1. INTRODUCTION
Thank you for selecting this Bluetooth headset BHT-106R. This
Bluetooth headset uses 2.4GHz Bluetooth technology for
communication – without the inconvenience of wires.
This Bluetooth headset is compatible with devices that support the
Bluetooth Headset and Hands-free profiles. To be able to use the headset
with a mobile phone, the phone needs to have build-in Bluetooth
technology, or a compatible Bluetooth phone adaptor.
2. KEY DIAGRAM
Volume +
Earhook
LED
Function Button
Button
Earhook need to be
Be able to curve
plugged into the hole
of earhook on the
back
1. Function Button － Power on/off
Volume -
2. Volume+ Button － Volume Up
Button
3. Volume- Button － Volume Down
3. GETTING START
To use your headset, please follow these simple steps :
1. Charge the BHT-106R's battery
2. Switch your headset BHT-106R on
3. Pair your headset BHT-106R with a Bluetooth Telephone
I. CHARGE YOUR HEADSET BATTERY
When the headset BHT-106R is on and the battery becomes low,
the LED will blink green color for 3 minutes to remind you the
headset needs to be recharged, at the moment , please use AC
charger to charge the battery immediately .
II. SWITCH YOUR HEADSET ON/OFF
turn on : press and hold Function Button simultaneously until LED
blinks red (approximate 7 seconds) ,then release .
turn off : press and hold Function Button simultaneously until LED
blinks green (approximate 2 seconds),then release .
III. PAIR YOUR HEADSET WITH A BLUETOOTH TELEPHONE
Prior to using your headset for the first time, you must pair it with
another Bluetooth device, such as a mobile telephone. The Bluetooth
connection between the headset and your phone can be established by
setting up a paired link. With a paired link , the phone remembers the
headset's ID, and these 2 items are then paired together – eliminating
the need to repeat the setup process with future use. Only paired
devices can utilize Auto Answer and Auto-Transfer functions. The
information below describes pairing instructions for a typical device.
For specific instructions, refer to your mobile telephone user guide.
Advertisement
Summary of Contents for Smartlink BHT-106R
- Page 1 I. CHARGE YOUR HEADSET BATTERY with a mobile phone, the phone needs to have build-in Bluetooth When the headset BHT-106R is on and the battery becomes low, technology, or a compatible Bluetooth phone adaptor. the LED will blink green color for 3 minutes to remind you the headset needs to be recharged, at the moment , please use AC charger to charge the battery immediately .
- Page 2 The battery is not fully charged when you get Select BHT-106R on the menu of your phone, enter the PIN the headset. Before you can use the headset, you need to charge code 0000 , when your phone menu prompts you, and the the headset’s self-contained battery for up to 3~4 hours.
- Page 3 LED blinks Red rapidly, then release the “Function to determine the voice be transferred to mobile phone or To turn on BHT-106R , Button” to turn on BHT-106R Press and hold “FunctionButton” for 10 seconds until the LED blinks Red/ Green rapidly, then headset .
- Page 4 Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
