  • Page 1 GTS Traffic Systems Pilot’s Guide...
  • Page 2 Garmin. Garmin hereby grants permission to download a single copy of this manual and of any revision to this manual onto a hard drive or other electronic storage medium to be viewed for personal...
  • Page 3 (iv) damage caused by service performed by anyone who is not an authorized service provider of Garmin; or (v) damage to a product that has been modified or altered without the written permission of Garmin. In addition, Garmin reserves the right to refuse warranty claims against products or services that are obtained and/or used in contravention of the laws of any country.
  • Page 4 Distributor warranties are only valid in the area of intended distribution. Devices purchased in the U.S. or Canada must be returned to the Garmin service center in the U.K., the U.S., Canada, or Taiwan for service.
  • Page 5 Software are valuable trade secrets of Garmin and/or its third-party providers and that the Software in source code form remains a valuable trade secret of Garmin and/or its third-party providers. You agree not to reproduce, decompile, disassemble, modify, reverse assemble, reverse engineer, or reduce to human readable form the Software or any part thereof or create any derivative works based on the Software.
  • Page 6 Garmin GTS Traffic Systems 190-00587-02 Rev. E...

  • Page 7: Table Of Contents

    6.1.1 Control of Modes ................14 6.2 Traffic Information ................... 15 6.2.1 No-Bearing TAs ................16 6.3 ADS-B In Applications - SURF, AIRB ............18 6.4 Traffic Alerting ..................19 6.4.1 TAS/TCAS I Alerting ............... 19 190-00587-02 Rev. E Garmin GTS Traffic Systems...
  • Page 8 7.4 What capabilities does GPS data provide? ..........30 7.5 What kind of transponder is required for use with the GTS Traffic System? 30 7.6 Is ADS-B Out required with the GTS Traffic System? ........31 Section 8 Glossary ..................32 Garmin GTS Traffic Systems 190-00587-02 Rev. E...

  • Page 9: Section 1 System Description

    SECTION 1 SYSTEM DESCRIPTION Garmin GTS Traffic Systems are a family of Traffic Advisory Systems (TAS) and Traffic Alert and Collision Avoidance Systems (TCAS). The systems feature both active interrogation of aircraft transponders and reception of 1090 MHz Extended Squitter ADS-B broadcasts (ADS-B IN).

  • Page 10: Ads-B In

    These broadcasts contain much more data than just a simple position report, they include: identity (Flight ID/Tail Number, ICAO registration number, etc), ground track, ground speed, pressure altitude, indications of equipment capabilities, and emergency status. Figure 1 ADS-B Operation - FAA Illustration Garmin GTS Traffic Systems 190-00587-02 Rev. E...
  • Page 11 ATC radar picture to the aircraft. This aircraft is then included in the list of aircraft that is being provided TIS-B service and is then considered a “TIS-B participant.” 190-00587-02 Rev. E Garmin GTS Traffic Systems...
  • Page 12 Figure 3 TIS-B Operation - FAA Illustration NOTE: Even if the display is showing TIS-B traffic, unless the TIS-B participant indication is present (see Table 1) TIS-B services are not being provided specific to your aircraft. Garmin GTS Traffic Systems 190-00587-02 Rev. E...

  • Page 13: Section 3 System Specifications

    Garmin display units have the capability to show the status of the ground station services being received. An example for the GTN is shown below. See the display device Pilot Guide for the symbology used on that display. Unit Symbol Description Within coverage of a TIS-B ground station.

  • Page 14: Section 4 System Components

    The GTS 825/855 systems share a common system processor known as the “GTS Processor.” The GTS Processor can be configured during installation to be either a GTS 825 TAS or a GTS 855 TCAS I. Garmin GTS Traffic Systems 190-00587-02 Rev. E...

