- Page 1 BPC-203 Series Fanless Box PC with Intel® BayTrail Processors User’s Guide BPC-203 Series User’s Manual...
-
Page 2: Table Of Contents
Overview ....................24 Main Menu ....................25 Advanced Menu..................27 Boot Menu ....................37 Security Menu ................... 38 Save & Exit Menu ..................39 Chapter 4 Driver Installation .................. 41 BPC-203 Series User’s Manual... -
Page 3: Figures
Figure 5 Connect USB mouse & keyboard ..........20 Figure 6 RJ45/ RS-232 connector .............. 21 Figure 7 Com port ..................21 Figure 8 Turning on the system ..............22 Figure 10 VESA mounting (1) ..............23 Figure 10 VESA mounting (2) ..............23 BPC-203 Series User’s Manual... -
Page 4: Tables
Tables Tables Table 1 BPC-203 Series Specification ............13 Table 2 BIOS Main Menu ................25 Table 3 BIOS Main Menu ................26 Table 4 Advanced Menu ................27 Table 5 Advanced Menu – Display Configuration ........28 Table 6 Advanced Menu – Super IO Configuration ........29 Table 7 Advanced Menu –... -
Page 5: Safety Instructions
The product chassis may be hot when the system is working. Please do not touch the surface before turn off the system power and wait for about 5 minutes until the system cools down. BPC-203 Series User’s Manual... -
Page 6: When Working Inside A Computer
Also, before connecting a cable, make sure both connectors are correctly oriented and aligned. CAUTION Do not attempt to service the system yourself except as explained in this user’s guide. Follow installation and troubleshooting instructions closely. BPC-203 Series User’s Manual... -
Page 7: Preventing Electrostatic Discharge
Handle components and boards with care. Don’t touch the components or contacts on a board. Hold a board by its edges or by its metal mounting bracket. Do not handle or store system boards near strong electrostatic, electromagnetic, magnetic, or radioactive fields. BPC-203 Series User’s Manual... -
Page 8: Instructions For Lithium Battery
Do not dispose of lithium batteries in domestic waste. Dispose of the battery according to the local regulations dealing with the disposal of these special materials (e.g. to the collecting points for disposal of batteries) BPC-203 Series User’s Manual... -
Page 9: Preface
(take adequate measures) at their own expense. The user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. BPC-203 Series User’s Manual... -
Page 10: Maintaining Your Computer
Buildings in which climate is controlled usually maintain an acceptable level of humidity for system equipment. However, if a system is located in an unusually BPC-203 Series User’s Manual... - Page 11 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. BPC-203 Series User’s Manual...
-
Page 12: Chapter 1 Introduction
Chapter 1 Introduction Overview The BPC-203 series is a fanless Box PC that is ideal for space critical applications. This embedded hardware platform is designed with Intel® BayTrail Processors which provide with the excellent performance. System is supported with DDR3L SO-DIMM up to 4GB. -
Page 13: Product Specifications
Humidity Storage: -20°C to 80°C, 0%-90%, non-condensing Dimensions 184 x 56 x 110 mm (W x H x D) Weight 1600 g Mounting VESA-mount ( Optional) Certifications CE, FCC Class A Table 1 BPC-203 Series Specification BPC-203 Series User’s Manual... -
Page 14: System Tour
The hard disk LED blinks when data is being written into or read from the HDD. Phone Jack (Line-Out & MIC-In) Line out is used to connect the system’s audio out signal to amplified speakers or headphones. MIC-IN is designed to connect the microphone used for video conferencing, BPC-203 Series User’s Manual... - Page 15 The USB (Universal Serial Bus) port is compatible with USB devices such as keyboards, mouse devices, cameras, and hard disk drives. USB allows many devices to run simultaneously on a single computer, with some peripheral acting as additional plug-in sites or hubs. BPC-203 Series User’s Manual...
