Aiconn MR868-3G User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Mobile Air
MR868-3G Wireless Router
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the MR868-3G and is the answer not in the manual?

Questions and answers

Summary of Contents for Aiconn MR868-3G

  • Page 1 Mobile Air MR868-3G Wireless Router USER MANUAL...
  • Page 3 Aiconn 3G router Aiconn 3G router Aiconn 3G router Aiconn 3G router Aiconn, 3G router Aiconn 3G router Aiconn 3G δροµολογητή Aiconn 3G router Aiconn 3G router Aiconn 3G router Aiconn 3G router Aiconn 3G router Aiconn 3G router Aiconn...
  • Page 4 Aiconn 3G router Aiconn 3G router Aiconn 3G router Aiconn 3G router Aiconn 3G router Aiconn 3G router...
  • Page 5 Federal Communication Commission Interference Statement IMPORTANT NOTE: Radiation Exposure Statement: FCC Radiation Exposure Statement: The product comply with the US/Canada portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available.

  • Page 6: Table Of Contents

    Table of Contents Advanced Wireless Settings…………..……………………………………………………………………………………… 14-19 Advanced 3G Modem Settings………………...……………………………..………………………………………………..… 20-21 Advanced Firewall Settings……………………………………………………….…………………………………………..…..… 22-26 SMS……………………………………………………………………………………………………………………………………………... 27 Administrator Options………………………………………………………………………………………….…………………………. 28...
  • Page 7 Technical Specifications Dimensions Temperature Interface WLAN Security Function Buttons LED Status Indicators Battery Operating Systems Supported...
  • Page 8 Package Contents MR868-3G Mobile Air Power Adapter USB to mini-USB cable Travel Pouch Caution...
  • Page 9 Charging Methods Warning!
  • Page 10 MR868-3G Mobile Air Light Indicators Mini-B USB Power Input (PC or power adapter) Dongle USB Port Wake Button On/Off Switch Light Indicators WIFI...
  • Page 11 LED Status Blinking Searching Network WIFI Connected to Wi-Fi Network* Blinking Dialling Network Connected to 3G Network* On/Off Power Status* Blinking Low Battery Charging Not charging Blinking Battery Fault NOTICE In order to help conserve battery life, light indicators will automatically turn off after being connected for 10 seconds. To refresh the light indicators, press the Wake button.
  • Page 12 Battery Guide & Charging Tips NOTICE It is recommended to fully charge the battery for a minimum of 8 hours before using the MR868-3G Mobile Air for the first time Tips...
  • Page 13 Antenna Reception 90 degrees. to a maximum of 180 degrees, 120 degrees Warning! Always rotate the dongle upwards with the light indicator panel of the Mobile Router facing upwards no further than 180 degrees. Similarly, do not rotate the dongle downwards beyond 45 degrees. Rotating the dongle beyond these points will damage and void the warranty of the Mobile Router.
  • Page 14 Quick Connection & Setup Connecting to the MR868-3G Mobile Air ○ ○ Plug in your USB 3G modem Move the power switch from OFF > ON . The power LED light will turn on. The Wi-Fi & 3G LED lights will flash.
  • Page 15 Quick & Advanced Configuration To login Open your Web browser. Enter 192.168.6.1 into the address bar and press Enter or the Return key. You will be directed to the login page for the browser interface. Select the ‘ Quick ’ or ‘ Advanced ’ button on the login page. Select the ‘...
  • Page 16 Quick Configuration Settings Quick Settings Wireless Dial code, APN Service the Dial Code for your 3G network the APN service name The dial code and APN service name should be given you to by your network provider. If you are not certain, contact your network provider to find out the dial code & APN Service for your region, plus any additional information you may require.
  • Page 17 Wireless (SSID) This is Wireless Network’s Name. Change it to something unique so that users can easily identify your network. Security - The drop-down menu on the right will give you Security mode options. Select which type of the security feature you would like to enable on your wireless network (OPEN, WEP, or WPA-PSK) NOTICE You may leave your network ‘OPEN’...
  • Page 18 Password & HEX / ASCII Select either HEX or ASII encryption from the drop-down menu on the right and then set the new password for your wireless network. Selecting ‘WPA-PSK’ The configuration window will expand and the following will become visible: Mode / Cypher - This allows you to see the current settings for this configuration.
  • Page 19 Accessing the Advanced Configuration Settings Advanced Settings Main Homepage ○ Advanced login page. ○ Main Menu Quick Settings’ Advanced Settings • Wireless • 3G Modem • Firewall...