  • Page 15: Antennas

    Bearing from the bottom antenna on a retractable gear airplane is not used when the landing gear is extended. Interrogations transmitted from the bottom antenna are always omni-directional, regardless of the antenna type. 190-00587-02 Rev. E Garmin GTS Traffic Systems...

  • Page 16: Directional Antennas

    Figure 5 GA 58 Directional Antenna 4.2.1.2 Sensor Systems Low-Profile Antenna Sensor Systems antennas are low-profile directional antennas that may be installed on the top and/or bottom of the aircraft. Figure 6 Sensor Systems Low-Profile Directional Antenna Garmin GTS Traffic Systems 190-00587-02 Rev. E...

  • Page 17: Omni-Directional Antenna

    4.3.1 GPA 65 Amplifier Module (GTS 820 & 850 only) The GPA 65 is a combined Power Amplifier and Low Noise Amplifier that is required for use with the GTS 820 and GTS 850 systems only. Figure 8 GPA 65 PA/LNA Module 190-00587-02 Rev. E Garmin GTS Traffic Systems...

  • Page 18: Section 5 System Interfaces

    Contact your Garmin dealer to learn which displays are compatible with the GTS systems. Some displays may require the purchase and installation of additional modules and/or software.

  • Page 19: Landing Gear Position

    (operate/standby), initiating a self-test, or canceling/muting traffic advisories. Use of external switches is required with certain traffic displays that do not include integrated controls. External switches, when installed, are a momentary pushbutton type. 190-00587-02 Rev. E Garmin GTS Traffic Systems...

  • Page 20: Section 6 System Operation

    For display(s) that integrate control of ADS-B In and GTS Modes, configuration can be set to allow ADS-B In feature to be turned on or off while GTS is in Standby. This feature requires display(s) support. Garmin GTS Traffic Systems 190-00587-02 Rev. E...

  • Page 21: Traffic Information

    Figure 10 shows an example traffic display capable of showing additional data received via ADS-B. Intruder Altitude and Vertical Trend Figure 9 Example Traffic Display 190-00587-02 Rev. E Garmin GTS Traffic Systems...

  • Page 22: No-Bearing Tas

    Traffic Info Traffic Motion Touch For Vector (Green) Next Target Proximate Ownship Icon Non-Directional Traffic Traffic Display Radius Selected Vector Motion and Duration Touch To View Traffic Menu Figure 10 Example Traffic Display Garmin GTS Traffic Systems 190-00587-02 Rev. E...
  • Page 23 ADS-B is in Surface (SURF) Mode or own aircraft is on the ground. Ground traffic without directional information. Ground traffic is only displayed when ADS-B is in Surface (SURF) Mode or own aircraft is on the ground. 190-00587-02 Rev. E Garmin GTS Traffic Systems...

  • Page 24: Ads-B In Applications - Surf, Airb

    (see Figure 11). ADS-B and Orientation TCAS Status and Altitude Filter Traffic Display Radius Ownship Icon Selected Vector Motion and Duration Touch To View Traffic Menu Figure 11 Example Traffic Display Garmin GTS Traffic Systems 190-00587-02 Rev. E...

  • Page 25: Traffic Alerting

    GTS 800, GTS 820, and GTS 850 systems with software version 4.00 and later; and in GTS 825 and GTS 855 systems with system software version 3.00 and later. In earlier software versions, only radar altimeter is used for sensitivity level selection. 190-00587-02 Rev. E Garmin GTS Traffic Systems...
  • Page 26 6.4.1.1.4 No Available Inputs If none of the above inputs are available (radar altimeter, calculated height above ground, landing gear position, or groundspeed), the system will always remain in the most sensitive level, SL B. Garmin GTS Traffic Systems 190-00587-02 Rev. E...
  • Page 27 Intruder range is within 0.55 NM and vertical separation is within 800 feet. Intruder closing rate provides less than 20 seconds of separation or intruder range is within 0.55 NM. Table 4 TA Alerting Criteria 190-00587-02 Rev. E Garmin GTS Traffic Systems...