-
Page 16: Figure 2 Rear Panel
The slot is used for attaching a lock-and-cable apparatus. Locks are generally secured in place with a key or combination lock attached to a rubberized metal cable. HDMI HDMI connector for display output External power switch The external power switch allows powering ON and OFF the system. BPC-203 Series User’s Manual... - Page 17 Chapter 1 D-Sub 15 pin VGA connector for display output Clear CMOS 1x reset button for clear CMOS. Support RS-232 BPC-203 Series User’s Manual...
-
Page 18: Mechanical Dimensions
Chapter 1 Mechanical Dimensions Dimension: 183.86 x 55.98 x 109.5 mm (W x H x D) Figure 3 Mechanical Dimensions BPC-203 Series User’s Manual... -
Page 19: Chapter 2 Getting Started
Figure 4 VGA/ HDMI NOTE When the system reboots without connecting the DP/VGA/HDMI, there might be no image on screen when you insert the DP/VGA/HDMI cable. Please pressing <Ctrl>+<Alt>+<F4> simultaneously to show the image on screen. BPC-203 Series User’s Manual... -
Page 20: Figure 5 Connect Usb Mouse & Keyboard
Chapter 2 Connect USB mouse & keyboard Your BPC-203 series does not come with a keyboard and mouse connector, but you can use any USB keyboard or mouse to connect with your computer. USB 3.0 Figure 5 Connect USB mouse & keyboard NOTE Using a third-party USB mouse or keyboard may require software drivers. -
Page 21: Figure 6 Rj45/ Rs-232 Connector
Chapter 2 RS-232 Connector Pin Assignment Figure 6 RJ45/ RS-232 connector COM Ports COM ports with the pin definitions. COM 1 Figure 7 Com port BPC-203 Series User’s Manual... -
Page 22: Figure 8 Turning On The System
Connect the power cable to the power adapter Connect the power cable to a power outlet Press the power switch on the front panel to turn on the system DC Jack Power Switch Figure 8 Turning on the system BPC-203 Series User’s Manual... -
Page 23: Mounting Your Pc To A Monitor
To fasten the metal shelf, your monitor must comply with VESA75 or VESA100 standard. Place the BPC-203 series onto the monitor and secure it with the heat dissipating fins properly on VESA mount kit as shown below. Figure 10 VESA mounting (2) -
Page 24: Chapter 3 Ami Bios Setup
It is possible for the CMOS battery to fail, which will cause data loss in the CMOS only. If this happens you will need to reconfigure your BIOS settings. BPC-203 Series User’s Manual... -
Page 25: Main Menu
F3: Optimized Defaults Memory Information F4 Save & Exit ESC Exit Total Size 2048 MB (DDR3L) Frequency 1066 MHz System date [Fri 05/02/2014] System time [00:05:23] Access Level Administrator Version 2.16.1242. Copyright (C) 2012 American Megatrends, Inc. BPC-203 Series User’s Manual... -
Page 26: Table 3 Bios Main Menu
F3: Optimized Defaults F4 Save & Exit Memory Information ESC Exit Total Size 2048 MB (DDR3L) Frequency 1066 MHz System date [Fri 05/02/2014] System time [00:05:23] Access Level Administrator Version 2.16.1242. Copyright (C) 2012 American Megatrends, Inc. BPC-203 Series User’s Manual... -
Page 27: Advanced Menu
> USB Configuration ESC Exit >TPM Configuration > H/W Monitor Version 2.16.1242. Copyright (C) 2012 American Megatrends, Inc. Onboard LAN 1 Controller Options: Disabled, Enabled Onboard LAN 1 Boot Options: Disabled, Enabled Audio Controller Options: Disabled, Enabled BPC-203 Series User’s Manual... -
Page 28: Table 5 Advanced Menu - Display Configuration
Options: 64 M, 96 M, 128MB, 160 M, 192 M, 224 M, 256MB, 288 M, 320 M , 352 M , 384 M , 416 M , 448 M , 480 M , 512M DVMT Total Gfx Mem Options: 128MB, 256MB, MAX IGFX-Boot Type Options: VBIOS Default, CRT, HDMI BPC-203 Series User’s Manual... -
Page 29: Table 6 Advanced Menu - Super Io Configuration
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; Serial Port 1 Type Options: RS232, RS422, RS485 BPC-203 Series User’s Manual... -