  • Page 20: Advanced Wireless Settings

    Advanced Wireless Settings Advanced Settings Wireless’ Note to US model owner: To comply with US FCC regulation, the country selection function has been completely removed from all US models. The above function is for non-US models only. ○ Wireless Network (SSID & Wireless Channels) ○...
  • Page 21 ○ Wireless Network SSID Wireless Network’s Name. Change it to something unique for other users to easily identify your network. Channel - Click on the drop-down menu to choose Wireless Channels between 1-13. TIP: Try changing channels to get around interferences. Preferred channels to use are 1, 6 and 11 since they are considered non-overlapping channels .
  • Page 22 ○ ○ ○ ○ Wireless Security Policy Security Mode Click on the drop-down menu to choose which type of Wireless Security you would like to enable (WEP, WPA-PSK, WPA2-PSK). • Wired Equivalent Privacy (WEP) - is a 64-bit key with 10 hexadecimal digits or a 128-bit WEP key with 26 hexadecimal digits.
  • Page 23 This is a special mode of WPA that provides stronger encryption protection than WEP encryption for users without an enterprise authentication server. ○ ○ ○ ○ ○ WPA-PSK ○ Mode ○ Cipher ○ Passphrase DHCP Settings...
  • Page 24 This is a method for automatically configuring TCP/IP network settings on computers, printers, and other network devices. ○ IP address ○ DNS address The Subnet mask will configure automatically according to the Class rules set by the IP Address Range. IP Address Range Class A : 10.0.0.1 –...
  • Page 25 Power Saving Settings In order to save battery life, the router will enter ‘Sleep Mode’ if there is no data activity (upstream/downstream) over a given period of time. Use can enable/disable this setting, or configure the time period when the router to enters ‘Sleep Mode’.

  • Page 26: Advanced 3G Modem Settings

    Advanced 3G Settings ○ Pin Code Protect ○ Dial Code ○ APN Service ○ 3G Username & Password...
  • Page 27 ○ Pin Code Protect Click ‘Enable’ to enter the Pin Code for your 3G network. This is optional, and only required if your service provider asks you to do so. If your PIN code is “0000” enter 0000. WARNING! ○ Dial Code Enter the Dial Code for your 3G network in this field.

  • Page 28: Advanced Firewall Settings

    Advanced Firewall Settings Advanced Settings Firewall’ ○ Firewall Enable/Disable Setting ○ IP/Port Filtering ○ MAC Filtering ○ VPN Pass-through...
  • Page 29 Firewall Setting Firewall Setting Advanced Setting enable/disable ○ Firewall Enable/Disable Setting ○ Stateful Packet Inspection (SPI) ○ IP/Port Filter ○ MAC Filter...
  • Page 30 IP/Port Filtering Firewall IP/Port Filtering Advanced Settings Enter the Local IP Address Set Protocol (TCP/UDP, or Both) Determine the Port Ranges If you wish to delete an IP Address from the Filter list, simply tick the box next to the address and click the ‘Delete’ button at the bottom of the page.
  • Page 31 MAC Filtering Firewall MAC Filtering Enter the MAC address of the device you want to add. Then click ‘Add’. To delete a MAC address from the list, check the box next to the MAC address and then click on the ‘Delete’ button at the bottom of the page.
  • Page 32 VPN Pass-through Firewall VPN Pass-through enable/disable VPN PPTP Pass-Through VPN IPsec Pass-Through...

  • Page 33: Sms

    SMS’ ○ Phone Num ○ Msg. Content New SMS Notice The SMS feature may not be supported or available to some 3G dongles.

  • Page 34: Administrator Options

    Administrator Options Administrator Administrator’ ○ Change Password ○ Apply Firmware Upgrade ○ Settings Management...
  • Page 35 Change Password Administrator Change Password Enter your old password (default is ‘ admin ’) Enter your new password Confirm your new password Click the ‘Save’ button to save your changes.
  • Page 36 Firmware Upgrade Administrator Firmware Upgrade Choose File Submit Warning Do not apply the firmware upgrade when the battery is low!
  • Page 37 Settings Management Administrator Settings Management Load Default Warning! Do not turn off the router while it resets.
