Summary of Contents for 3Gate 1710D PLUS

  • Page 4 NOTICE Check this manual content for your safety before it start LCD monitor ● This manual could not copy of full or parts content. ● It can be different this manual content or products according to main function improve and option. ●...
  • Page 5 SAFETY INSTALLS LCD MONITOR Guide installation LCD monitor ● Do not expose the LCD monitor to hot place ● Periodically wipe its surface with a soft and dry clot. ● Do not close up opening hole any material it may cause fire due to temperature rise to inside ●...
  • Page 6 SAFETY INSTALLS LCD MONITOR Related in power notice ● Do not use the LCD monitor if power cord or outlet has been damaged. ● Make sure to hold the plug not the cord or do not hold the plug with hands wet.
  • Page 7 SAFETY INSTALLS LCD MONITOR Blue) can be seen in some case. These are LCD panel features as this is not a default. This cannot be returned or refunded, as they are not related with monitor function.
  • Page 8 FEATURES OF LCD MONITOR ● As we used LCD(Liquid Crystal Display) panel and slim design, you can use effectively in a small space. ● If you connect LCD monitor to computer information is exchanged each other through communication method which called DDC and help user set best-fitted resolution and frequency.
  • Page 9 LCD MONITOR'S COMPONENT LCD monitor deserve are consisted of component which are necessary to use LCD monitor. LCD Monitor Power Cable DC 12V Adapter D-SUB RGB Cable User's Manual DVI Digital Cable(Option)
  • Page 10: Front View

    EACH PART OF FUNCTION & NAME Front View ꋎ TFT-LCD It is display the screen. ꋏ AUTO Button It will be automatically adjusted to the most suitable condition. ꋐ MENU Button It is display OSD functions to the screen. ꋑ POWER Button Turn on /off the monitor.
  • Page 11 EACH PART OF FUNCTION & NAME ꋓ UP Button Menu moves to the up direction and phase value. In case of DVI LCD monitor, you should press "Source" button and it adjusted DVI function or RGB(Analog) function.
  • Page 12: Rear View

    EACH PART OF FUNCTION & NAME Rear View ꋎ DC Input Jack: (D/C 12V) ꋏ DVI-D Connector It should connect DVI cable to the graphic card of slot. In case of dual DVI, DVI slot are located. ꋐ D-SUB RGB Connector It shall connect D-SUB RGB cable to the graphic card of slot.
  • Page 13 EACH PART OF FUNCTION & NAME In case of dual DVI, from left side D/C jack, DVI-2, DVI-1, D-SUB RGB slot. As emitting power hole is for emitting power efficiently which occurs during various components and LCD panel operating if may cause problem in case you block it. Please do not put water or any substance inside.
  • Page 14 CONNECTING PC TO THE LCD MONITOR Connecting LCD Monitor With PC ꋎ PC & the monitor power are off. ꋏ Connect the D-SUB RGB cable to PC. ꋐ Connect the adapter to the monitor D/C jack. ꋑ PC & monitor power is on after connect line between PC and monitor. ꋒ...
  • Page 15 CONNECTING PC TO THE LCD MONITOR In case of monitor that supports graphic card and DVI, it is better not to connect D-SUB RGB cable. There may occur problem such as recognizing monitor as 2 PCs in operation system or not recognizing DVI in basis status.
  • Page 16 CONNECTING PC TO THE LCD MONITOR Connect monitor cable before put stand to the back cover. ꋎ Remove back cable cover of 2 bolts. ꋏ Put LCD monitor stable place and connect D-SUB RGB cable to the D-SUB RGB slot before assemble it. ꋐ...
  • Page 17 INSTALLATION DRIVER ꋎ Monitor Driver If you connect LCD monitor, windows recognize as a plug & play monitor. If you use plug & play monitor, there are no different in function and screen quality. ꋏ Hand Operated Setting (Example : Windows XP) Go to web page and down load driver into the PC.
  • Page 18 OSD SCREEN ADJUST & SELECTION You can change screen use by OSD button. Do press OSD button if you need change it. OSD Panel Adjustment ꋎ Press menu button it will be display OSD screen. ꋏ Press (DOWN) or (UP) button, go to item bar if you want change setting item value and press menu again.
  • Page 19 RGB & DVI INPUT SIGANL SELECTION ꋎ After press (Source) button, it will be display RGB and DVI on the screen. In case computer VGA card does not support DVI ▶ function it is impossible to connect DVI cable and cannot output screen.
  • Page 20: Color Menu

    OSD MENU ADJUST Color Menu ▶ Contrast Change contrast to the screen. ▶ Brightness Change brightness to the screen. ▶ Gamma Change gamma rate. ▶ Color Temp Change color temperature to the screen. ▶ User Change R/G/B ratio. ▶ Exit Finished setting.
  • Page 21 OSD MENU ADJUST Picture ▶ H.Position Change horizontal location value. ▶ V.Position Change vertical location value. ▶ Phase Change screen clearness value. ▶ Clock Change screen clock value. ▶ Sharpness Change scaling value. ▶ Exit Finished setting. In case of LCD, it has 1280x1024 pixel and shows optimum screen in 1280x1024 in below resolution.
  • Page 22: Function Menu

    OSD MENU ADJUST Function Menu ▶ Auto Adjust Adjust location and screen automatical. ▶ Auto Color Adjust color and brightness automatical. ▶ Exit Finished setting. In case of monitor that supports DVI function, it does not operate all menu function. Color and screen functions are operating only RGB mode.
  • Page 23: Osd Menu

    OSD MENU ADJUST OSD Menu OSD menu can be change 6 different language such English, French, ▶ Language Germany, Spain, Italy, Korean. Default setting language is Enlish. Adjust horizontal location value ▶ OSD H.Pos OSD. ▶ OSD V.Pos Adjust vertical location value of OSD. It can set OSD time to disappear or visible OSD menu on the screen if you ▶...
  • Page 24: Misc Menu

    OSD MENU ADJUST Misc Menu ▶ Signal Source Select input source DVI & RGB. Select resolution at DOS ▶ Mode Select (640x400, 720x400) ▶ Reset Back to factory setting value. ▶ Exit Finished Setting.
  • Page 25 SUPPORT MODE & FREQUENCY Support mode and frequency Support Resolution Vertical Frequency (Hz) 640 x 480 60/72/75Hz 800 x 600 60/70/72/75Hz 1024 x 768 60/70/72/75Hz IBM PC 1280 x 1024 60/70/72/75Hz DOS 640 x 480 60Hz DOS 720 x 400 70Hz 640 x480 66.67Hz...
  • Page 26 CHECK THIS ONE BEFORE CALL FOR A/S Problem Check Point Answer Display screen Check Plug and Check monitor cable and PC is on not work. monitor cable. power saving mode. Does power button In case of No signal letter - work correctly? appeared it is a phenomenon that signal transmitted from VGA cord...
  • Page 27: Light Indicator

    LCD MONITOR SPECIFICATION ITEM SPECIFICATION Panel 17", 19“ TFT-LCD Panel Max. Resolution 1280 X 1024 (SXGA) D-SUB RGB Input signal Digital DVI (Option) Input 100~240V Output DC 12V 17" : ON : 44Watt / OFF : 3Watt Consumption Power 19" : ON : 50watt / OFF : 3Watt 17"...
