Before You Begin You must have at least the following: • A desktop computer with an available PCI 2.2, 32-bit, 5 volt PCI slot • At least a 500MHz processor and 128MB of memory • 802.11a, 802.11b 802.11g Access Point (for Infrastructure Mode) or another 802.11a, 802.11b, or 802.11g wireless adapter (for Ad-Hoc;...
Page 3
Continued... The Install Screen will appear. Click Install Driver If the CD Autorun function does not automatically start on your computer , go to Start > Run and type “D:\Driver\ setup.exe.” If it does start, proceed to the next screen. “D:\Driver\setup.exe.”...
Page 4
Continued... Click Next Click Next Click Finish Shut down your computer...
Page 5
Pls. Note that the ant. Should be this one To avoid damage caused by static electricity, make sure to properly ground yourself by rst touching a metal part of your computer to discharge any static electricity before working with the WL-660GS.
Page 6
Installing the WL-660GS Wireless PCI Adapter in Your Computer (cont.) Gently connect the antenna to the antenna stand. Finished!
Restart Your Computer When you restart your computer this Found New Hardware Wizard (Windows XP) screen will appear: Select Install the software automatically (Recommended) Click Next For Windows XP: This Hardware Installation alert screen may appear after the desktop computer restarts. Click Continue Anyway to nalize the installation...
Page 8
Your Installation is Complete! After you have nished the installation in Windows XP, 2000, Me, or 98SE, the WL-660GS Conguration Utility will automatically start and the utility icon will appear in the bottom right hand corner of the desktop screen (systray). If this icon appears GREEN, then...
Page 9
Appendix For Windows XP, if you wish to use the utility, please do the following steps. Click the XP Networking icon to use the Zero Conguration Wireless Settings. Click Advanced “Use Uncheck Windows to congure my wireless network settings.” Click...
Page 10
Channel: Displays Strength: Displays the Link distance from the access the channel Quality for the WL-660GS point. information. By wireless connection to the default, the channel is access point. The Signal set to 6 and selection Strength represents the...
Page 11
Authentication: Wireless Mode: SSID: The Service Set You can specify the The factory setting is Identier is the name assigned authentication mode set to Infrastructure. to the wireless network. The for the wireless Ad-Hoc mode is used factory SSID setting is set to network.
IP Address Conguration To connect to a network, make sure the proper network settings are congured for WL-660GS. Microsoft Windows XP: Go to Start > Right-click on My Network Places >select Properties > Right-click and select Properties on the Network Connection associated with the DWL-AG530.
Settings > Network and Dial- up Connections > Right Click and select Properties on the Local Area Connection associated with the WL-660GS. Click Internet Protocol (TCP/IP) Click Properties Dynamic IP address setup Used when a DHCP server is available on the local network.
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
