Summary of Contents for Safelinq SmartLinQ Mobile
-
Page 1: Table Of Contents
R&TTE Directive 7.2 Button description The Safelinq service LED’s and Connectors Introduction Operating your SmartLinQ Mobile Features 9.1 Switching your SmartLinQ Mobile on/off Components 9.2 Call/Answer Name of Each Part 9.3 Adjust the volume Battery Assembly/Disassembly 9.4 Make a phone call 5.1 Battery Assembly... -
Page 2: Precautions And Notices For Safety
Precautions and Notices for Safety Please ensure that you use your handset correctly after reading the safety instructions. Precautions • Turn your phone off in a potentially • Do not remodel, disassemble, or repair explosive atmosphere. your phone on your own. •... -
Page 3: R&Tte Directive
Declaration of Conformity to R&TTE Directive 1999/5/EC This equipment fulfils the R&TTE directive (Council Directive 1999/5/EC). European States qualified under wireless approvals: Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, The Netherlands, Portugal, Spain, Sweden, and the United Kingdom... -
Page 4: The Safelinq Service
The SmartLinQ Mobile has been exclusively developed by Safelinq. For the full details of the functionality of your SmartLinQ Mobile go to www.safelinq.com. It should be noted that the SmartLinQ Mobile will only operate in combination with a Safelinq subscription. -
Page 5: Introduction
1. Introduction The SmartLinQ Mobile is a powerful GPS location device which is small in size and lightweight. It is designed for personal security and has an inbuilt emergency call button as well as a motion sensor. Both these features ensure direct contact to your chosen control centre or emergency number should you encounter a difficult or threatening situation. -
Page 6: Features
2. Features GPS (Global positioning system) Receiver Emergency button Motion sensor alert Low battery alert Speed sensor alert Four pre-programmable buttons Auto answer... -
Page 7: Components
3. Components 1 SmartLinQ Mobile Use an approved Safelinq charger and battery. 2 Battery Pack Do not use non genuine parts as it could damage 3 Handsfree headset the battery or cause an explosion. 4 AC-power adapter 5 This Manual... -
Page 8: Name Of Each Part
4. Name of Each Part Earphone jack Button Lock Volume GSM LED Speaker power LED GPS LED Emergency button Call/Answer Power/Hang up Microphone Pre-Programmable buttons Power adapter/connector... -
Page 9: Battery Assembly/Disassembly
5. Battery Assembly/Disassembly 5.1 BATTERY ASSEMBLY 1 Fit the battery pack correctly into the groove 2 Slide it all the way as indicated by the arrow, and lock the battery button into place. 5.2 BATTERY DISASSEMBLY Release the battery disassembly button in the direction indicated by the arrow and remove the battery. -
Page 10: Installing The Sim Card
SIM card is facing downwards. Close the SIM card holder and move it to the left to lock. 2 Slide the battery back in at the top of the SmartLinQ Mobile and push it down to lock it into position. -
Page 11: Buttons
7. Buttons 7.1 BUTTON OVERVIEW The phone panel consists of nine buttons. • Power/Hang up Button • Call/Answer Button • Emergency Button • Four pre-programmable Buttons • Volume Button • Lock Button... -
Page 12: Button Description
7.2 BUTTON DESCRIPTION Call/Answer Power/Hang up • To make a call. • To turn on. Press this button after pressing one of the pre- Press for 3 seconds until you hear the power- programmable buttons and hearing a beep. on melody. •... - Page 13 7. Buttons Pre-programmable buttons To call the number programmed behind one of the four pre-programmable buttons, press this button wait for a beep and then press the Call/Answer button. Volume • To increase the volume of a call. Press the upper part of the volume button. •...
-
Page 14: Led's And Connectors
GSM connection, the LED will flash quickly. charged. Once charged, the Power LED will light up continuously. • If the SmartLinQ Mobile is connected to the GSM network, the LED will flash slowly. GPS LED While the SmartLinQ Mobile is searching for a GPS Headset connector connection, the GPS LED will flash quickly. -
Page 15: Operating Your Smartlinq Mobile
9. Operating your SmartLinQ Mobile 9.1 SWITCHING YOUR SMARTLINQ MOBILE ON/OFF • To turn on: Press the Power/Hang up button at least for 3 seconds, it will turn on. The GSM LED will flash quickly until the SmartLinQ Mobile registers to the GSM network. After successful registration the GSM LED will flash slowly. -
Page 16: Adjust The Volume
9.4 MAKE A PHONE CALL • You can store four pre-programmed numbers in your SmartLinQ Mobile. • When you want to call one of the numbers, first press the relevant short dial button, wait for the beep and then press the Call/Answer button •... -
Page 17: Emergency
9. Operating your SmartLinQ Mobile 9.5 EMERGENCY The SmartLinQ Mobile support an emergency function. You can make an emergency call in the following way: 1 If you slide up Emergency button, the phone will sequentially dial the four pre-programmed numbers. If no one answers the call will be diverted to your chosen control centre. -
Page 18: Auto Answer
• The following two conditions are to be satisfied for Auto Answer to be operational: 1 Auto Answer function is activated on the Safelinq service. 2 When an incoming number corresponds to a number stored in pre-programmed button 1 or 2. -
Page 19: Technical Specification
10. Technical Specification Earphone jack Button Lock Volume GSM LED Speaker power LED GPS LED Emergency button Call/Answer Power/Hang up Microphone Pre-Programmable buttons Power adapter/connector... - Page 20 General Dimension (mm – H/W/D) 86 x 46 x 16.8 mm Weight (g) Hardware GPS Baseband SIRF GSC3F Band Quad band GSM 850/900/1800/1900 Receiver 20 x 11 mm Speaker 20 x 11 mm Screen Indicator light x 3 Charge light GSM status indicator light GPS status indicator light Keyboard backlight...
- Page 21 10. Technical Specification System Interface Proprietary Earphone Interface 2.5 mm jack RF Test Interface For use by mobile network operators for RF network testing. Temperature Normal working conditions: -10 to 55˚C Limited working conditions: 55 to 65˚C Software Ring tone 16 polyphonric MIDI for incoming calls Voice Codec FR,EFR,HR,AMR...
- Page 22 Over the air command settings from the Safelinq server using the Safelinq proprietary protocol. Motion Sensor When activated, sends alert information when the sensor detects certain changes in the movement of the device. Speed Sensor When activated, sends alert information when the speed threshold is met.
-
Page 23: Troubleshooting And Safety Info
11. Troubleshooting and Safety info TROUBLESHOOTING Problem Problem The location of the SmartLinQ Mobile cannot be After the SmartLinQ Mobile is turned on, the GSM found. LED continually flashes rapidly Reason Reason The SmartLinQ Mobile is outside satellite coverage. The SIM card is not inserted. - Page 24 • Switch off the SmartLinQ Mobile if near SmartLinQ Mobile is charging. medical equipment. If you are unable to switch the SmartLinQ Mobile off, please remove the battery for 3 seconds and then replace back on the SmartLinQ Mobile. The SmartLinQ Mobile will now be switched off.
- Page 26 SAR INFORMATION The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types GT100 (FCC ID: XMR-16182010002) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the ear is 0.773 W/kg and when properly worn on the body is 0.856 W/kg.
