  • Page 2 Preface This user guide explains how to use the Car Infotainment System and contains the information that a driver must know for safe driving. Be sure to keep this user guide inside the car. Give it also to the other driver when the car is delegated or rented.
  • Page 3 Preface Manufactured under license from Dolby Laboratories. USA-Federal Communications Commission (FCC) "Dolby" and the double-D symbol are trademarks of This device complies with part 15 of the FCC Rules. Operation is Dolby Laboratories. subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference Note: received, including interference that may cause undesired operation.

  • Page 4: Table Of Contents

    Contents Cautions ..................5 AV-IN..................25 Precautions................5 Sirius/XM (Optional)..............26 Discs ..................5 Phone ..................27 Safety Instructions .............7 Phone GUI...............27 Cautions before Use ............7 Phone Book ..............28 Cautions while Using the Product........8 Movie ..................30 Product Features...............9 Movie GUI ...............30 Main Unit................9 Movie Playlist Edit ............31 Remote Control..............10 Movie Playlist ..............31 Basic Operation...............12...

  • Page 5: Cautions

    Cautions 1. Cautions Discs • Playable Discs Type of Mark Recorded Precautions Media (Logo) Signals WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE Digital Video THIS PRODUCT TO RAIN OR MOISTURE. DVD-Video (MPEG2) Digital Video DVD-RW Divx DVD-R Digital Audio MP3/WMA/OGG Digital Video...
  • Page 6 Cautions • DVD Area Code • Handling Discs DVD Video System assigns the area code to DVD Video Players and DVD Do not use discs with rough edges. Using such discs could cause the product Discs, according to the areas where they are sold. For example, DVD Video to malfunction or be damaged.

  • Page 7: Safety Instructions

    Cautions cause a product failure or fire. Do not block the ventilation hole. If it is Safety Instructions blocked, a product failure or fire may happen due to accumulated heat. • Do not use when the product contains a defect or malfunction. Do not operate the product while it is in abnormal conditions.

  • Page 8: Cautions While Using The Product

    Cautions Cautions while Using the Product • The operation temperature range of the product is -10 to 60℃. Use the product only when the ambient temperate is within -10 to 60℃. If the user uses the product out of the temperature range, it may cause a product failure.

  • Page 9: Product Features

    Product Features 2. Product Features ⑥ ] Button - It goes to the main menu for you to select a source. Main Unit - When pressed for over one second, it goes to Setup. ⑦ [Tilt] Button - By pressing it shortly, the slope of LCD panel changes by one level. - While pressing it, the slope of LCD panel continuously changes.

  • Page 10: Remote Control

    Product Features Remote Control ③ Numeric Button • Radio - Select any of frequencies (1–6) stored in Preset. - When pressed for over one second, the current frequency is stored in the corresponding preset (1–6). - Enter the frequency in the frequency input panel. •...
  • Page 11 Product Features • Phone: When a phone call is issued or received for the entered phone number, it answers. • Movie/Music/Photo: Selects or unselects a playback file in the playback list editing area. [RETURN] Button ⑨ • Radio: Closes the frequency input panel. •...

  • Page 12: Basic Operation

    Basic Operation 3. Basic Operation Initial Use and Power Supply Volume Adjustment The power of this product is set to Off by default. Accordingly when you use When you press the [Volume] button or Volume (+)/(-) icons on the LCD this product for the first time after installation, move the ignition key location screen, the volume level increases or decreases.

  • Page 13: Adjusting The Slope Of Lcd Panel

    Basic Operation Adjusting the Slope of LCD panel Inserting and Removing Disc/SD Memory Card By pressing the [Tilt] button shortly, you can change the slope of LCD panel When you press the [ ] button, the LCD panel moves downward to expose level by level.

  • Page 14: Using The Touch Screen

    Basic Operation Using the Touch Screen This product uses the touch screen LCD display. You can perform functions Danger: Handling Remote Control Batteries by using their respective icons on the screen. • If you do not use batteries properly, they may explode. When video sources such as DVD, VCD, iPod VIDEO, AV-IN, Movie, Photo, •...