Page 30: Table 8 Advanced Menu - Super Io Configuration - Serial Port
IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12; Serial Port 2 Type Options: RS232 BPC-203 Series User’s Manual... -
Page 31: Table 9 Advanced Menu -Cpu Chipset Configuration
Intel Virtualization Technology [Disabled] ESC Exit Version 2.16.1242. Copyright (C) 2012 American Megatrends, Inc. EIST Options: Disabled, Enabled Limit CPUID Maximum Options: Disabled, Enabled Execute Disable Bit Options: Disabled, Enabled Intel Virtualization Technology Options: Disabled, Enabled BPC-203 Series User’s Manual... -
Page 32: Table 10 Advanced Menu -Sata Configuration
Port 1 [ Enabled ] F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.16.1242. Copyright (C) 2012, American Megatrends, Inc. SATA Options: Disabled, Enabled SATA Mode Options: AHCI , IDE Port 1 Options: Disabled, Enabled BPC-203 Series User’s Manual... -
Page 33: Table 11 Advanced Menu -Usb Configuration
Options: Disabled, Enabled, Auto xHCI Legacy Support Options: Disabled, Enabled xHCI Hand-off Options: Disabled, Enabled EHCI Hand-off Options: Disabled, Enabled USB Mass Storage Driver Support Options: Disabled, Enabled Silicon-Power PMAP Options: Auto, Floppy, Forced FDD, Hard Disk, CD-ROM BPC-203 Series User’s Manual... -
Page 34: Table 12 Advanced Menu -Tpm Configuration
Security Device Support [Disabled] F1: General Help Current Status Information F2: Previous Values F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.16.1242. Copyright (C) 2012 American Megatrends, Inc. Security Device Support Options: Disabled, Enabled BPC-203 Series User’s Manual... -
Page 35: Table 13 Advanced Menu -H/W Monitor
System Temperature : +42 C F2: Previous Values +VCORE : +0.729V F3: Optimized Defaults +VIN : +12.268V F4 Save & Exit : +5.066V ESC Exit +VMEN : +1.349V Version 2.16.1242. Copyright (C) 2012 American Megatrends, Inc. BPC-203 Series User’s Manual... -
Page 36: Table 14 Power Management Configuration
Power Saving Mode Options: Disabled, EUP Enabled Resume By PCIE Device Options: Disabled, Enabled Resume By RTC Alarm Options: Disabled, Enabled Resume By Ring Device Options: Disabled, Enabled Watchdog Timer Configuration WDT Function 【Disabled】 ■ Options: Disabled, Enabled BPC-203 Series User’s Manual... -
Page 37: Boot Menu
Options: Disabled, Enabled CSM Support Options: Disabled, Enabled Boot Option Filter Options: UEFI and Legacy, Legacy only, UEFI only Boot Option # 1 Options: Disabled, IBA GE Slot 00C8 v1410 Network Device BBS Priorities Options: Disabled BPC-203 Series User’s Manual... -
Page 38: Security Menu
F2: Previous Values The password length must be in the following range: F3: Optimized Defaults Minimum Length F4 Save & Exit Maximum length ESC Exit Administrator Password User Password Version 2.16.1242. Copyright (C) 2012, American Megatrends, Inc. BPC-203 Series User’s Manual... -
Page 39: Save & Exit Menu
Save Options Enter: Select Save Changes +- Change Opt. Discard Changes F1: General Help F2: Previous Values Restore Defaults F3: Optimized Defaults F4 Save & Exit ESC Exit Version 2.16.1242. Copyright (C) 2012, American Megatrends, Inc. BPC-203 Series User’s Manual... - Page 40 Load Optimal Default values for all the setup values. This option allows you to load failsafe default values for each of the parameters on the Setup menus, which will provide the most stable performance settings. The F8 key can be used for this operation. BPC-203 Series User’s Manual...
-
Page 41: Chapter 4 Driver Installation
You can download the drivers for the BPC-203 series from the our website and install as instructed there. For other operating systems, please contact us.