  • Page 28: Ads-B In Alerting

    ADS-B, ADS-R, or TIS-B for an intruder aircraft that can’t be tracked with active surveillance. Such targets are tracked with ADS-B In only, and are included in the display of traffic. GTS will also generate alerts for targets tracked with ADS-B In only. Garmin GTS Traffic Systems 190-00587-02 Rev. E...
  • Page 29 Unavailable or > 10,000 and ≤ 20,000 > 1,500 > 1,500 > 1,500 Unavailable or Unavailable or Unavailable or > 20,000 > 1,500 > 1,500 > 1,500 Table 5 Alerting Thresholds for ADS-B Traffic 190-00587-02 Rev. E Garmin GTS Traffic Systems...
  • Page 30 0.80 NM and 700 ft. Within the next 48 seconds, intruder range and relative altitude are predicted to be within 1.10 NM and 700 ft. Table 6 TA Alerting Conditions Garmin GTS Traffic Systems 190-00587-02 Rev. E...

  • Page 31: Ta Aural Alerts

    If the aircraft has retractable landing gear, all TA aural alerts will be muted when the landing gear is extended. Landing gear position does not mute TA aural alerts if height above ground is available. 190-00587-02 Rev. E Garmin GTS Traffic Systems...

  • Page 32: Ownship Air/Ground Detection

    • GPS groundspeed. Greater than 35 knots indicates in air, and less than 30 knots indicates on ground. • Air/ground message from a Garmin avionics system. Ownship air/ground detection is used for the automatic mode switching and calculated height above ground features.

  • Page 33: Calculated Height Above Ground

    If GPS position is not available, the on-ground altitude will still be used as a reference point as long as the ownship is on the ground and for up to 60 seconds after takeoff. 190-00587-02 Rev. E Garmin GTS Traffic Systems...

  • Page 34: Ground Traffic Filtering

    Calculated height above ground is used similarly to how radar altitude is used. Ground traffic is only filtered when the calculated height above ground is less than 1,700 feet. Garmin GTS Traffic Systems 190-00587-02 Rev. E...

  • Page 35: Self-Test

    Test Passed” (depending on the system type) will be played. If the self-test is unsuccessful, the aural announcement “[TAS / TCAS I] System Test Failed” will be played. The system may be installed so that the self-test cannot be initiated while airborne. 190-00587-02 Rev. E Garmin GTS Traffic Systems...

  • Page 36: Section 7 Q And A

    TCAS-equipped aircraft are nearby, so that the GTS traffic system can adjust its transmit power and reduce frequency congestion. The GTS 800 does not require a transponder interface (regulatory requirements for transponder usage still apply). Garmin GTS Traffic Systems 190-00587-02 Rev. E...

  • Page 37: Is Ads-B Out Required With The Gts Traffic System

    7.6 Is ADS-B Out required with the GTS Traffic System? No. The ADS-B In feature uses ADS-B, ADS-R, and TIS-B, but the ownship is not required to be equipped with ADS-B Out. 190-00587-02 Rev. E Garmin GTS Traffic Systems...

  • Page 38: Section 8 Glossary

    56-bit “message” field. Nautical Mile Other Traffic (other than TA or PA traffic) Proximity Advisory Traffic Advisory TAS: Traffic Advisory System TCAS: Traffic Alert and Collision Avoidance System TIS-B: Traffic Information Service - Broadcast Garmin GTS Traffic Systems 190-00587-02 Rev. E...
  • Page 40 © 2018 GARMIN Corporation GARMIN International, Inc. 1200 East 151 Street, Olathe, Kansas 66062, U.S.A. Garmin AT, Inc. 2345 Turner Rd., S.E., Salem, Oregon 97302, U.S.A. Garmin (Europe) Ltd. Liberty House, Hounsdown Business Park, Southampton, Hampshire SO40 9LR, U.K. GARMIN Corporation No.
