Introduction
Digit Primo personal tracking is a powerful GPS locator which is designed for people, pets and asset tracking.
With superior receiving sensitivity, fast TTFF and GSM frequencies 850/900/1800/1900. Its small size and long battery life makes it ideal for
use on mobile items or for covert tracking. Location and reports can be real time or scheduled and the Digit software platform offers a
perfect solution for all your needs. Based on the embedded wireless tracking protocol, The Primo can communicate with the backend server
through GPRS/GSM network, and transfer reports of trips and device battery status and scheduled GPS position.
1. Buttons and LEDs
Dimensions
68 x 37 x 20mm
58g
On/Off Button:
Turns the device ON if already off (Press until the green LED flashes fast)
Turns the device OFF if currently on (Press until the red LED begins flashing)
SOS Button:
Hold for two seconds – the SOS message will be sent to the programmed numbers
Mini USB:
Used for charging
Reset key:
Pressing disconnects the internal battery
Press power button to restart the device
(Reset does not work if charger plugged in)
2. LED Description
There are three LED lights on the Digit Primo device, their description is as follows.
3. Usage
3.1 Supplied parts:
Digit Primo device
Charging cable
Power adaptor
Digit PRIMO instructions
LED
State
GPS
Flashing
(Blue)
Off
GSM
Flashing
(Green)
Off
Power
Slow red flash
Slow green flash
Fast red flash
Fast green flash
Meaning
Valid GPS fix
No GPS
GSM network connected
No GSM
Charging
Fully charged
Shutting down (
after power button pressed)
Starting up
(after power button pressed)
Advertisement
Table of Contents
Summary of Contents for Digit Primo
- Page 1 With superior receiving sensitivity, fast TTFF and GSM frequencies 850/900/1800/1900. Its small size and long battery life makes it ideal for use on mobile items or for covert tracking. Location and reports can be real time or scheduled and the Digit software platform offers a perfect solution for all your needs.
- Page 2 The charging process will last about 5 hours depending on battery condition. Note: Before using the Digit Primo device for the first time please make sure that the battery is fully charged, which will make the life of the battery much longer.
- Page 3 5. Programming via SMS The Digit Primo is shipped with 30s updates as standard. It will also send the SOS to a test SMS location, in order to send to your desired recipient you will need to send an SMS. The default settings are for MTN and changes will need to be made if you wish to use a Vodacom card.
- Page 4 6. Battery Life Many users ask what is the battery life of the Digit Primo? This is a bit of a variable and is thus very hard to quote accurately. Experiments have shown that if used for a whole day by a guard doing patrols, the Primo comfortably made 13 hours at 30s moving updates. Another test during the comrades where the runner ran without stopping, the battery lasted the 6h30min run as well as 3 hours afterwards, again on a 30s update.