  • Page 15: Selecting Source

    Selecting Source on 4. Selecting Source Moving to the Main Menu Selecting a source on the Main Menu • When you press the [ ] button on the body or the [SETUP] button on the remote control while a source is running, the main menu appears. •...

  • Page 16: Common Gui

    Common GUI 5. Common GUI ① Changes to the main menu while the current source is running. ② Changes to the main menu after stopping the current source running. ③ Performs or stops the Mute function. The shape of icon changes according to the Mute function’s activation.

  • Page 17: Navigation

    Navigation 6. Navigation Insert the SD memory card that contains the Navigation map program into the NAVI slot and refer to the user guide for the Navigation map program that is separately provided. Note: Moving to the Main Menu while Navigation is Running The icon does not appear while the Navigation is running or outputting.

  • Page 18: Radio

    Radio 7. Radio Note: Radio Source Deactivation/Activation When a disc, iPod or AV-IN, SAT radio , movie, or music source is running, the radio source is deactivated. To activate the radio source, quit the running Radio GUI disc, iPod or AV-IN, radio, movie, or music source.

  • Page 19: Disc

    Disc 8. Disc ⑥ Changes to the DVD/VCD control. If the disc is CD/MP3CD, this is not supported. Disc GUI ⑦ Displays the current playback position. You can change it by clicking the ▪ desired position on the bar or dragging the arrow. ⓐ...

  • Page 20: Inputting Title/Chapter/Track

    Disc Inputting Title/Chapter/Track DVD/VCD Control The following figure displays the chapter input panel that has been open by clicking the chapter icon. ① Moves the cursor on the root/title menu selects the item where the cursor is located. ① Enter the chapter number to play back. ②...

  • Page 21: Ipod

    iPod™ 9. iPod™ Note: iPod Source Deactivation/Activation When this product is connected to an external device, the iPod source is iPod Video GUI automatically deactivated. If a radio, disc, AV-IN, radio, movie, or music source is running, the iPod source is deactivated. To activate the iPod source, disconnect the external device, connect the iPod device, and quit the running radio, disc, AV-IN, radio, movie, or music...

  • Page 22: Ipod Menu & List

    iPod™ • Music Lists iPod Menu & List The following shows the music list panel that is selected on the main menu. • iPod Main Menu ① Music list. When the list is selected, it changes to the corresponding list panel.
  • Page 23 iPod™ • Artists List • Artist Albums List The following shows the Artists list panel that is selected on the top music list. The following shows the Artist (e.g. Bigbang) album list panel that is selected in the upper Artists list. ①...
  • Page 24 iPod™ • Artist Album Playlist The following shows the playlist panel of the album (e.g. For The World) selected in the upper Artist album list. ① Album playlists. When pressed, it starts playing. ② Opens or closes the playlist panel. ③...

  • Page 25: Av-In

    AV-IN 10. AV-IN It outputs the CVBS video signals and stereo audio signals received from an external device that is connected to the external input port (see page **). Note: AV-IN Source Deactivation/Activation When this product is connected to an iPod device, the AV-IN source is automatically deactivated.

  • Page 26: Sirius/Xm (Optional)

    AV-IN 11. Sirius/XM (Optional) - 26 -...

  • Page 27: Phone

    Phone 12. Phone Note: Miscellaneous Icons Phone GUI Icon Description When a phone rings, it answers the phone by replacing the (Call) icon. When the call is connected, the hands-free function is performed or cancelled by replacing the (Call)/(Answer) icon. When a phone rings, it rejects answering by replacing the (Hang Up) icon.

  • Page 28: Phone Book

    Phone • Phone Book 02 Phone Book • Phone Book 01 The following shows the phone book that is selected in Phone Book Main. ① Changes to the phone book while you are absent. ① Moves to the previous panel. ②...
  • Page 29 Phone • Phone Book 03(e.g. Joe Richards) The following shows the phone book that is selected in the previous phone book. ① Changes to the previous panel. ② Mobile phone number saved. ③ Home phone number saved. ④ Company phone number saved. ⑤...

