Option Audio GlobeTrotter EXPRESS 7.2 Quick Start Manual

STATUS INDICATORS
Red LED • – GSM/EDGE (2G)
Blue LED • – UMTS/HSDPA (3G)
LED FLASHING MEANING
• • • Unregistered. Searching for a
• • • network.
• • • Registered on a 3G
Connected or Ready for con-
nection to the Internet on a 3G.
•• •• ••
(UMTS) network. (Packet Switched
Attached)
•••• •••• •••• Connected to the Internet.
Registered on a 2G (GSM)
• • •
network.
Connected or Ready for connec-
•• •• •• tion to the Internet on a 2G net-
work.(Packet Switched Attached)
Connected or Ready for con-
•••• •••• •••• nection to the internet on a 2G
network.
•••••• A problem occurred.
If you have any technical problems with this product, feel free to contact our support team at www.option.com/support/index.shtml
Copyright Option nv © 2006 all rights reserved. No parts may be reproduced without written permission.
Z06.243_GT_EXP_7.2_QS.indd 1-2
GlobeTrotter EXPRESS 7.2
NOTES
Both LEDs flash at the same
time giving a purple colour.
SMS possible. No access to
network.
the Internet.
If connected – this is a UMTS
connection.
This is an HSDPA connection.
SMS possible. No access to
the Internet.
If connected – this is a GPRS
connection.
If connected – this is a EDGE
connection.
Eject the card safely and
try again.

Quick Start Guide 4 / 4

Quick Start Guide
GlobeTrotter EXPRESS 7.2
INSTALLATION AND SETUP
Follow these 5 steps to install your GlobeTrotter EXPRESS 7.2 to make your laptop wireless.
Step 1 – Insert the SIM card into the slot of the GlobeTrotter EXPRESS 7.2 card
Step 2 – Insert the GlobeTrotter EXPRESS 7.2 card into the laptop
GE021xQS-01
GlobeTrotter EXPRESS 7.2
Quick Start Guide 1 / 4 Quick Start Guide 2 / 4
