WIRELESS IP CAMERA
SETUP AND USER MANUAL
Thank you for choosing electriQ.
Please read this user manual before using this item and
keep it safe for future reference.
V isit our page
www.electriQ.co.uk
for our entire range of
electricals

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DOGCAM720 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ElectrIQ DOGCAM720

Summary of Contents for ElectrIQ DOGCAM720

  • Page 1 WIRELESS IP CAMERA SETUP AND USER MANUAL Thank you for choosing electriQ. Please read this user manual before using this item and keep it safe for future reference. V isit our page www.electriQ.co.uk for our entire range of electricals...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS  Read all instructions. All user guidelines must be read before the device is used.  Retain the instructions for further use.  For indoor use only. Do not position the unit where it would be subjected to extreme moisture, temperature, or dust.
  • Page 3 INTRODUCTION Thank you for purchasing an electriQ Wifi controlled device. INSTALLATION OF APP Before installation download the YOOSEE app either using the QR codes below or searching in your chosen app store. ANDROID REGISTER WITH THE APP Once the app has loaded select the option for Quick Register.
  • Page 4 You will then be prompted to register using your mobile phone number or email address, verify the address / phone number given and create a password (Enter the password in both boxes) A verification code will be sent to your phone or email which must be input into the app to complete registration.
  • Page 5 CONNECTING THE CAMERA TO YOUR WIRELESS NETWORK Please note the camera can only be connected to a 2.4ghz network. If your router is also able to operate at 5ghz (Dualband), the 2.4ghz MUST be given a different name (SSID) to the 5ghz network and the connection made to the 2.4ghz network only.
  • Page 6 Once the camera is bleeping, return to the app on your phone and press the + icon in the top right hand corner Press the option to “Add new device” Press the option for Fast Networking. Select your 2.4ghz WIFI network from the drop down list and enter the password for your network.
  • Page 7 Press on the access point created by the camera which will be labelled “GM_AP_******” The phone will then disconnect from your wifi network, and will connect to the network created If the app is unable to create the connection, it will bring up a message, asking you to swap the internet connection manually.
  • Page 8 USING THE APP - OVERVIEW ALL DEVICE SCREEN 1: Scan QR code from friend for device sharing 2: Change the name of the camera 3: Add a new camera 4: Share device with a friend / create QR code 5: N/A 5 6 7 6: Playback from SD card in camera...
  • Page 9 While on the camera view screen you can pan and tilt the image by sliding your finger across the image. A pinch action can also be used to zoom in and out on the image.
  • Page 10 ALL DEVICES SCREEN SHARING THE DEVICE WITH FRIENDS AND FAMILY Once your camera is set up it can be shared using Button 4 on the All Devices screen. This will create a QR Example code which can then be scanned on the other persons phone.

  • Page 11: Camera Settings

    CAMERA SETTINGS The camera settings can be accessed using button 7 in the All Devices Screen. Device Information: Shows details of the camera’s firmware and internet connection Time Settings: Allows the timezone and time to be changed. Picture and Sound: Allows the Video format to be changed between PAL and NTSC.

  • Page 12: App Settings

    APP SETTINGS The App Settings can be accessed using Button 11 on the All Devices Screen. System Settings: Allows the settings for the system to be changed. This includes autostarting the app when your phone is started, Default settings for monitoring via the app, and changing the response of the phone when the alarm is triggered.
  • Page 13 ACCESSING THE CAMERA WITH A PC The camera can also be accessed on a windows PC using the CMS app available from http://www.yoosee.co Before installing the app, ensure the camera is connected to the same network as your computer, either by first following the setup through the app.

  • Page 14: Preview Screen

    CONTROLS Preview: View what is currently been recorded by the cameras connected. Playback: View what has been recorded through the app. Allows the date and time of the recording to be selected. Log: View events that have happened on the camera /App.

  • Page 15: Playback Screen

    Mute: Turn sound on / off from the chosen camera. Screen PTZ: Change between using the controls on the left to pan and tilt the camera, and been able to drag the mouse on the picture to pan and tilt. Page Left and Right: Scroll through the pages of camera views from Camera 1 onwards.
  • Page 16 PLAYBACK THROUGH PC Through the app, you are able to playback videos recorded both within the app onto the PC, and footage saved on the camera itself. PLAYBACK OF RECORDINGS ON THE PC On the left hand side of the screen select the date you require to view, and press the search button below.

  • Page 17: Electriq Uk Support

    We cannot guarentee the availability of all features described on all platforms and hardware combinations. electriQ UK SUPPORT www.electriQ.co.uk/support Service Line: 0871 620 1057 Office hours: 9AM - 5PM Monday to Friday www.electriQ.co.uk...
