Nera WorldPro 1000

User Guide

Table of Contents

Summary of Contents for Nera WorldPro 1000

Page 1 Nera WorldPro 1000 User Guide...
Page 2 American National Standards Institute (ANSI/LEEE C95.1-1992) recommends that people should not be exposed to radiation stronger than 1 milliwatt per square centimetre at the frequencies used in the Nera WorldPro 1000 terminal. Accordingly, the operator of the terminal should ensure that the area extending 0.5 metre from the front of the antenna be kept clear of personnel when the ter-...
Page 3 CAUTION Changes or modifications not expressly approved by the manufacturer could void the user's authority, which is granted by FCC, to operate this satellite terminal Nera WordPro 1000.
Page 4 CE : 0434 FCC ID : TSF 107020 IC : 6200A - 107020 GMPCS The Nera WorldPro 1000 terminal fully complies with the R&TTE directive © Nera SatCom AS, 2006...
Page 5: Table Of Contents
GPS ................18 Interfaces ............11 Satellite communications ........19 Setting up procedure ........... 20 Nera WorldSet signal strength bar ..21 BGAN LaunchPad signal strength bar..21 Antenna pointing ..........22 TECHNICAL DATA ........11 Satellite signal at low elevation angles ..23 Packet Switched (PS) service ......12...
Page 6 Data connection ..........32 Communication path .........A-4 LaunchPad help ..........33 Terminal log ............34 APPENDIX B - MAIN PARTS ....B-1 Audio and lights setup ........ 35 APPENDIX C - LIST OF TERMS ..... C-1 APPENDIX D - TROUBLESHOOTING .D-1 Nera WorldPro 1000...
Page 7: Introduction
General 64kbps on demand, e.g. for video, audio. File transfer - send and receive large files. The Nera WorldPro 1000 satellite terminal is a small Store and forward - save and send files e.g. video. lightweight satellite terminal providing transmission via Inmarsat’s BGAN broadband data and voice service.
Page 8: Standard Equipment
Standard equipment Accessories • Interface Unit with built-in Bluetooth • Nera WorldSet, see Appendix A - Nera WorldSet • Antenna Unit with built-in GPS receiver • Split cable for interconnection of separated Inter- (camera stand compatible mounting nut integrat- face unit and Antenna Unit, 3, 10 and 20 m •...
Page 9 � �� Figure 1 Nera WorldPro 1000, functions and services. Nera WorldPro 1000...
Page 10 INTRODUCTION ’ USER GUIDE cont �� Figure 2 Nera WorldPro 1000, identification. Nera WorldPro 1000...
Page 11: Physical Data
1 connector, USB v1.1 (USB v2.0 compatible) Dual port support: - control port/serial port profile - DUN (dial up networking) Weight: < 1 kg including battery Figure 3 Nera WorldPro 1000, dimensions and weight. Interfaces �� See figure 4 Bluetooth: Built-in antenna, Bluetooth v1.2...
Page 12: Packet Switched (Ps) Service
TECHNICAL DATA ’ USER GUIDE cont Packet Switched (PS) service • Calls made via Nera WorldSet connected to the Telephone Interface (ISDN compatible), or e.g. Shared channel (Variable Bit Rate service - VBR) Bluetooth handset (options). Pay for data sent/received •...
Page 13: Ac/Dc Adapter
Sleep mode: 0.5W Nera WorldPro 1000 CD Transmission: <20W (depending on satel- lite signal, devices connected, The CD ROM supplied with Nera WorldPro 1000 con- activity factor) tains: • BGAN LaunchPad program for operation from PC Antenna performance • manuals Gain: Tx 8.5 dBic, Rx 8.5 dBic...
Page 14: Satellite Coverage Map
OPERATION USER GUIDE Satellite coverage map Nera WorldPro 1000...
Page 15: Indicator Panel
�� Nera WorldPro 1000...
Page 16: Sim Card
Numbers (IMN) on which the user can be contacted • SIM PIN code (Personal Identification Number) irrespective of the Nera WorldPro 1000 used. • APN (Access Point Name) All outgoing calls will be billed to the owner of the SIM •...
Page 17: Installing Sim Card And Battery
The SIM card must be installed prior to installing the battery. �� The battery is enclosed with the Nera World- �� Pro 1000, and must be installed before it can be �� charged. Charge for 24 hrs the first time.
Page 18: Gps
GPS receiver has as clear a view of as much open In normal operation, the GPS receiver built in to sky as possible. the Nera WorldPro 1000 needs to be able to receive signals from at least three satellites so that it can From inside a window calculate a latitude and a longitude –...
Page 19: Satellite Communications
Satellite communications Three satellites are positioned stationary above equator. The satellites provide the �� coverage shown on the map. The Nera WorldPro 1000 searches for all satellites as default. The Nera WorldPro 1000 provides communication via satellite; which requires free line of sight.
Page 20: Setting Up Procedure
A good satellite signal is necessary to obtain a sta- The terminal is automatically set in Antenna Pointing ble network connection. mode. Alternatively, the Nera WorldSet or BGAN LaunchPad can be used as an aid in pointing the Nera �� WorldPro 1000, see next page. �� ...
