LG 32UL950 Owner's Manual

Hide thumbs Also See for 32UL950:

Advertisement

Quick Links

OWNER'S MANUAL
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and
retain it for future reference.
32UL950
32BL95U
www.lg.com
Copyright © 2018 LG Electronics Inc. All Rights Reserved.

Advertisement

loading

Related Manuals for LG 32UL950

Summary of Contents for LG 32UL950

  • Page 1 OWNER’S MANUAL LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32UL950 32BL95U www.lg.com Copyright © 2018 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of OPEN SOURCE SOFTWARE NOTICE HDMI Licensing Administrator, Inc.

  • Page 3: Open Source Software Notice

    Supported Drivers and Software LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
  • Page 4 Product and Button Description Moving and Lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. • Place the monitor in the original box or packing material before attempting to move it. •...
  • Page 5 Installing on a Table Adjusting the Stand Height • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm away from Place the monitor mounted on the stand base in an upright position. the wall to ensure sufficient ventilation.
  • Page 6 Using the Kensington Lock Installing the Wall Mount Plate The connector for the Kensington security system is located at the bottom of the monitor. This monitor meets the specifications for the wall mount plate or other compatible devices. For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website NOTE at http://www.kensington.com.
  • Page 7 Back of the Monitor NOTE • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non-standard screws. • The wall mount kit includes the installation guide and all necessary parts.

  • Page 8: Using The Monitor

    USING THE MONITOR DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • Illustrations in this manual may differ from the actual product. NOTE Press the joystick button, go to [Settings] [Input], and then select the input option. •...
  • Page 9 Connecting AV Devices CAUTION Cautions When Using a USB Device HDMI Connection • A USB device with an automatic recognition program installed, or that uses its own driver, may not be recognized. HDMI transmits digital video and audio signals from your AV device to the monitor. •...
  • Page 10 Case 2: HDMI/DP (DisplayPort) Input Peripheral devices connected to the USB IN port can be controlled from the PC. [To use USB C-A cable] Please connect the USB C-A cable to the PC. To use USB 3.0, connect the USB C-A cable of the product to the PC. [PC] [Monitor] (Sold separately)

  • Page 11: User Settings

    USER SETTINGS NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. Activating the Main Menu Press the joystick button on the bottom of the monitor. Move the joystick up/down and left/right to set the options. Press the joystick button once more to exit the main menu.
  • Page 12 Main Menu Features Main Menu Description [Input] Sets input mode. Power Off [Power Off] Turns off the monitor. [Settings] Configures the screen settings. Settings Input Exit [Game Mode] Sets the game mode for gaming. [Exit] Exits the main menu. Game Mode Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the [Settings].
  • Page 13 Quick Settings [Settings] > [Quick Settings] Description [Brightness] Adjusts the contrast and brightness of the screen. [Contrast] [Volume] Adjusts the volume level. NOTE • You can adjust [Mute] / [Unmute] by moving the joystick button to in the [Volume] menu. Input [Settings] >...
  • Page 14 [PBP] [Settings] > [Input] Description [Input List] Displays the screens of two input modes on one monitor. [Main Input List] Please refer to the table below for possible PBP combinations. [Sub Input List] Sub Screen (Right) PBP Connection Main Screen (Left) [Aspect Ratio] Adjusts the aspect ratio of the screen.
  • Page 15 Picture NOTE • The [Picture Mode] that can be set depends on the Input signal. [[Picture Mode] on SDR (Non HDR) signal] [Settings] > [Picture] Description [Picture Mode] [Custom] Allows the user to adjust each element. [Vivid] Heightens contrast, brightness and sharpness to display vivid images. [HDR Effect] Optimizes the screen for high dynamic range.
  • Page 16 [[Picture Mode] on HDR signal] [Settings] > [Picture] Description [Picture Mode] [Custom] Allows the user to adjust each element. [Vivid] Optimized the screen for HDR vivid colors. [Standard] Optimized the screen for HDR standard. [Cinema] Optimized the screen for HDR video. [FPS] This HDR mode is optimized for FPS games.
  • Page 17 [Settings] > [Picture] Description [Picture Adjust] [Brightness] Adjusts the color contrast and brightness of the screen. [Contrast] [Sharpness] Adjusts the sharpness of the screen. [SUPER RESOLUTION+] [High] Optimizes the screen for crystal clear images. Best for high-definition video or games. [Middle] Optimizes the screen for comfortable viewing, with images at the middle level between the low and high modes.
  • Page 18 [Settings] > [Picture] Description [Game Adjust] [Response Time] Sets a response time for displayed pictures based on the movement of the picture on the screen. For a normal environment, it is recommended that you use [Fast]. When there is a lot of motion, it is recommended that you use [Faster]. Setting to [Faster] may cause image sticking.
  • Page 19 [Settings] > [Picture] Description [Color Adjust] [Gamma] [Mode 1], [Mode 2], The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the lighter the image becomes. [Mode 3] [Mode 4] If you do not need to adjust the gamma settings, select [Mode 4]. [Color Temp] Set your own color temperature.
  • Page 20 General [Settings] > [General] Description [Language] Sets the menu screen to the desired language. [SMART ENERGY SAVING] Conserve energy by using luminance compensation algorithm. [High] Saves energy using the high-efficiency [SMART ENERGY SAVING] feature. [Low] Saves energy using the low-efficiency [SMART ENERGY SAVING] feature. [Off] Disables the feature.
  • Page 21 [Settings] > [General] Description [HDMI ULTRA HD Deep Color] Provides sharper images when connected to a device supporting ULTRA HD Deep Color. 4K @ 60 Hz Support Format Color Depth / Chroma Sampling Resolution Frame rate (Hz) 8 bit 10 bit YCbCr 4:2:0 YCbCr 4:2:2 59.94...
  • Page 22 [Settings] > [General] Description [Buzzer] This feature lets you set the sound generated from Buzzer when your monitor powers on. [OSD Lock] This feature disables the configuration and adjustment of menus. [Information] The following display information will be shown; [Serial Number], [Total Power On Time], [Resolution]. [Reset to Initial Settings] [Do you want to reset your settings?] [Yes]...

  • Page 23: Troubleshooting

    TROUBLESHOOTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. • Is the power LED on? Check the power cable connection and press the power button. •...
  • Page 24 Have you installed the display driver? Be sure to install the display driver from the display driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http:// www.lg.com. • Make sure to check if the graphics card supports Plug and Play function.

  • Page 25: Product Specification

    PRODUCT SPECIFICATION Color Depth 8-bit / 10-bit color is supported. Resolution Max Resolution 3840 x 2160 @ 60 Hz Recommended Resolution 3840 x 2160 @ 60 Hz Power Sources Power Rating 19.5 V 9.0 A Power Consumption Operating Mode: 70 W (Typical)* (Typical) Sleep Mode: ≤...
  • Page 26 Factory Support Mode (Preset Mode, PC) DisplayPort/Thunderbolt 3/ USB-C Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 45.00 60.00 1280 x 800...
  • Page 27 HDMI Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 45.00 60.00 1280 x 800 49.702 59.810 1280 x 1024 63.981...
  • Page 28 HDMI Timing (Video) Preset Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) 480P 31.5 720P 1080P 67.5 2160P...
  • Page 29 This device can be used in all regions. Read the owner's manual (CD) carefully and keep it at hand. Please note that the label attached to the product provides information for technical support. Model Serial No.
