Modal MD-SPBT01 User Manual page 5

Number Component
2
+
3
AUX IN jack
4
-
(power)
5
button
6
USB port
Status
7
indicator LED
Volume Up
Plug an external audio device into this jack. The default source for
this speaker is Bluetooth. If a cable is inserted into this AUX IN jack,
the source is automatically switched to AUX IN. Unplug the cable
and the source automatically switches back to Bluetooth.
Volume Down
• Slide the switch to the right
LED ON (red/white LED blinking to enter auto pairing mode).
• Slide the switch to the left
OFF.
When power is on, the unit automatically connects to the last
paired Bluetooth device within six seconds. If the last paired
Bluetooth device is not in range, the unit automatically searches
for another device to pair to.
Plug the USB cable into this port.
Power
• LED is white when the speaker is turned on. LED is o when
the speaker is turned o .
Charging
• When the speaker is o , the LED is red while charging. After
charging is complete, the LED turns o .
• When the speaker is on, the LED is solid red while charging.
After charging is complete, the red LED turns o and the white
LED turns on.
Other
• No Bluetooth connection, the white LED ashes slowly.
• Bluetooth is in pairing mode, the white and red LEDs alternate
blinking.
• Successful Bluetooth connection, solid white LED.
• The white LED blinks quickly when increasing/decreasing the
volume. When the minimum/maximum volume is reached,
the LED is solid white.
• The LED quickly blinks red when the battery is low. The
speaker remains on for approximately 10 more minutes.
Function
to power on the speaker –
to turn the speaker o – LED
MD-SPBT01
5
