Summary of Contents for Accton Technology WMG623A
- Page 1 UIDE WLAN Module WMG623A...
- Page 2 UIDE WMG623A WLAN Module WMG623A E042010-CS-R01 XXXXXXXXXXXXX...
-
Page 3: Compliances
OMPLIANCES EDERAL OMMUNICATION OMMISSION NTERFERENCE TATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 4 OMPLIANCES HIS DEVICE IS INTENDED ONLY FOR INTEGRATORS UNDER THE FOLLOWING CONDITIONS The antenna must be installed such that 20 cm is maintained between the antenna and users, and The transmitter module may not be co-located with any other transmitter or antenna. For all products marketed in the US, OEM has to limit the operation channels in CH1 to CH11 for 2.4 GHz band by supplied firmware programming tool.
-
Page 5: About This Guide
BOUT UIDE This guide details the hardware features of the WMG623A WLAN Module, URPOSE including its physical and performance-related characteristics, and how to install the device and use its configuration software. This guide is for PC users with a working knowledge of computers. You UDIENCE should be familiar with Windows operating system concepts. -
Page 6: Table Of Contents
ONTENTS OMPLIANCES BOUT UIDE ONTENTS NTRODUCTION WMG623A Hardware Description ARDWARE PECIFICATIONS Physical Specifications Wi-Fi Specifications Compliances LOSSARY – 6 –... -
Page 7: Introduction
NTRODUCTION The WMG623A is a Wi-Fi PCI Express Card that allows simple design-in 802.11b/g/n Wi-Fi functionality for various products, such as notebooks and home gateways. The WMG623A includes a built-in high-performance CPU that off-loads Wi- Fi packet processing tasks from the main processor. The hardware form factor follows the PCI Express standard, but the data path conforms to an RGMII interface. -
Page 8: Specifications
ARDWARE PECIFICATIONS HYSICAL PECIFICATIONS PCI Express Card standard, 3.3 VDC NTERFACE 2 W maximum OWER ONSUMPTION 72 x 48 mm (2.83 x 1.89 in) HYSICAL 17 g (0.6 oz) EIGHT Operating: 0 to 50 °C (32 to 122 °F) EMPERATURE Storage: -20 to 70 °C (-4 to 158 °F) 5% to 95% (non-condensing) UMIDITY... -
Page 9: Compliances
| Hardware Specifications PPENDIX Compliances 802.11n (20 MHz, 400ns GI): 216.7, 195, 173.3, 144.4, 130, 115.6, 86.7, 72.2, 65, 57.8, 43.3, 28.9, 21.7, 14.4, 7.2 Mbps 802.11n (40 MHz, 400ns GI): 450, 405, 360, 300, 270, 240, 180, 150, 135, 120, 90, 60, 45, 30, 15 Mbps 11b mode: 20 +/- 0.5 dBm (peak) RF O UTPUT... -
Page 10: Glossary
LOSSARY IEEE 802.3-2005 specification for 10 Mbps Ethernet over two pairs of 10BASE-T Category 3 or better UTP cable. IEEE 802.3-2005 specification for 100 Mbps Fast Ethernet over two pairs of 100BASE-TX Category 5 or better UTP cable. IEEE 802.3ab specification for 1000 Mbps Gigabit Ethernet over four pairs 1000BASE-T of Category 5 or better UTP cable. - Page 11 LOSSARY the Bootstrap Protocol (BOOTP), adding the capability of automatic allocation of reusable network addresses and additional configuration options. Data passing between the access point and clients can use encryption to NCRYPTION protect from interception and evesdropping. A popular local area data communications network, which accepts THERNET transmission from computers and terminals.
- Page 12 LOSSARY Orthogonal Frequency Division Multiplexing: OFDM allows multiple users to ODFM transmit in an allocated band by dividing the bandwidth into many narrow bandwidth carriers. Service Set Identifier: An identifier that is attached to packets sent over SSID the wireless LAN and functions as a password for joining a particular radio cell;...
- Page 13 LOSSARY WPA Pre-shared Key: WPA-PSK can be used for small office networks with WPA-PSK a limited number of users that may not need a high level of security. WPA- PSK provides a simple security implementation that uses just a pre-shared password for network access.
- Page 14 WMG623A E042010-CS-R01 **************...
