Summary of Contents for KingtronicRF KRF-688
- Page 1 Wireless Tire Pressure Monitoring System KRF-688 WIRELESS TIRE PRESSURE MONITONING SYSTEM MANUAL...
- Page 2 Wireless Tire Pressure Monitoring System Wireless Tire Pressure Monitoring System KRF-688 2-WAY Wireless Tire Pressure Monitoring System can ensure your safety driving. The system will automatic check your tires pressure and temperature any time and monitor them on during driving. It warns...
-
Page 3: System Installation
Wireless Tire Pressure Monitoring System System Installation Main display unit installation : Step 1: The power adaptor wire install to Holder of Display. Step 2: Pastes on the Holder of Display the 3M double coated foam tape, puts in front the driver seat to be easy to see also does not affect the driving view. - Page 4 Wireless Tire Pressure Monitoring System Step 5: Setting up the Main display unit in the holder . Connect to the power plug. - 3 -...
- Page 5 Wireless Tire Pressure Monitoring System Tire pressure and temperature sensor installation: Step 1: Take off the tires and bleed the air. Step 2: Recognize the number on each sensor with position of tire on the vehicle. = Left Front No.1 = Right Front No.2 ○...
- Page 6 Wireless Tire Pressure Monitoring System Step 3: Switch to ON and installation the sensor to the rim(see installation diagram) Step 4: Set up back the tires on the wheel and load with the completed tires in the vehicle. Step 5: Set up new stand value of tire .(see Set Pressure stand value ) Turn on the ignition switch of the vehicle until the power is activated on the cigar lighter.
-
Page 7: The System Operation
Wireless Tire Pressure Monitoring System The System Operation Key Function ON/OFF Manual/Function select Temperature/Pressure Switch Transmit signal Adjust Pressure values—press the key increase values Adjust Pressure values—press the key reduce values - 6 -... - Page 8 Wireless Tire Pressure Monitoring System Display Figure Function Each tire’s value of pressure/temperature Transmit/Receive State Detect tire pressure state Battery state Detect tire temperature state Auto tire pressure detect Temperature/Pressure unit switch Program learning/ Replacing tire option Program Unusual tire Pre./Tem. Warning Unusual tire Pre./Tem.
- Page 9 Wireless Tire Pressure Monitoring System System Alarm When the system detects any unusual pressure from tires is lower 15% of Pressure stand value . It’s warn state ,the display unit will turn yellow color backlight and beep sound . Each five minutes transmit signal warning.
- Page 10 Wireless Tire Pressure Monitoring System System Operation Power ON/OFF : Press button to turn ON/OFF the main unit. Turn ON - Press button , hear the sound and backlight light 5 sec. Turn OFF - Press button over 2 sec. And release when hear beep 2 sound and backlight light 3 sec. The display show when the system is Stand-by.
- Page 11 Wireless Tire Pressure Monitoring System Set Pressure stand value : (Take the Main Unit from the holder and set-up) Press confirm Press Press 3 sec After Beep enter the Select Function mode. Press Transmit Press switch signal tire position After hear 1-beep from Main When the new pressure Press 3 sec, After...
- Page 12 Wireless Tire Pressure Monitoring System Tires re-position : Press 3 sec Press confirm Press After 1-Beep enter the Select Function mode. Press Enter this monitor press switch Press ( increase ) flash tire position ( reduce) adjust flash tire pressure value Press Transmit Press...
-
Page 13: Fcc Notice
FCC Notice: Notice : The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device.
