AS 1500 Intelligent RF AP Quick Installation Guide
Multi-Antenna Airespace Access Point Quick Installation Guide
This Guide contains several sections allowing you to install an AS 1500 (AS-1500-ABG-INT) Airespace
Access Point. This model contains internal 802.11a and 802.11b/g antennas and no connectors for
optional external antennas.
•
Overview
•
Step 1: Collecting Required Tools and Supplies
•
Step 2: Configuring the Airespace AP Before Installation
•
Step 3: Preparing Mounting Locations
•
Step 4: Mounting the Airespace APs
•
Step 5: Returning MAC Information
•
Planning Notes
•
FCC Statements for Airespace APs
ATTENTION!
Special Considerations
While Airespace Access Points have been engineered for easy installation, there are some guidelines
that are very important to the end users:
•
PLACE Airespace Access Points NO MORE THAN 140 FEET APART FROM EACH OTHER. Placing
Airespace APs further apart almost always results in poor coverage.
•
DO NOT MOUNT Airespace APs OUTSIDE BUILDINGS.
•
DO NOT MOUNT Airespace APs ON BUILDING PERIMETER WALLS UNLESS THE OPERATOR
WANTS TO PROVIDE COVERAGE OUTSIDE THE BUILDING.
•
MAKE SURE that plenum-mounted Airespace APs are powered using Power Over Ethernet (POE)
and use only the metal brackets (not the Ceiling-Mount Base or the Hanging-Ceiling Clips) to
comply with safety regulations.
•
MAKE SURE THAT THE Airespace Access Points ARE INSTALLED VERTI-
CALLY. Airespace Access Points ARE DESIGNED TO BE INSTALLED
VERTICALLY, either standing up in a plenum or hanging from a ceiling,
to create the largest coverage area per Airespace AP. Hanging the
Airespace AP from the ceiling provides the best RF coverage.
12/29/04
90-100tbd-000 Rev 1 (Preliminary 3)
Print This Document
© 2004 All Rights Reserved.
PRELIMINARY 3
System Release x.x

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS 1500 and is the answer not in the manual?

Questions and answers

Related Manuals for Airespace AS 1500

Summary of Contents for Airespace AS 1500

  • Page 1 Multi-Antenna Airespace Access Point Quick Installation Guide System Release x.x Print This Document This Guide contains several sections allowing you to install an AS 1500 (AS-1500-ABG-INT) Airespace Access Point. This model contains internal 802.11a and 802.11b/g antennas and no connectors for optional external antennas.

  • Page 2: Step 1: Collecting Required Tools And Supplies

    Overview Overview This guide is designed to provide you with the information needed to mount AS 1500 Airespace Access Points (Airespace APs). Airespace APs are part of the innovative Airespace Wireless Enterprise Platform (Airespace System), and require no manual configuration after they are mounted.
  • Page 3 The following procedures are designed to make sure that your Airespace AP physical installation goes smoothly and that initial operation is as expected. If you are unable to prepare your Airespace AP for deployment, this Step also describes RMA (Return Material Authorization) procedures.
  • Page 4 If everything works correctly (the GREEN LED is on and the RED LED is off), disconnect the Airespace AP and take it to its final destination and install it as described in this document. If your Airespace AP fails this visual test, refer to RMA Procedures in the Airespace Product Guide to return your Airespace APs.

  • Page 5: Step 3: Preparing Mounting Locations

    Master. A Master Airespace Switch or Appliance should only be used for configuring Airespace APs and not in a working network. Note that the Master Airespace Switch or Appliance is normally not used in a deployed network, so the Master Airespace Switch or Appliance setting is automatically disabled upon reboot or AireOS code upgrade.
  • Page 6 Route the CAT-5, optional power supply, optional external antenna cable(s), and optional Kensington MicroSaver Security cables to where they can plug into the Airespace AP. Make sure to leave about 6 inches (15 cm) of slack in the cables for future modifications.

  • Page 7: Step 4: Mounting The Airespace Aps

    Using the supplied or optional separately-orderable Airespace AP mounting kits, mount each Airespace AP in its indicated location, oriented as shown on the map. Note that you can mount the Airespace APs in the ceiling plenum or below the ceiling, but the Airespace APs perform best when mounted below the ceiling.
  • Page 8 Information. Projection Wall Mount (Details TBD) Projection Wall Mount When you are mounting the Airespace AP out from a wall (flat sides along the wall or hallway), use an optional factory-orderable projection wall-mount L-bracket. • Before proceeding, gently screw the two factory-supplied screws and spring washers into the bottom of the Airespace AP.
  • Page 9 Figure - Assembling the Mounting Screws and Spring Washers to the Airespace AP • Copy the MAC address(es) from the label(s) on the Airespace AP onto the corresponding location on the map. MAC addresses have the format 000B85xxxxxx. • You have already attached the projection wall-mount L-bracket to the wall in...
  • Page 10 Ceiling-Mount Slotted Clips (Details TBD) Ceiling-Mount Slotted Clips When you are mounting the Airespace AP on the extruded aluminium rails of a hanging ceiling requiring a slotted connector, use the ceiling-mount slotted clips to mount the Airespace AP as shown in the following figure and as described below: •...

  • Page 11: Step 5: Returning Mac Information

    802.11a LEDs lit), the Airespace AP begins broadcasting its beacon signal(s). When this happens, complete the installation as quickly as possible to remove yourself from within 8 inches (20 cm) of the Airespace AP to comply with FCC RF radiation exposure guidelines.

  • Page 12: Planning Notes

    When you are powering the Airespace AP from AC power, route the power supply cable from the AC convenience outlet to the Airespace AP. Make sure you secure the AC power plug so it will be difficult for people to pull on the power cord or unplug the power supply from the AC power outlet.

  • Page 13: Fcc Statements For Airespace Aps

    FCC Statements for Airespace APs FCC Statements for Airespace APs This section includes the following FCC statements for the Airespace AP: • Class A Statement • RF Radiation Hazard Warning • Non-Modification Statement • Deployment Statement Class A Statement Class A Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 14: Safety Considerations

    FCC certification of this product is not allowed. Installers of the radio and end users of the Airespace Wireless Enterprise Platform must adhere to the installation instructions provided in this manual.
