twice Twice Twice Twice Twice Take snapshots NanoPen User Guide...
Page 10: Getting Started
Getting Started When you get the NanoPen, check that the box contents are complete, and undamaged. Also take time to read the instructions and familiarize yourself with the basic functions. Then take the following actions: Connect the Pen to a PC using the supplied USB cable and adjust the time stamp using the process described on page 25.
Page 11: Pen
Press on the power button indicated in the open view picture (page 7). When the LEDs flash 5 times, the Pen is on. To switch the Pen off, press the button again until the LEDs flash 2 times. NanoPen User Guide...
Page 12: Charging
When fully charged, the green LED will remain on. This can take up to 3 hours. Note: The supplied charger allows charging from main power (110V-220V AC) or from car cigarette lighter socket (12V DC). USB output 110V-220V AC input 12V DC input NanoPen User Guide...
Page 13: Memory Availability
Remote Control. The LEDs will then indicate the following: Red and Green = battery full Green = ½ to ¾ battery available Red = ¼ to ½ battery available No indication = empty to 1/4 NanoPen User Guide...
Page 14: Writing
Twist and pull off the nib end of the Pen until it seperates. Inside the tip, locate the slot and, using a small screwdriver, turn the screw counter clock wise until the ink cartridge falls free. Replace the empty cartridge and reverse the procedure. NanoPen User Guide...
Page 15: Remote Control
Operation beyond this distance, is not guaranteed. Locking and Unlocking To ensure against the accidental activation of the NanoPen, the Remote Control can be locked, by pressing buttons and together. Locking is confirmed by four vibrations. To unlock the NanoPen, press buttons together.
Page 16: Charging
When fully charged, the green LED will remain on. This can take up to 3 hours. Remote Control Side View Micro-USB socket Note: The supplied charger allows charging from main power (110V-220V AC) or from car cigarette lighter socket (12V DC). NanoPen User Guide...
Page 17: Video And Audio Recording
To cease recording press any button on the Remote Control. The Remote Control will then vibrate twice. Alternatively, if the Remote Control has been lost or damaged, it is possible to start A/V recording by pressing the power button for 10 seconds. NanoPen User Guide...
Page 18: Audio Only Recording
Remote Control. The Remote Control will vibrate once. During recording the Remote Control will vibrate once per 12 minutes. To cease recording press any button on the Remote Control. The Remote Control will then vibrate twice. NanoPen User Guide...
Page 19: Taking A Snapshot
Note: Firstly, make sure that the Pen is switched on and the lens or microphone are not obstructed. To take a snapshot, ensure the Pen's lens is pointed at the subject and press button on the Remote Control. The Remote Control will vibrate twice. NanoPen User Guide...
Page 20: Indications
Green LED confirms normal functions combined with vibrations. For more information see page 9. However, if the memory of the NanoPen is full, starting to recording will cause the Green LED to flash once, and then immediately twice. Any flashing Red LED indicates problem. Generally it will indicate that the Pen is turned off or out of range of the Remote Control or that the memory has become full.
Page 21: Pc Functions
Right-click on the Windows Explore. Windows Explorer opens. Navigate to the NanoPen drive, and do any of the following: Click and drag a file to copy it from the NanoPen to another • location. Right-click a file and select Cut to remove it from the NanoPen, •...
Page 22: Disconnecting The Pen
Click the task bar. A pop-up opens that lists all removable devices currently connected to the PC. In the pop-up, click NanoPen. The pop -up opens informing you that it is safe to remove the hardware. Disconnect the Pen from the USB cable.
Page 23: Nanopen Manager
27. Failure to do this will result in irreparable damage. The NanoPen Manager is a utility used primarily for managing the NanoPen memory utilization, pairing between the NanoPen and a Remote Control and for updating the Firmware. Special...
Page 24 The NanoPen Manager Tab consists of the following elements: Element Description The location of the PC where the NanoPen Drive USB port is mapped. Info Read-only information, including the Firmware version and the NanoPen unique serial number. Levels Indicators for the NanoPen battery status and the percentage of memory used.
Page 25: Synchronizing Date And Timestamp
PC clock when you connect the NanoPen device to the PC USB drive. To Set the NanoPen Date and Timestamp: Connect the NanoPen device to a PC USB port. A New Hardware Device dialog box appears. NanoPen User Guide...
Page 26 . The NanoPen Manager application is opened and the Date and Timestamp are automatically synchronized with the PC clock. Clock Updated, indicating Verify that the Status bar displays that the NanoPen clock and the PC clock are synchronized. NanoPen User Guide...
Page 27: Formatting The Nanopen Memory
NanoPen. Format Disk button and press OK to confirm Click the operation. You are prompted to disconnect the NanoPen from the PC USB drive. Disconnect the Pen from the PC USB drive. NanoPen internal memory is formatted. NanoPen User Guide...
Page 28: Updating The Nanopen Firmware
Updating the NanoPen Firmware From time to time, new versions of the NanoPen Firmware will be released. To Update the NanoPen Firmware: Connect the Pen to the PC USB port. Firmware Update tab. Select the The Firmware Update pane is displayed.
Page 29 A dialog will confirm that the update has been successful. Disconnect the Pen from the PC USB port. • The NanoPen has now been reset and will start with the new Firmware. • The Pen LEDs will blink 5 times after disconnection.
Page 30: Pairing And Un-Pairing
NanoPen. Use the following process to pair between an un-paired Remote Control and the NanoPen. Connect the Pen to the PC. Pairing tab in the NanoPen manager. Open the The Pairing pane is displayed. Click on the Pair Button.
Page 31 Take the Remote Control, and press on any button. You should then be notified that the update has been successful. 6. Disconnect the NanoPen from the USB cable and test that the NanoPen and the Remote Control are paired. If not, then repeat the process.
Page 32: Care And Maintenance
Keeping the NanoPen close whenever possible will keep the USB connector free of dust and moisture. • Store the NanoPen in the original box (closed) in a cool, dry and dust-free place. • Basic cleaning of the NanoPen should be performed with a clean, damp cloth, with the NanoPen turned off.
Page 33: Troubleshooting
NanoPen in its dirty. original container. Nothing happens Follow the unlocking NanoPen is when I try to record...
Page 34: Technical Specification
Li-Ion 360 mAh Auto Shutdown 3 Hours Charging Via USB Remote Control Two-Way RF ISM Band Indication Vibrations, LED PC interface USB 1.1 or higher Time Stamp Date, Time Dimensions Weight 35 gr. 144mm X Ø13.1mm Size NanoPen User Guide...
Page 35: Warranty
The device will be restored to proper operating condition at no charge to you. This includes warranted parts and labor for Pro4Tech defects. Such service, repair or adjustment of the device is assured to the customer, provided the device has not been misused, tampered with, modified...
Page 36: Fcc Compliance
Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Pro4Tech Ltd.) could void the user’s authority to operate the equipment. NanoPen User Guide...
