Simplicity 4560 Parts Manual page 7

Steering Group
REF NO PART NO.
1 1722318SM
2 1722319SM
2 1725024SM
3 1960540SM
4 1722749SM
5 2176440SM
6 1721736ASM
7 1960114SM
8 1933260SM
9 1931211SM
10 1722459SM
11 1722461SM
12 1724470ASM
13 1960032SM
14 1930645SM
15 1664847SM
16 1723604SM
17 1919314SM
18 1931317SM
19 2828372SM
20 1611710SM
21 1960114SM
22 1933988SM
Footnotes
The above parts group applies to the following Mfg. Nos.:
2690621 - Baron XL
2690622 - Baron XL
2690625 - 2420 XL
2690762 - Baron
2690772 - 2421
Briggs and Stratton Yard Power Products Group
Copyright © 2008 by Briggs and Stratton Corporation
Milwaukee, WI, USA. All rights reserved
QTY. DESCRIPTION
1 STEERING WHEEL, Straight Shaft
1 CAP, Steering Wheel, Simplicity Logo
1 CAP, Steering Wheel, Plain
1 PIN, Spring
1 COVER, Black Rubber
2 BUSHING
1 PLATE, Mounting Steering
5 WASHER
2 CAPSCREW, Hex Head Flange Lock, 3/8-16 x 3/4
2 NUT, Hex Whiz Lock, 3/8-16
1 BEARING, Flange
1 SPACER
1 GEAR & SHAFT ASSEMBLY
1 CAPSCREW, Hex Head, 3/8-16 x 1-1/4
1 NUT, Hex Flange Lock, 3/8-16
2 CAPSCREW, Hex Head Taptite, 5/16-18 x 3/4
1 SHAFT ASSEMBLY
1 PIN, Cotter
2 CARRIAGE BOLT, 1/4-20 x 3/4
2 NUT, Hex,1/4-20
1 RING, Clipring Extension
2 WASHER
2 NUT, Push, 5/16
7
TP 400-4560-02-BR-SM