  • Page 30: Movie

    Movie 13. Movie Note: Playable File Format and Codec • Playable File Format: AVI, WMV, ASF • Playable Audio/Video Codec: MPEG4 ASP, MPEG4 SP, Xvid, WMV Movie GUI • The file of holding unplayable file extension can not be added to the movie playlist.

  • Page 31: Movie Playlist Edit

    Movie Movie Playlist Edit Note: Playlist Edit You can add or delete playable files saved in the SD memory card and USB • Screen on the left: The file administrator displays the folders and playable memory device and change their sequences. files saved in the SD memory card or USB memory device.

  • Page 32: Music

    Music 14. Music Note: Playable File Format • Playable File Format: MP3, WMA, OGG • The file of holding unplayable file extension can not be added to the Music GUI music playlist. • You can see a warning message of “NOT SUPPORTED AUDIO FILE”...

  • Page 33: Music List

    Music • Top List Music List • Playlist ① This is the top list screen. You can switch to the corresponding list panel by selecting the list. ① This is a playlist. Select and push a desired file to play the music. -Playlist: Switches to the edited playlist panel.
  • Page 34 Music • Artist • Artist Playlist (e.g. Mariah Carey) This is the artist list selected from the top list. This is the playlist of the artist selected from the artist list (Ex: Mariah Carey). ① This is the artist list. Switch to the corresponding artist playlist panel by ①...

  • Page 35: Photo

    Photo 15. Photo Note: Playable File Format • Playable File Format: BMP, JPEG • The file of holding unplayable file extension can not be added to the photo playlist. • You can see a warning message of “NOT SUPPORTED IMAGE FILE”...

  • Page 36: Rear View Camera

    Rear Camera & Phone Mute 16. Rear View Camera 17. Phone Mute When the Rear CAM is set to “On” after installing/connecting a rear viw The telephone lead is connected to the car kit. Upon making or receiving a camera, it will automatically switch to the Rear View Camera Source if the call, it switches to Phone Mute Source, mute the running source during a transmission is set to the rear gear regardless of the source being executed phone call, and the call is diverted through the speakers of the vehicle.

  • Page 37: Setup

    Setup—Display • Dimmer 18. Setup Adjust the brightness of LCD screen according to the brightness of use environment. Note: Initialization If the (Default) icon is pushed from every setting mode, the value is set to the initial value set at the time of manufacture. Display •...
  • Page 38 Setup—Display screen to apply the newly adjusted values. To return to the previous setting • Touch Adjustment values after canceling the adjusted values, please wait for 30 seconds. The screen icon may not work well as the touch sensitivity of the LCD screen is changed due to the severe temperature change of environmental change.
  • Page 39 Setup—Display • Clock • Zone - SYNC - Single Zone: Output the current source to an external A/V device connected ON: Automatically adjust the time displayed on the bottom of the product to the A/V OUT terminal. based on the time received from RDS. OFF: Do not use the automatic time adjust function.

  • Page 40: Sound

    Setup—Sound Sound Danger: Max. Volume Setting and Passenger Safety • Speaker Control If the Max. Volume is set too high, it can be harmful to the health of the You can set the volume and various other effects on the front/rear/left/right weak and elderly, pregnant women and nursing mothers and patients from a speaker.
  • Page 41 Setup—Sound • EQ Select • My EQ Set the equalizer (EQ). Set the EQ according to one's own taste. There are three default modes of POP, Classic and Rock and three user Set the values of three frequency zones such as BASS, MID and Treble. They setting modes.
  • Page 42 Setup—Sound • Source Offset • Voice The volume level can be adjusted differently according to the source type. Accordingly, set the Volume Offset of each source to output an appropriate volume level when running the source. The offset setup value can be adjusted in 7 levels by 2db up/down according to the current volume level.