Page 21: Nera Worldset Signal Strength Bar
USER GUIDE OPERATION ’ cont Nera WorldSet signal strength bar BGAN LaunchPad signal strength bar �� Nera WorldPro 1000...
Page 22: Antenna Pointing
45°. momentarily. The vertical angle ranges stepwise from 10° to 90°. The Nera WorldPro 1000 is now ready for call. Free line of sight to the satellite is required. Alternatively, the Nera WorldSet or BGAN LaunchPad Observe the satellite Signal indicator.
Page 23: Satellite Signal At Low Elevation Angles
�� The solution is to change the height above ground �� 30 cm up/down. On a flat roof the antenna should be �� installed close to the edge or horizontally on the roof, �� Nera WorldPro 1000...
Page 24: Cables And Lengths
All cables provide the best possible IP protection on the 4-wire/2 metres. Dust and moist protection. �� terminal. Nera WorldPro 1000 should only be used with �� these cables and accessories. The Nera WorldPro 1000 terminal including the Nera ��...
Page 25: Data Connection Via Usb
Connecting up Connect the PC to the USB connector on the Nera Installing USB drivers WorldPro 1000 to start the BGAN LaunchPad and set up a data connection or SMS. Two Nera USB drivers must be installed prior to con- necting the PC to Nera WorldPro 1000.
Page 26: Voice Communication Via Nera Worldset
To call the Nera WorldPro 1000, dial: Connect the Nera WorldSet to the telephone interface. 00870 + Inmarsat Mobile Number (IMN) For antenna pointing, you can use the Nera Worldset For use, see Nera WorldSet - User Guide display. Adjust for maximum signal.
Page 27: Split Operation
Antenna Unit outside. The split cable is optional (max 20 m). The Nera WorldPro 1000 can also be operated with the Interface Unit separated from the Antenna Unit. Activate buttons on the Interface Unit and the An-...
Page 28: Communication Via Bluetooth
USB port. Switch on the PC and, if required, The Bluetooth indicator lights green when the PC install the self-running software enclosed with the Blue- is connected. Nera WorldPro 1000 is now ready for tooth adapter. operation via Bluetooth.
Page 29: Bgan Launchpad
BGAN LaunchPad. and monitor data connections, send and receive text messages and manage your phone call history and Nera USB drivers must be installed in the PC prior contact details. to connecting to the USB cable between the PC and...
Page 30: Overview
�� Nera WorldPro 1000...
Page 31: Gps Status
USER GUIDE OPERATION ’ cont GPS status Nera WorldPro 1000...
Page 32: Data Connection
OPERATION ’ USER GUIDE cont Data connection Nera WorldPro 1000...
Page 33: Launchpad Help
USER GUIDE OPERATION ’ cont LaunchPad help Nera WorldPro 1000...
Page 34: Terminal Log
OPERATION ’ USER GUIDE cont Terminal log Nera WorldPro 1000...
Page 35: Audio And Lights Setup
USER GUIDE OPERATION ’ cont Audio and lights setup Nera WorldPro 1000...
Page 37: Inmarsat Bgan System
Partners (interconnects �� fixed telecommunication networks with the Inmarsat system, two in each Ocean Region). MES: Mobile Earth Station (Nera WorldPro 1000, a user terminal for the Inmarsat system). Figure A-1 Overview of the Inmarsat BGAN system. Nera WorldPro 1000...
Page 38: System Satellites
�� relative position to the earth. The satellites provide 99% landmass coverage. The Nera WorldPro 1000 can communicate via the three satellite Ocean Regions: Indian Ocean Region �� ...
Page 39 USER GUIDE USER GUIDE APPENDIX A - SYSTEM OVERVIEW ’ cont Figure A-3 BGAN Satellite Access Station. Nera WorldPro 1000 Nera WorldPro 1000...
Page 40: Communication Path
APPENDIX A - SYSTEM OVERVIEW ’ USER GUIDE USER GUIDE cont Communication path �� Nera WorldPro 1000 Nera WorldPro 1000...
Page 41: Appendix B - Main Parts
APPENDIX B - MAIN PARTS USER GUIDE �� Nera WorldPro 1000...
Page 43: Appendix C - List Of Terms
DUN Dial Up Network. MES Mobile Earth Station, a user terminal for an In- Elevation vertical angle to the satellite, i.e. the height marsat system; the Nera WorldPro 1000 is an MES for of the satellite above the horizon. the Inmarsat BGAN system.
Page 44 POR Pacific Ocean Region (F3 - 178ºEast). UMTS Universal Mobile Telecommunications System. PPP Point-to-Point Protocol used for serial data com- munication via the Nera WorldPro 1000 USB port or USB Universal Serial Bus. Bluetooth connection. USIM SIM card designed for 3G mobile telephony.
Page 45 �� Nera WorldPro 1000...
Page 46: Appendix D - Troubleshooting
�� Nera WorldPro 1000...
Page 47 �� Nera WorldPro 1000...
Page 48 �� Nera WorldPro 1000...
Page 49 APPENDIX D - TROUBLESHOOTING ’ cont �� Nera WorldPro 1000...
Page 50 �� Nera WorldPro 1000...
Page 52 Nera ASA Nera SatCom AS Bergerveien 12, PO Box 91 N-1375 Billingstad, Norway Tel: +47 67 24 47 00 Fax: +47 67 24 46 21 www.nera.no...
