Iono MKR User Guide
November 2018
Revision 002
IMMS13X Iono MKR
a general-purpose, professional input/output module based on Arduino MKR boards

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IMMS13X Iono MKR and is the answer not in the manual?

Questions and answers

Summary of Contents for Sfera Labs IMMS13X Iono MKR

  • Page 1 Iono MKR User Guide November 2018 Revision 002 IMMS13X Iono MKR a general-purpose, professional input/output module based on Arduino MKR boards
...
  • Page 2: Table Of Contents

    Safety information Qualified personnel Hazard levels Safety instructions General safety instructions Battery Introduction Features Usage and connections Device identification Power supply Multi-mode inputs Analog mode Digital mode DI5 and DI6 digital inputs Analog output Relay digital outputs RS-485 serial port Mapping Hardware Installation Opening the case...
  • Page 3 Safety instructions Set-up Conformity Information CANADA RCM AUSTRALIA / NEW ZEALAND Iono MKR User Guide...
  • Page 4 Please download and read the Sfera Labs Terms and Conditions document available at: http://www.sferalabs.cc Iono and Sfera Labs are trademarks of Sfera Labs S.r.l. Other brands and names may be claimed as the property of others.
 Copyright © 2018 Sfera Labs S.r.l. All rights reserved.
  • Page 5: Safety Information

    Safety information Carefully and fully read this user guide before installation and retain it for future reference. Qualified personnel The product described in this manual must be operated only by personnel qualified for the specific task and installation environment, in accordance with all relevant documentation and safety instructions.
  • Page 6: Safety Instructions

    Safety instructions General safety instructions Protect the unit against moisture, dirt and any kind of damage during transport, storage and operation. Do not operate the unit outside the specified technical data. Never open the housing. If not otherwise specified, install in closed housing (e.g. distribution cabinet).
  • Page 7 WARNING Improper handling of lithium batteries can result in an explosion of the batteries and/or release of harmful substances. Worn-out or defective batteries can compromise the function of this product. Replace the RTC lithium battery before it is completely discharged. The lithium battery must be replaced only with an identical battery.
  • Page 8: Introduction

    Introduction Iono MKR combines the ease of use of the Arduino platform with multiple input and output interfaces; the result is a rugged, safe, reliable and easy to connect module, suited for installation both in industrial and residential environments. Iono MKR ships without any Arduino board, so you can use your preferred Arduino MKR board, as far as it is fully compatible with the Arduino MKR pinout and fits the Iono MKR case.
  • Page 9: Features

    Features The Iono MKR modules key features are: ✓ 12÷28Vdc power supply, with surge and reverse polarity protection, and 1.1A resettable fuse ✓ compatible with 3.3V operating voltage Arduino MKR boards. Currently the following boards are supported: Arduino MKR WiFi 1010, Arduino MKR1000 WiFi (with headers), Arduino MKR ZERO, Arduino MKR GSM 1400, Arduino MKR FOX 1200, Arduino MKR WAN 1300 ✓...
  • Page 10: Usage And Connections

    Usage and connections CONNECTION EXAMPLE Iono MKR User Guide...
  • Page 11: Device Identification

    Device identification The device can be identified with the information provided in the rating and identification plate, permanently attached to the side of the case. EXAMPLE RATING AND IDENTIFICATION PLATE Power supply Iono MKR can be powered with DC voltage only: ✓...
  • Page 12 input/output lines, or for 1-Wire or Wiegand support, you can move jumpers J4 (DI6) and J5 (DI5) to the BYP position. NOTICE Note that, with the jumpers in the BYP position, you should limit the voltage applied to DI5 or DI6 between +0V and +5V (TTL level). Exceeding this voltage range will result in damage to the Arduino board and Iono MKR.
  • Page 13: Analog Output

    DI5-DI6 JUMPERS POSITION Analog output Iono MKR features a 0÷10V output (AO1) which can be controlled by the DAC0 pin of the Arduino board; the 0÷3.3V range of the DAC0 pin is converted to a 0÷10V output voltage. This is a sink/source output (the current direction at this output can be both positive and negative).
  • Page 14 A 120 Ohm termination resistor between A and B can be enabled installing jumper J3. RS-485 JUMPERS SCHEMATIC RS-485 JUMPERS POSITION Iono MKR User Guide...
  • Page 15: Mapping