  • Page 43: System

    Setup—System • Disc - AUDIO - Speaker System • Disc - VIDEO - Format Set the respective speakers of 5.1 speaker system when playing a DVD. Set the TV type that the DVD is played. - FRONT SPEAKER: Select Large or Small according to the size of the front - NTSC: As the type established by the National Television System speaker in use.
  • Page 44 Setup—System • Disc - AUDIO - Speaker Output • Disc - AUDIO - SPDIF (Sony/Philips Digital Interface) When generating a voice signal by connecting to an external digital audio unit, set the voice signal output method by using SPDIF. - DOWNMIX: Set this function when listening to the multi-channel voice signal through two-channel audio.
  • Page 45 Setup—System • Disc - AUDIO - Delay • Disc - Preference - Audio Adjust the Delay Time of each speaker by setting the distance according to Set the language supported by DVD. the speaker location except for the front speakers. •...
  • Page 46 Setup—System • Disc - Preference – Parental (Limited View Option) • Disc - Password - Mode This is the function that limits viewing in order to keep children from watching adult programs. - Password Mode: Select whether or not to set a password. ON: Use the password mode.
  • Page 47 Setup—System • Disc - Initialization ⑥ If a unique address of the mobile phone is created in the list (authentication list) on the right, the authentication process is normally When the user has set the System – DVD setup incorrectly by mistake, the terminated.
  • Page 48 Setup—System • Photo • ETC Set the time interval of photo slide show. - Beep: Turn on/off the beep sound when pushing a button or touch screen. • Rear CAM Set when connecting the rear view camera. - Auto Close ON: When the engine is stopped, the LCD panel will be closed automatically.

  • Page 49: Version

    Setup—Version Version ② Check the current version and update version and push the (START The user can check the currently installed/used program versions of Boot, OS, UPDATE) icon. Application, Phone and MICOM. The software upgrade may be performed without a prior notice to the user for performance upgrade. The update and other information may be posted on the product website of manufacturer and reseller.
  • Page 50 Setup—Version ④ If the update is completed, the window of “Update Completed” will appear. Push the「OK」button. ⑤ If the update is successfully completed, the screen will return to ①. Please check the updated version. If the update is completed, the main menu will appear;...

  • Page 51: Appendix

    Appendix 19. Appendix • General Symptom Cause Action Trouble Shooting Replace with a fuse of If the problem continues after performing the following actions, please same amperage. If the contact the place of purchase or customer support center (***-****-****). Power does not turn fuse blow again, consult Fuse has blown.
  • Page 52 Appendix • LCD Screen • Disc Symptom Cause Action Symptom Cause Action The image is not The parking brake is not Check that the parking Disc cannot be Another disc is already Eject the disc before displayed. pulled. brake is set. loaded.

  • Page 53: Notices For Installation And Service

    Appendix output other than those specified, it can damage the product or speaker. Notices for Installation and Service • Please be careful so that the blue wire of this product is not connected to power socket of auto antenna. Danger: Product Installation •...

  • Page 54: Installation And Removal Of The Main Unit

    Appendix Installation and Removal of the Main Unit • Removal • Installation–Installation Method by Using Universal Mounting Bracket ① Please remove the screws from the rear side of main unit in the reverse ① Insert the universal mounting bracket into the Instrument Panel of the car. order of installing the main unit.

  • Page 55: Components And Accessories

    Appendix Components and Accessories Main Unit Mounting Bracket Trim Cover Remote Control USB Extension Cable Power & Speaker Out AV IN/OUT iPod Multi-media Steering Wheel Bluetooth Microphone GPS Antenna Cable Assembly Cable Assembly Cable Remote Out Cable Battery Machine Screw(8EA) Split Bar SD Card Owner’s Manual...

  • Page 56: System Connection

    Appendix System Connection - 56 -...

  • Page 57: Specifications

    Appendix Specifications • Monitor • Bluetooth Screen Size 6.98 inch Wide Format (167.35mm×93.0mm×6.8mm) Core Version Bluetooth V 2.0 Display Method TFT Active Matrix LCD Range Class 2 Resolution 800(V) × 480(H) Profile HFP, A2DP, HSP, AVRCP, PBAP, OPP Color system NTSC, PAL, SECAM •...
  • Page 58 Appendix - 58 -...
