*** USER'S MANUAL ***
FCC ID : SHBBS4100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BS4100 and is the answer not in the manual?

Questions and answers

Summary of Contents for RoyalDigital BS4100

  • Page 1 *** USER’S MANUAL *** FCC ID : SHBBS4100...
  • Page 2 The Federal Communication Commission Statement This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communication.

  • Page 3: Table Of Contents

    Content 1. Product Introduction…………………………………………3 Overview………………………………………………………….3 Main Features…………………………………………………….3 Product Notification……………………………………………...3 Application………………………………………………………..3 2. Before Start…………………………………………………..4 LED Display…………………………………………………….4 Hardware Feature….…………………………………………..4 2.2.1 Power Switch…………………………………………….4 2.2.2 Power Jack………………………………………………4 2.2.3 Bluetooth Status LED (Blue)………………...………..4 2.2.4 GPS Status LED (Green)…………………….………..4 2.2.5 Battery Status LED (Red)……………………………..4 Getting Start….………………………………………………..5 2.3.1 Step 1: Power on wireless GPS receiver……………5 2.3.2 Step 2: Link to Bluetooth device……………………….5 2.3.3 Step 3: Navigate………………………………………..7...

  • Page 4: Product Introduction

    1. Product Introduction 1.1 Overview RoyalDigital wireless BS4100 GPS receiver is designed with tack switch which makes users power on and off the device easily. The dimension is 79mm(L) x 50mm(W) x 17mm(H) and weight only 68 g, making it an ideal solution to carry everywhere.

  • Page 5: Product Notification

    Red LED indicates the status of the battery 2.2 Hardware Feature 2.2.1 Power Switch RoyalDigital wireless GPS receiver is designed with tack switch which makes users power on and off the device easily. 2.2.2 Power Jack With the USB type power jack, users can charge the device through charger, laptop or desktop.

  • Page 6: Gps Status Led (Green)

    device to link. Blinking Blue light: The wireless GPS receiver is transmitting data over Bluetooth. 2.2.4 GPS Status LED (Green) Blinking Green light: The wireless GPS receiver is powered on and receiving satellite signals. Constant Green light: The position is fixed. 2.2.5 Battery Status LED (Red) When using battery as power source Blinking Red light: The rechargeable Li-Ion battery is in low battery mode.

  • Page 8: Step 3: Navigate

    2.3.3 Step 3: Navigate Install your navigation software to your host Bluetooth device. After installation, please start the navigation system and set the correct COM port for your navigation software. Please note that different host Bluetooth devices may request different COM port.

  • Page 9: Fcc Notices

    2.4 FCC Notices This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation.