    Mapping The following table shows the mapping of the inputs and outputs of the Iono MKR module to the related pins of the Arduino platform. Iono MKR inputs and outputs Arduino pins DI1 – AV1 – AI1 DI2 – AV2 – AI2 DI3 –...
  • Page 16: Hardware Installation

    Hardware Installation For the initial set-up, the plastic DIN rail case must be removed to access the circuit boards and internal connectors. The case also needs to be opened to connect a USB cable to the programming port of the Arduino board, and if the factory configuration of the internal jumpers for the RS-485 termination resistors or digital input configuration must be changed (see below).
  • Page 17: Arduino Mkr Board Installation

    Arduino MKR board installation To install your own Arduino MKR board in Iono MKR, or replace a pre-installed board, no tools are required. The Arduino MKR board top side pin headers (female) connect to the pin headers (male) of the top Iono MKR board. The Arduino MKR board is installed upside down, with the micro USB programming near the relay outputs terminal block.
  • Page 18: Iono Mkr Software Development

    Iono MKR software development Since Iono MKR is just a super-sized I/O shield for a standard Arduino MKR board, you don’t need any specific library to work on it. Our libraries and examples, available with source code on GitHub, will provide you with some handy utilities to speed up your development, including functionalities to monitor the inputs (filtering out possible noise) and control the outputs, HTTP APIs, Modbus support and much more.
  • Page 19: Optional Components

    Optional components Real Time Clock module Iono MKR can be shipped with an optional, factory-installed hardware real time clock with a dedicated long-life non-rechargeable back-up battery. The battery is only used to power the RTC chip when the main power is not available. Depending on operating conditions it should last up to two years if the Iono MKR board is not powered, more if the Iono MKR receives external power.
  • Page 20: Earthquake Sensor Module

    Replace the RTC lithium battery before it is completely discharged. Replace the battery every 5 years even if the battery is still working properly. The lithium battery must be replaced only with an identical CR1025 Lithium / Manganese Dioxide (Li/MnO2) battery. Do not throw lithium batteries into fire, do not solder on the cell body, do not recharge, do not open, do not short-circuit, do not reverse polarity, do not heat above 100°C and protect from direct sunlight, moisture and condensation.
  • Page 21: Block Diagram

    Block diagram BLOCK DIAGRAM Iono MKR User Guide...
  • Page 22: Board Layout

    Board layout BOARD LAYOUT Iono MKR User Guide...
  • Page 23: Technical Specifications

    Technical specifications Power supply 12…28V⎓ nom. (11…30V⎓ ) Reverse polarity and surge protection up to ±500V/ 2ohms 1.2/50μs using an auto resetting fuse and diodes 70mA with Arduino MKR1000 WiFi Current consumption at VS+ 12V⎓ unconnected inputs and relays off 165mA with Arduino MKR1000 WiFi Current consumption at VS+ 12V⎓...
  • Page 24 Max cable length for digital inputs (1-6) 30 meters Max cable length for analog inputs (1-4) 15 meters Digital outputs 4 power relays with single coil MAX output contact rating (each output) Resistive load (cos φ = 1): 6A at 250V~ (1500VA) Inductive load (cos φ...
  • Page 25 Storage temperature -20…+70 °C Relative humidity 5% to 90% noncondensing Protection degree IP20 128 g (Iono MKR) Weight 160 g (Iono MKR with Arduino MKR1010 WiFi) Iono MKR User Guide...
  • Page 26: Dimensions

    Dimensions DIMENSIONS Iono MKR User Guide...
  • Page 27: Disposal

    Disposal (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems). This marking on the product, accessories or literature indicates that the product should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
  • Page 28: Conformity Information

    Conformity Information The declaration of conformity is available on the internet at the following address: https://www.sferalabs.cc/iono-mkr/ This device complies with the essential requirements of the following directives and harmonised standards: ✓ 2014/35/UE (Low Voltage) ✓ 2014/30/UE (EMC) ✓ EN61000-6-1:2007 (EMC Immunity for residential, commercial and light-industrial environments) ✓...
  • Page 29: Canada

    Modifications: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Conditions of Operations: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
